PCB Piezotronics IMI SENSORS ICP TO603C91 Installation And Operating Manual page 18

Model Number
603C91
Performance
Sensitivity(± 10 %)
Measurement Range
Frequency Range(± 3 dB) 30 to 600,000 cpm
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral Noise(100 Hz)
Spectral Noise(1 kHz)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material 316L Stainless Steel
Sealing
Electrical Connector
Electrical Connection Position
[6]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
INDUSTRIAL ICP® ACCELEROMETER
EN GLISH SI
100 mV/g 10.2 mV/(m/s²)
± 50 g ± 490 m/s²
0.5 to 10,000 Hz
1,500 kcpm 25 kHz
2
350 µg
3,434 µm/sec
± 1 % ± 1 %
≤ 7 % ≤ 7 %
5,000 g pk 49,050 m/s² pk
-65 to +250 °F -54 to +121 °C
See Graph See Graph
IP68, IP69K IP68, IP69K
≤ 3.0 sec ≤ 3.0 sec
≥ 0.3 sec ≥ 0.3 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
< 150 Ohm < 150 Ohm
8 to 12 VDC 8 to 12 VDC
2
8 µg/√Hz
78.5 (µm/sec )/√Hz
2
5 µg/√Hz
49.1 (µm/sec )/√Hz
2
4 µg/√Hz
39.2 (µm/sec )/√Hz
8 8
> 10 Ohm > 10 Ohm
11/16 in x 1.73 in 18 mm x 44 mm
1.95 oz 55 gm
1/4-28 Female No Metric Equivalent
2 to 5 ft-lb 2.7 to 6.8 Nm
Ceramic Ceramic
Shear Shear
316L Stainless Steel
Welded Hermetic Welded Hermetic
4-Pin, M12 4-Pin, M12
Top Top
Optional versions have identical specifications and accessories as listed for the standard model except
[1]
where noted below. More than one option may be used.
[2]
- Metric Mount
M
[3] Supplied Accessory: Model M081A61 Mounting Stud 1/4-28 to M6 X 1 (1)
[3]
TO - Temperature Output
[4] Temperature Output Range
Temperature Scale Factor
Electrical Connections(Pin A)
Electrical Connections(Pin B)
Electrical Connections(Pin C)
Electrical Connections(Pin D)
[3]
[3]
[3]
[3]
[3]
[5]
N OTES:
[1]Conversion Factor 1g = 9.81 m/s².
[2]The high frequency tolerance is accurate within ±10% of the specified frequency.
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]1/4-28 has no equivalent in S.I. units.
[6]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 081A40 Mounting Stud (1)
Model ICS-2 NIST-traceable single-point amplitude response calibration at 6000 cpm (100 Hz) for
each axis (1)
Entered: LK Engineer: GD
Date: 06/11/2020 Date: 06/11/2020 Date: 06/11/2020 Date: 06/11/2020 61657
3425 Walden Avenue, Depew, NY 14043
Revision: D
ECN #: 50817
OPTION AL VERSION S
+36 to +250 °F +2 to +121 °C
5.56 mV/°F + 32 +10 mV/°C
Acceleration Signal / Power Acceleration Signal / Power
Ground Ground
No Connection No Connection
Temperature Output Temperature Output
Sales: MC Approved: BAM Spec Number:
