- Page 1 SK517 COM Express® Type 7 Carrier Board w/PCIe 104 User’s Manual Revision Date: Mar.5. 2024...
-
Page 2: Safety Information
SK517 User’s Manual Revision Date: Mar.5.2024 Safety Information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the ... -
Page 3: Revision History
SK517 User’s Manual Revision Date: Mar.5.2024 Revision History Revision Date (yyyy/mm/dd) Changes Version 1.0 2024/03/05 Initial release... -
Page 4: Table Of Contents
SK517 User’s Manual Revision Date: Mar.5.2024 Index ........................... 1 AFETY NFORMATION ................................1 LECTRICAL SAFETY ................................1 PERATION SAFETY ..................................1 TATEMENT ..........................2 EVISION ISTORY 1: P ..................4 HAPTER RODUCT NTRODUCTION ..............................4 1-1. PECIFICATIONS .............................. 6 1-2. -
Page 5: Chapter 1: Product Introduction
SK517 User’s Manual Revision Date: Mar.5.2024 1. C 1: P HAPTER RODUCT NTRODUCTION 1-1. Specifications System COM Express Intel® Xeon® D-1700 processor (Ice Lake-D LCC) (Type 7) ntel® Xeon® D-1700 processor (Ice Lake-D LCC) COM Express •Xeon® D-1746TER 2.0/3.1GHz 15MB, 67W, 10C CPU Options •Xeon®... - Page 6 SK517 User’s Manual Revision Date: Mar.5.2024 Internal I/O Display Port Header 2x (1x20Pin) SATA Port (Standard 2x (up to 6Gb/s) 7Pin) SATA Power COM (RS232) 6x (2 TX/RX form COMe module) USB 3.0 (2x10Pin) Front Panel (2x5Pin) Smart Fan 2x (1x CPU Fan, 1x System Fan)
-
Page 7: Board Diagram
SK517 User’s Manual Revision Date: Mar.5.2024 1-2. Board Diagram... -
Page 8: Connector & Pin Header
SK517 User’s Manual Revision Date: Mar.5.2024 1-3. Connector & Pin Header... -
Page 9: Chapter 2: Jumpers And Connectors Locations
SK517 User’s Manual Revision Date: Mar.5.2024 2. C 2: J HAPTER UMPERS AND ONNECTORS OCATIONS 2.1. Connector & Pin Definitions J4 /J5/ J6/ J7 : COM1 / COM2 / COM3 / COM4 RS232 RS422 RS485 Data- Data+ DTR- DSR# RTS#... - Page 10 SK517 User’s Manual Revision Date: Mar.5.2024 (2-3) (1-2) RS232 (1-2) (2-3) RS485 Half Duplex (1-2) (1-2) RS485/422 Full Duplex JP15: COM3 Pin9 select Function (1-2) Closed (3-4) Closed (5-6) Closed +12V JP16/ JP17: COM3 Mode select JP12 JP13 Mode (2-3)
- Page 11 SK517 User’s Manual Revision Date: Mar.5.2024 J17: MXM_DP(A/B) Function Pin Function Function Function DPA_TN1 DPA_TP3 DPA_AUXP_CLK DPB_TN1 22 DPB_TP3 DPB_AUXP_CLK DPA_TP0 13 DPA_TN3 DPA_AUXN_DAT DPB_TP0 14 DPB_TN3 DPB_AUXN_DAT DPA_TN0 15 DPA_TP2 DPB_TN0 16 DPB_TP2 DPA_TN2 DPA_AUX_SEL 37 DPA_DET DPB_TN2 28...
- Page 12 SK517 User’s Manual Revision Date: Mar.5.2024 SIM_CARD1 Pin Function Function UIM1_PWR UIM1_RESET UIM1_VPP UIM1_CLK_R UIM1_DATA SIM_CARD2 Pin Function Function UIM2_PWR UIM2_RESET UIM2_VPP UIM2_CLK_R UIM2_DATA CN5, CN6: SATA Power Definition CN3, CN4: SATA Function SATA_TX0P SATA_TX0N SATA_RX0N SATA_RX0P LAN 1 Pin Function...
- Page 13 SK517 User’s Manual Revision Date: Mar.5.2024 J8: System FAN Connector Function System FAN OUT +12V J11: Front Panel Function HDLED+ PWLED+ HDLED- PWRBTN# RESET JUSB3_1: USB 3.0 Port Function Function +5V_USB0 USB2_DP1 USB3_RXN0 USB2_DN1 USB3_RXP0 USB3_TXP1 USB3_TXN0 USB3_TXN1 USB3_TXP0 USB3_RXP1...
- Page 14 SK517 User’s Manual Revision Date: Mar.5.2024 J2: MXM_VGA Function MVGA_VS MVGA_SCL MVGA_HS MVGA_SDA MVGA_VCC MVGA_R MVGA_B MVGA_G J10: MXM FAN connector Function +12V CN18: MXM DC-IN Definition DC-IN: System DC-IN Definition +DCIN JP23: Clear CMOS Function (1-2) Closed Normal(default) (3-4) Closed...
- Page 15 SK517 User’s Manual Revision Date: Mar.5.2024 STACKPC1:...
