Trinity MX Series Instruction Manual

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit
www.horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product.
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability
of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly
can result in damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this
Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without
direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC.
This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to
assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
Age Recommendation: Not for children under 14 years. This is not a toy.
NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside of
the intended purpose and will not provide warranty service related thereto.
Table of Contents
Specifications ...................................................................................................1
Connect .............................................................................................................2
Battery Wire Connection ....................................................................................2
Motor Wire Connection ......................................................................................2
Receiver Wire Connection .................................................................................2
Power On and Calibrate ....................................................................................2
Power On/Off ESC .............................................................................................2
Throttle Calibration ...........................................................................................2
LED Indicator Status .........................................................................................2
ESC Modes ........................................................................................................3
High Voltage Protection .....................................................................................3
Low Voltage Protection ......................................................................................3
Thermal Protection Mode ..................................................................................3
Throttle Protection Mode ...................................................................................3
Sensored and Sensorless Modes .......................................................................3
MX10 Pro Gen2 ESC Wireless Module Connection ..........................................3
Wireless Application .........................................................................................4
Real-Time Operating Data Monitor ....................................................................4
Programming Settings Options ..........................................................................4
Throttle .............................................................................................................5
Brake ................................................................................................................5
Boost ................................................................................................................5
Turbo ................................................................................................................6
General Settings ...............................................................................................6
Troubleshooting Guide ......................................................................................7
1-Year Limited Warranty ..................................................................................7
Warranty and Service Contact Information .....................................................8
FCC Information ................................................................................................8
IC Information ...................................................................................................8
Compliance Information for the European Union ............................................8
MX Series Elecstronic Speed
Instruction Manual
NOTICE
MEANING OF SPECIAL LANGUAGE
Specifications
Cont. Current
Burst Current
Applications
LiPo/NiMH Cells 2–4S LiPo / 5–12S NiMH
BEC Output
Dimensions
(L x W x H)
Weight
*MX10 ESC Motor Limit 3.5T
1
MX8 Pro Gen2
220A 200A
1000A 1000A
1:8 Vehicle 1:10 / 1:12 Vehicle
2–3S LiPo / 5–10S NiMH
6.0V, 7.4V Adjustable / 10A 6V/7.4V Adjustable / 10A
55mm x 40mm x 34mm 38.5mm x 38mm x 27mm
140g 102g
TEP0013, TEP0014
MX10 Pro Gen 2*
