Summary of Contents for Ekso Bionics EVO

  • Page 1 Belt Upgrade...

  • Page 2: Contact Information

    Ekso EVO in violation of your contract with Ekso Bionics, Inc. Ekso Bionics, Inc. does not accept any responsibility for any damage caused to its products, either directly or indirectly, as a result of use and/or repair by unauthorized personnel.
  • Page 3 TABLE OF CONTENTS PAGE Contact Information Ekso Bionics Customer Experience Copyright All Rights Reserved Trademarks Patents/Patents Pending Disclaimer III. Table of Contents Chapter 1: Introduction Chapter 2: Instructions Chapter 3: Ekso EVO Fitting Guide and User Manual...

  • Page 4: Chapter 1 Introduction

    The new Ekso EVO waist belt is designed to be more comfortable, more durable, and easier to adjust. Older Ekso EVO devices can be retrofit to use the new waist belt with the belt upgrade kit – 109201 ASSY, BELT UPGRADE KIT, EVO. Follow the steps in this guide to...

  • Page 5: Chapter 2 Instructions

    Page 3 Instructions CHAPTER 2 INSTRUCTIONS Figure 1 If you have not already done so, remove the old waist belt from the arms. Next, unzip neoprene covers and remove the lower torso tubes from the upper torso tubes. Figure 2 Next, remove the torso pad from the torso pad support by peeling it up off the Velcro.
  • Page 6 Page 4 Instructions Figure 3 Using a T20 torx wrench loosen the two M4 screws securing the upper torso tube, and remove it from the silver upper tube lug by sliding down. Figure 4 Insert the new upper torso tub onto the lug with the holes facing towards you. Insert the two M4 screws into the top two holes and lightly tighten to attach the upper torso tube to the lug.
  • Page 7 Page 5 Instructions Figure 5 Rotate the upper torso tube 180 degrees until the two remaining threaded holes are exposed. Position the neoprene linkage cover so that the hole in the cover is surrounding the two holes. Attach the torso pad support using a T20 torx wrench and the two remaining M4 screws.
  • Page 8 Page 6 Instructions Figure 7 Insert the new torso tubes provided in the waist belt upgrade kit to the same setting you had previously. Zip the neoprene linkage cover closed. Repeat the process for the other arm. Figure 8...

  • Page 9: Chapter 3 Ekso Evo Fitting Guide And User Manual

    Use the same “standard” or “wide” arm setting as on the previous waist belt. CHAPTER 3 EKSO EVO FITTING GUIDE AND USER MANUAL For further assistance in fitting or using your Ekso EVO device, refer to the user manual or instructional videos available on our website. Use Instructions...
