- Page 1 F O R D C U S T O M MONTEREY O W N E R S H A N D B O O K...
- Page 2 ThIs handbook Is to be used In conjunctIon wIth the manufacturers orIgInal handbook, and safety !MPORTANT InformatIon and operator InstructIons for any equIpment as per the specIfIcatIon of your vehIcle.
-
Page 3: Table Of Contents
OPERATING INSTRUCTIONS ADDENDUM Operating the ramp and access Addendum Handbrake Wiring diagrams Securing a manual wheelchair PAS 2012 TechnIcal SpecIfIcatIon 14-15 Tyre inflator After Sales Support Six way power seat... -
Page 4: Operating The Ramp And Access
F OR D C U STOM | OPERATING THE RAMP VW KEY FOB GM WIRELESS REMOTE Unlock the vehicle using the central locking system on the key. Check the switch on the side of the GM wireless remote handset Ensure there is sufficient space behind the vehicle. Stand well is set to ON. - Page 5 | FO RD C U STOM OPERATING THE RAMP Press OPEN to open the powered tailgate and ramp. To close the ramp and tailgate, from either in or outside the vehicle, press CLOSE.
- Page 6 F O R D C U STO M | OPERATING THE RAMP After 15 minutes of the vehicle being left unlocked the air suspension automatically enters sleep mode. To activate the air suspension press UNLOCK on the key. If you are inside the vehicle press UNLOCK on the key or turn the ignition on.
-
Page 7: Handbrake
| FORD CUSTOM HANDBRAKE HANDBRAKE The handbrake is operated by pressing the button to the right of the steering wheel. Press it once to turn the handbrake on secur- ing the vehicle in its position. The handbrake symbol on the dashboard will illuminate and the red light on the handbrake switch will be on. -
Page 8: Securing A Manual Wheelchair
F O R D C U STO M | SECURING A MANUAL WHEELCHAIR 1. Position the wheelchair in the rear saloon and use the four restraints to safely secure it. (see page 6 on Securing the Restraints). See figure 1. 2. - Page 9 | FO RD C US TOM SECURING A MANUAL WHEELCHAIR !MPORTANT These instructions to be used in conjunction with the seperate/additional instructions supplied by Unwins. Due to the great variation in wheelchair design you must satisfy yourself that the restraints are appropriate for your wheelchair.
-
Page 10: Tyre Inflator
F O R D C U STO M | TYRE INFLATOR Your Ford Custom comes with a tyre inflator kit. The kit replaces the need for a spare tyre. Inside the kit box you will find a cylinder of fluid, which will plug a puncture in your tyre, and a tyre inflator to connect to the 12V socket in the car. -
Page 11: Six Way Power Seat
| FO RD CU STOM SIX WAY POWER SEAT The six way seat enables the driver to move forwards, backwards, up and down and rotate through 90 degrees allowing a convenient transfer from wheelchair to seat. !MPORTANT Please refer to manufacturers product manual for full instructions and settings Forward and aft Height... -
Page 12: Addendum
Replacement parts used in the conversion of this vehicle can be sourced from GM Coachwork. Telephone the Parts Department on 01626 855055 PAS 2012 COMPLIANCE: This vehicle complies with PAS 2012-1. PAS0101 GM Coachwork Ford Custom Monterey Note: Optional extras may not be PAS Accredited... -
Page 13: Wiring Diagrams
| FO RD C U S TO M WIRING DIAGRAMS WIRING DIAGRAM... -
Page 14: Pas 2012 Technical Specification
F OR D C U STOM | UWAV TECHNICAL SPECIFICATION WHEELCHAIR ACCESS ENTRANCE DIMENSIONS Width (mm) Height (mm) 1538 DESIGNATED TRAVELLING POSITION Width (mm) Length (mm) 1130 Wheelchair space gradient (degrees) Maximum seated eye line height (mm) 1358 Internal roof height (mm) 1518 Maximum wheelchair mass (kg) MAXIMUM ACCESS DIMENSIONS... - Page 15 | FOR D C U S TOM UWAV TECHNICAL SPECIFICATION Max permitted front axle weight (kg) 1275-1282 Max permitted rear axle weight (kg) 820-994 Gross vehicle weight (GVW) 2095-2276 Kerb weight (kg) 22020-2201 Fuel tank capacity (litres) As stage 1 Ground clearance (mm) SEATING PROVISIONS Variant 1...
-
Page 16: After Sales Support
WARRANTY AND BREAKDOWN For technical issues with the operation of the components involved in the conversion of the vehicle to wheelchair access e.g. the ramp, reels, winch etc. For other issues, e.g the engine, please contact your local VW dealer. FAMILIARISATION CHECKS (MOTABILITY) This is a vehicle check after delivery to ensure you are happy with the operation of the equipment... - Page 17 | FORD CU STOM NOTES If your WAV has been purchased VAT exempt, all subsequent Our Customer Care Department is very experienced and they are responsible for ensuring you have the finest possible repairs, maintenance and parts relating to that vehicle may be VAT free and an exemption form must be completed in each service throughout the life of your vehicle.
- Page 18 GET IN TOUCH t: 01626 244090 e: service@gmcoachwork.co.uk w: www.gmcoachwork.co.uk Every endeavour has been made to ensure that the information and details contained in this brochure were accurate at the time of going to press November 2021. However the company reserves the right, whilst preserving the essential characteristics of the models described, to introduce at any time modifications, changes of details, equipment or accessories.
