- Page 1 User Manual 4K-Minicam-system EMC4K Status: V1.0.5EN, 30.10.2023 Program Status: Hardware EMC4K-xxx-01-x (18.09.2023) Software: AVT-miniCam V1.0.05 (30.10.2023)
-
Page 2: Table Of Contents
Contents List of abbreviations ......................3 Introduction ..........................4 1. Operating Conditions and Safety Instructions ..............5 2. Scope of Delivery ....................... 6 3. Assembly/Use ........................7 4. Charging the Battery ......................8 5. Technical Specifications ....................9 6. Operation of the miniCam Software ................10 7. -
Page 3: List Of Abbreviations
List of abbreviations Electro-Magnetic Compatibility FC/PC Fiber Connector / Physical Contact Personal Computer Universal Serial Bus Fiber Optic Cable Fiber cable... -
Page 4: Introduction
Introduction With the AVT 4K-MiniCam system, you have acquired a variable, easy-to-connect measuring device with small dimensions. The data transmission is done optically with a Kevlar reinforced high flexible fiber optic cable (FOC). The connection to personal computers (PCs)/laptops is made with a USB 3 connector (type A). -
Page 5: Operating Conditions And Safety Instructions
1. Operating Conditions and Safety Instructions The 4K-MiniCam is designed for indoor applications only. For outdoor applications, please con- tact the manufacturer (AVT). The permissible ambient temperature and humidity must be ob- served. The camera must never be exposed to excessive temperatures! The voltage rating must be observed for connecting the camera and the charger to power. -
Page 6: Scope Of Delivery
Optionally, the FOC with FC/PC connections is routed through the housing. The user manual is either enclosed or provided online for download. Figure 1: Standard scope of delivery of the AVT 4K-MiniCam (left: without internal accumulator, right: with internal accumulator) -
Page 7: Assembly/Use
(FOC) is led directly out of the camera housing via an EMC-proof bend protection sleeve. The AVT 4K MiniCam is very easy to use via Plug & Play (UVC standard). The MiniCam software is designed for the Windows operating system (version ≥ 10). One side of the FOC is connected inside the camera and comes out directly as a fiber optic at the back. -
Page 8: Charging The Battery
4. Charging the Battery (optional) If the camera is used with battery option, the charging socket must be properly screwed to the cover to prevent interference fields from entering! The battery is designed for permanent operation of the camera for at least 8 hours. There is also a production-related spread of the operating time, but it is over 8 hours. -
Page 9: Technical Specifications
126 mm / 186 mm (with battery inside) Width 50 mm Height (with foot) 50 mm (60 mm) Weight 385 g Order Information AVT – EMC4K - xxx - xx - A Focal length Version EMC hardened 032: 3.2 mm Internal battery 01: version 1 4K-MiniCam 045: 4.5 mm... -
Page 10: Operation Of The Minicam Software
6. Operation of the miniCam Software (free of charge) The basic software for operating the AVT 4K-MiniCam is called miniCam. When installing the software, the necessary certificates and drivers are installed, with which the connection to the camera can be established. When the optical converter is connected to USB 3.0 and the cam- era is powered or switched on (A option), it is recognized in the software. - Page 11 1. You can show and hide the blue pane on the left with clicking the three horizontal lines on the top left of the window. 2. Multiple AVT 4K-MiniCams cameras can be connected to the laptop / PC simultaneously. From the “Video Device” drop down the different video cameras can be selected. In case...
-
Page 12: Operation Of The Minicam-Pro Software
7 by the number 1 is pressed that this section fills the entire window. Figure 7: Software demonstration of the AVT miniCam for different settings 7. Operation of the miniCam-Pro Software (chargeable) The miniCam-Pro software has all the functionalities of the basic miniCam software with many added functionalities. - Page 13 Figure 8: miniCam-Pro software different settings Figure 9: miniCam-Pro change detection section interface ( “Home”)
- Page 14 Change detection with miniCam-Pro software 1. Change in detection area: During camera operation, if you want to detect changes in a specific area, you can tick the “Add Detection Area” checkbox and mark out the area in which changes should be detected (mouse movement by pressed left button). Then you can check the box “Capture Detected Change”...
- Page 15 2. Here you can select a criterion for change detection. You can select one or multiple options of the following: Image Change, Brightness Change, Color Change. You select an option by checking the checkbox “is Activated” in the respective subsection. For each option there is a slider for controlling the sensitivity in detection.
- Page 16 Version 1.00 Initial creation of the document (18.09.2023) 1.01 Extension of the document (04.10.2023) 1.02 Extension of the document (09.10.2023) Contact details AVT GmbH Automatisierungs- und Verfahrenstechnik Am Hammergrund 1 98693 Ilmenau Germany Tel: +49 (0)3677 6479-56 Web: www.avt-ilmenau.de Mail: info@avt-ilmenau.de...
