- Page 1 INSTRUCTIONS MANUAL TURBOPACK YOUR PROTECTION BY EXCELLENCE...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS TECHNICAL CHARACTERISTICS COLUMN ASSEMBLY (2400-3200) OPTIONAL OVERHEAD HEAT DEFLECTOR ASSEMBLY (1600-2400) OPERATING INSTRUCTIONS SHRINK WRAPPING TIPS PREVENTIVE MAINTENANCE MAINTENANCE SPARE PARTS LIST WARRANTY RIPACK ADDITIONAL PRODUCTS DECLARATION OF CONFORMITY... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Users of the TURBOPACK® must read this user’s guide completely before the first use. Do not use this appliance in regulated zones where there is a specific risk of fire or explosion. Comply with local gas regulations. Do not use the appliance to shrink plastic film on a floor made of combustible materials or with waste (wood, plastic, etc.). - Page 4 SAFETY PRECAUTIONS This appliance, like all other gas appliances, consumes air and produces combustion fumes that contain CO2 and CO. Exposure to high levels of CO gas is lethal. Make sure there is sufficient ventilation in accordance with the amount of time the appliance is used.
-
Page 5: Technical Characteristics
TECHNICAL CHARACTERISTICS 1200 1600 2000 2400 3200 Energy developed 75 kW 110 kW 143 kW 177 kW 210 kW 280 kW 64,500 Kcal 94,500 Kcal 122,500 Kcal 153,500 Kcal 181,000 Kcal 240,500 Kcal Heating power (255 957 BTU’s) (375 006 BTU’s) (486 119 BTU’s) (609 137 BTU’s) (718 266 BTU’s) -
Page 6: Column Assembly (2400-3200)
COLUMN ASSEMBLY (2400 – 3200) 1. Carefully remove the protective boxes 2. Lower the frame and check that the wheels manoeuvre correctly 3. Screws and nuts are in the black casing 4. Assemble the column using 2 operators or a hoist and attach to the hook. 5. -
Page 7: Optional Overhead Heat Deflector Assembly (1600-2400)
OPTIONAL OVERHEAD HEAT DEFLECTOR ASSEMBLY (1600-2400) 1. Use a 10 mm spanner for the 8 M6x20 screws 2. Use the 7 M6x20 screws on the column and position the rail as shown in the picture. - Page 8 OPTIONAL OVERHEAD HEAT DEFLECTOR ASSEMBLY (1600-2400) 4. Hook the cable with the snap hook. 3. Place the visor with its carriage on the rail. 5. To adjust the load balancer properly, release the stresses by loosening the pads (4 Allen key 5 screws). Slide the cap a few times, then slightly retighten the 4 screws (contact tightening).
-
Page 9: Operating Instructions
OPERATING INSTRUCTIONS PROHIBITED WITH TURBOPACK® LIQUID PHASE PROPANE GAS HORIZONTAL CYLINDER (Ex: Forklift fuel) TURBOPACK® works with (Vapor-Type cylinders) PROPANE gas in the gaseous phase. Connect the valve(s) to 1 to 3 new propane cylinders, depending on your model. The regulator type depends on the gas standard in each country. - Page 10 OPERATING INSTRUCTIONS 3. Using a N°5 Allen key, loosen the 4 screws then pull the two handles towards you. Adjust the position of the handles to the operator's height, then tighten the 4 screws. 4. Open the PROPANE gas cylinder valve(s) to 90°. 5.
- Page 11 OPERATING INSTRUCTIONS 8. Close the red taps on the column above your load/pallet to save gas. 9. Make an initial turn without ignition to familiarise yourself with turning corners. Then approach the TURBOPACK® to a distance of 30 cm to start it. The guide wheel determines the minimum distance from the pallet.
- Page 12 OPERATING INSTRUCTIONS 12. Adjust your walking speed while estimating the quality of the film shrinkage. Once the column has passed one side of the pallet, start the Turbopack rotating and continue shrinking without stopping. Rotate 90° to prevent the column from overheating the corners of the pallet (see drawing).
-
Page 13: Shrink Wrapping Tips
SHRINK WRAPPING TIPS CALCULATING THE LENGTH OF A COVER (made to measure) : Half-wide+ ~10 % • Measure from the bottom of the load to the top, starting from the widest side + half the horizontal face + ~10% to allow the Height film to pass under the pallet. -
Page 14: Preventive Maintenance
PREVENTIVE MAINTENANCE Lubricate the pistons of the gas taps #248235 every TUTORIAL LINK three months or every 500 hours. They must not get stuck. Replace gas hoses as soon as cuts or cracks appear. TUTORIAL LINK Every 5 years at the latest. -
Page 15: Maintenance
MAINTENANCE SEFMAT DECLINES ALL RESPONSIBILITY IN THE EVENT OF DISMANTLING OF THE TURBOPACK® BY A PERSON OUTSIDE THE DISTRIBUTION NETWORK AND/OR WHO IS NOT QUALIFIED TO CARRY OUT MAINTENANCE OPERATIONS. COLUMN DOESN’T START 1. No gas supply • Re-prime the safety valves, checking that there are no leaks. - Page 16 MAINTENANCE 1. No gas supply Cleaning injectors and burners : 1. Remove the M5 locking screw from the burner (1). 2. Remove the ignition chimney (2) and burner (3). 3. Using tool #233426, to carefully remove the injector (4). 4. Clean the parts with a low-pressure jet of compressed air. 5.
- Page 17 MAINTENANCE Tutorial Video Link 2. No spark at the spark plug • Replacing the red button Piezo igniter(131072) : 2,5 + 5 Using a 2.5 Allen key to remove the 4 screws from the black casing Using Allen key 5 to remove the 2 retaining screws. Remove the plastic sleeve at the bottom of the piezo and pull out the ignition wire.
- Page 18 MAINTENANCE THE COLUMN DOES NOT SWITCH OFF Lien Tuto vidéo 1. Blocked valve(s) Lubricate the pistons (see "PREVENTIVE MAINTENANCE") Replace the gas valve(s) #248235 : 2,5 + 5 10 + 17 + 19 Using a 2.5 Allen key, remove the 4 screws from the black casing 2.
-
Page 19: Spare Parts List
SPARE PARTS LIST Article Code Picture Description 131072 Piezo igniter 133675 Crankcase 133679 Mixing box 139027 Propan jet 48.100 139057 Turbopack blind jet 142050 Brake levers 143073 EU pressure gauge 143074 UL pressure gauge 146161 Turbopack Handlebars 148229 Turbopack Spring Return Control 148231 Swivel wheel with brake... - Page 20 SPARE PARTS LIST Article Code Picture Description 148232 Fixed wheel 148233 Support wheel 148237 Swivel wheel without brake 150231 Load balancer 233426 Jet tool 233455 Turbopack start combustion 233456 Combustion N°2 234137 Turbopack regulator 235317 Cable sheath and seal assembly 236107 Start cable (spark plug + cable + piezo connection) 236108...
- Page 21 SPARE PARTS LIST Article Code Picture Description 248235 Gas tap 250028 Rubber hose DIN Ø 6 Lg 1m with connections 38G (A - B) 250090 Rubber hose DIN 1,5 m Ø int. 6, with connections 38G (A - B) 250160 Rubber hose UL 1,5 m Ø...
-
Page 22: Warranty
In order to assert his rights, the customer purchasing the TURBOPACK® must inform RIPACK®, in writing at the following address info@sefmat com, of the existence of defects within a maximum period of seven 7 days from their discovery, under penalty of forfeiture of any action relating there to. -
Page 23: Ripack Additional Products
RIPACK ADDITIONAL PRODUCTS MULTICOVER FILM SEALERS The MULTICOVER sealers allow to make pallet covers and bags from rolls of shrink-film when required and in any size. Make savings by avoiding useless stock of various heights and sizes. Contact your distributor for a quote or an appointment https://ripack.com/produits/multicover-960/ MULTICOVER 955 Ripack®... -
Page 24: Declaration Of Conformity
CE - KONFORMITÄTSERKLÄRUNG Le fabricant soussigné : The manufacturer undersigned : Der unterzeichnende Hersteller: SEFMAT S.A.S, 7 RUE DE BETNOMS, 33185 LE HAILLAN, FRANCE Déclare que l’appareil : Hereby declares that the appliance : Erklärt hiermit, dass das Gerät : TURBOPACK ®... - Page 25 REGISTER YOUR PRODUCT ONLINE WARRANTY CONTRACT ripack.com/en/register-a-product...
