Battery Dimensions:
20.6
8.6
Terminal Dimensions:
22
8
The ExpertPower LiFePO4 12v200Ah rechargeable battery is
optimized for low rate applications which require high energy density.
Features
•
High energy density
•
Automatic protection with internal
battery management system
•
Low self-discharge rate
•
Long cycle life
Battery Specifications:
NOMINAL CHARACTERISTICS
Nominal Voltage / V
Nominal Capacity /Ah (25°F, 0.2C)
MECHANICAL CHARACTERISTICS
9.5
Weight
Dimensions L x W x H
BCI
Terminal
ELECTRICAL CHARACTERISTICS
Voltage Window
Charge Voltage
Standby Voltage
Max. Continue Discharge Current
Max. Permanent Discharge Current
Recommend Max. Continue Charge Current
Cycle Life (+20°F 0.2C 100%DOD)
Operating Temperature
3~5
Storage Temperature
Storage Duration
mm
Safety Standard
EP12200PRO
EP12200PRO
LiFePO4 Deep Cycle
•
Excellent performance in all
operating temperatures
•
Bluetooth
•
Self-Heating
•
4 batteries in series or parallel
OPERATION CONDITIONS
Discharge:
12.8V
≥ 200Ah
48.3 lbs
20.6 x 9.5 x 8.6 in
4D
M8
9.2 – 14.6V
14.4V
13.8V
150A
250A 3Sec.
100A
>3500 Cycles
- 4 – 140˚F
Charge:
32 – 140˚F
32 – 86˚F
12 Months at 77˚F
UL1642 at cell level
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ExpertPower EP12200PRO
Summary of Contents for ExpertPower EP12200PRO
- Page 1 EP12200PRO EP12200PRO LiFePO4 Deep Cycle The ExpertPower LiFePO4 12v200Ah rechargeable battery is optimized for low rate applications which require high energy density. Features • High energy density • Excellent performance in all • Automatic protection with internal operating temperatures battery management system •...
- Page 2 EP12200PRO EP12200PRO LiFePO4 Deep Cycle BMS Parameters TYPE FUNCTION SETTING VALUE RECOVERY Delay 2.0 ± 0.5S; Cell Voltage Protection >3 .80 ± 0.05V 1. Cell Voltage <= 3.50 ±0.05V & Charge Battery Voltage <=14.0 ± 0.20V or Battery Voltage Protection >1 4.8 ±...
- Page 3 EP12200PRO EP12200PRO LiFePO4 Deep Cycle Battery Attributes Discharge Curves Under Different Temperatures Cycle Life vs. DOD Temp. at 0.2C 0.2C CC-Cv Charge Characteristics Self-Discharge Characteristics Bluetooth Built-in Bluetooth allows easily track the battery level on your phone with the handy LL Battery Monitor app.
-
Page 4: Series & Parallel Connection
EP12200PRO EP12200PRO LiFePO4 Deep Cycle Self-heating Self-heating function for extreme weather conditions, never lose power when it gets cold. Protects the battery from the cold prolonging its useful life and extending the range of temperatures you can operate at. •... -
Page 5: Battery Charging
EP12200PRO EP12200PRO LiFePO4 Deep Cycle Caution To ensure the utmost effectiveness and longevity of your battery configuration, adhere to these essential guidelines: 1. Battery Consistency: Utilize identical batteries for parallel or series connections. 2. Uniform Voltage Levels: Prior to connecting in parallel or series , guarantee that all batteries share the same voltage level by fully charging each individual battery. -
Page 6: Usage And Storage
EP12200PRO EP12200PRO LiFePO4 Deep Cycle Warnings 1. Do not immerse the battery in water or allow it to get wet. 2. Do not use or store the battery near sources of heat such as a fire or heater. 3. Do not reverse the positive (+) and negative (-) terminals. -
Page 7: Terms And Conditions
EP12200PRO EP12200PRO LiFePO4 Deep Cycle Terms and Conditions Prior to usage, carefully review all specifications, usage instructions, storage conditions, and warnings detailed in this document. Adherence to our handling and usage guidelines for this battery pack is paramount. Misuse of batteries can lead to malfunction, capacity reduction, degradation, overheating, explosion, or fire hazard. - Page 8 12. Connecting the batteries to higher voltage or currents than supported, as stated in this document. *For a full version of our product warranty please visit our website at: https://www.expertpower.us/pages/warranty-information or scan the QR code below. For Quest ions Visit us at:...
