Battery Dimensions:
13
6.8
Terminal Dimensions:
16
8
Overview
The ExpertPower LiFePO4 12V 100Ah rechargeable battery is
optimized for low rate applications which require high energy density.
Features
•
High energy density
•
Automatic protection with internal
battery management system
•
Low self-discharge rate
•
Long cycle life
Battery Specifications:
Nominal Voltage / V
Nominal Capacity /Ah (77°F, 0.2C)
MECHANICAL CHARACTERISTICS
8.4
Weight
Dimensions L x W x H
BCI
Terminal
ELECTRICAL CHARACTERISTICS
Voltage Window
Charge Voltage
Standby Voltage
Max. Continue Discharge Current
Max. Permanent Discharge Current
Recommend Max. Continue Charge Current
Cycle Life (68°F 0.2C 100%DOD)
Operating Temperature
3~5
Storage Temperature
Storage Duration
mm
Safety Standard
LiFePO4 Deep Cycle
•
Excellent performance in all
operating temperatures
•
Bluetooth
•
4 batteries in series or parallel
NOMINAL CHARACTERISTICS
OPERATION CONDITIONS
EP12100BT
12.8V
≥ 100Ah
22.6 lbs
13 x 6.8 x 8.4 in
Group 31
F12/ M8
9.2 – 14.6V
14.4V
13.8V
100A
210A 3Sec.
50A
>3500 Cycles
Discharge:
- 4 – 140˚F
Charge:
32 – 140˚F
32 – 86˚F
12 Months at 77˚F
UL1642 at cell level
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ExpertPower EP12100BT
Summary of Contents for ExpertPower EP12100BT
- Page 1 EP12100BT LiFePO4 Deep Cycle Overview The ExpertPower LiFePO4 12V 100Ah rechargeable battery is optimized for low rate applications which require high energy density. Features • High energy density • Excellent performance in all • Automatic protection with internal operating temperatures battery management system •...
- Page 2 EP12100BT LiFePO4 Deep Cycle BMS Parameters TYPE FUNCTION SETTING VALUE RECOVERY Delay 2.0 ± 0.5S; Cell Voltage Protection > 3.80 ± 0.05V 1. Cell Voltage <= 3.50 ±0.05V & Charge Battery Voltage <=14.0 ± 0.20V or Battery Voltage Protection > 1 4.8 ± 0.20V 2.
- Page 3 EP12100BT LiFePO4 Deep Cycle Battery Attributes Discharge Curves Under Different Temperatures Cycle Life vs. DOD Temp. at 0.2C 0.2C CC-Cv Charge Characteristics Self-Discharge Characteristics Bluetooth Built-in Bluetooth allows easily track the battery level on your phone with the handy LL Battery Monitor app.
-
Page 4: Series & Parallel Connection
EP12100BT LiFePO4 Deep Cycle Series & Parallel Connection Supports expansion up to 4 batteries sequenced in either series at 48V 100Ah, or 10 batteries in parallel at 12V 1000Ah. Wiring Considerations During the wiring of sequenced batteries, it is imperative to adhere to the following guidelines to ensure optimal safety and performance: •... -
Page 5: Battery Charging
EP12100BT LiFePO4 Deep Cycle Battery Charging Efficiently charging LiFePO4 Batteries involves a precise 2-stage algorithm known as "Constant Current/Con- stant Voltage" (CC/CV). Following the standard LiFePO4 profile, the process entails a 0.2C Constant Current (CC) charge up to 14.2V, followed by Constant Voltage (CV) at 14.4V charge until the current reduces to ≤ 0.05C. -
Page 6: Usage And Storage
EP12100BT LiFePO4 Deep Cycle Usage and Storage 1. Before Use Inspection: Before employing the battery, conduct a thorough examination to ensure its integrity, free from visible damage or structural irregularities. 2. Terminal and Other Visual Checks: Do not utilize the battery if terminals are bent, broken, or if the battery... -
Page 7: Warranty Information
11. Use of an appliance with built-in charging for a different battery chemistry. 12. Connecting the batteries to higher voltage or currents than supported, as stated in this document. *For a full version of our product warranty please visit our website at: https://www.expertpower.us/pages/warranty-information or scan the QR code below. - Page 8 EP12100BT LiFePO4 Deep Cycle For Ques tions Visit us at: (562) 630 - 3002 6437 Alondr a Blvd And Suppo rt Expert Power.us support@expert power.us Paramoun t, CA 90723...
