- Page 1 AX Stove User Guide AX Stove User Guide April 2014 BS EN 13240:2001 +A2:2004 CE BK525 Rev03...
- Page 2 AX Stove User Guide Arada Ltd April 2014 Congratulations on the purchase of your new Arada stove! More than 30 years of experience has been put into the development of your stove to ensure ultimate performance and years of trouble free use and enjoyment.
-
Page 3: Table Of Contents
Cracked glass ......8 Further resources / reading 9 Guarantee BK525 Rev03... -
Page 4: Warnings
Any further warnings in this document will be marked out in a box such as this one. Ignoring the warnings could lead to damage/injury to persons and/or property. 1.1 Health and Safety Please consult health and safety guidelines for advice on handling heavy and/or large items. BK525 Rev03... -
Page 5: Advice On Fuel Types
Arada recommends the use of approved smokeless fuels which have been deemed suitable for use on closed appliances including multi fuel stoves. For additional advice on fuels, please refer to The Solid Fuel Association. BK525 Rev03... -
Page 6: Before Using Your Stove
AX Stove User Guide 3 Before using your stove Arada stoves are designed to be operated with the re door(s) closed at all times, apart from refuelling (when alight) or cleaning (when cold). Never leave the appliance unattended for an extended length of time with the door(s) open. -
Page 7: Air Inlet Controls
Figure 1: Single door stove air inlet controls. 4.1.1 Primary air Primary air enters the appliance through the inlets near to the bottom of the re door. Your stove has a control knob to adjust the ow of the primary air. BK525 Rev03... -
Page 8: Airwash System / Secondary Air
5. After ten to fteen minutes, close the primary air control and regulate the airwash system to control the burn rate and maintain clear glass, typically by reducing to approximately half open. BK525 Rev03... -
Page 9: Burning Solid Fuels
4. When the re is well alight regulate the burning rate by controlling the primary air inlet control. 5. The airwash should be opened su ciently to keep the door glass clean. BK525 Rev03... -
Page 10: Warning - Fume / Smoke Emissions
6 Further information for all stove owners 6.1 Door glass The door glass should remain clear during normal burning. However under certain conditions, such as burning at a low rate, using damp wood or overnight BK525 Rev03... -
Page 11: Reduced Burning
This will allow a free ow of air through the appliance thus preventing moisture and condensation forming inside the stove and chimney. This preventative maintenance will ensure your stove stays in the best condition for the coming winter months. BK525 Rev03... -
Page 12: Replacement Parts
• Put the fork end of the operating tool into the slots of the ash pan and remove from the ash pit chamber. • Empty the ash into a suitable container and replace the ash pan into the stove, withdraw the operating tool and close the re door. BK525 Rev03... -
Page 13: Ongoing Care For Your Arada Stove
When the appliance is cold, open the re door so that it is at right angles to the front of the stove and lift the re door up o the hinges. BK525 Rev03... -
Page 14: Liners / Rebricks
You should discontinue use of your stove until it has been repaired. You can source replacement glass kits from your stove dealer or online at www.aradastovesandspares.com BK525 Rev03... -
Page 15: Further Resources / Reading
• BESCA - Building Engineering Services Competence Assessment Limited www.besca.org.uk • Blue Flame Certi cation www.blue amecerti cation.com • Certsure www.certsure.com • NAPIT - National Association of Professional Inspectors and Tester www.napit.org.uk • OFTEC - Oil Firing Technical Association Limited www.oftec.org.uk BK525 Rev03... - Page 16 AX Stove User Guide • Stroma www.stroma.com • Arada Technical Support 01297 35998 (Mon-Fri 8:30am-5pm) technical@aradastoves.com • Arada Stoves Support Site www.aradastoves.com/support BK525 Rev03...
-
Page 17: Guarantee
When you contact the helpline, they will need to know: • Your name, address, post code and telephone number. • Clear and concise details of the fault. • Your proof of purchase, installation and annual servicing details will also be required. Information is also available at www.aradastoves.com/support BK525 Rev03... - Page 18 AX Stove User Guide Manual last updated: April 2014 ©Arada Ltd 2017 Arada Ltd - The Fireworks - Weycroft Avenue - Axminster - Devon - EX13 5HU +44 (0)1297 35700 | info@aradastoves.com | www.aradastoves.com BK525 Rev03...
