Auto Vox T9 Pro User Manual

Stream media rear view mirror

Advertisement

Stream Media
Rear View Mirror
English
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T9 Pro and is the answer not in the manual?

Questions and answers

Rodolfo B Barrera
June 1, 2025

Do I need an SD card to view the rearview in real time as a monitor on the mirror screen?

1 comments:
Mr. Anderson
June 1, 2025

No, you do not need an SD card to view the rearview in real time on the Auto Vox T9 Pro mirror screen. The SD card is only required for continuous recording.

This answer is automatically generated

Neal
May 16, 2025

If the rear backup light wire is connected, will the mirror automatically go to rear view if it is in screen saver mode and display is off and the car is put into reverse?

Subscribe to Our Youtube Channel

Summary of Contents for Auto Vox T9 Pro

  • Page 1 Stream Media Rear View Mirror English User Manual...
  • Page 3 Introduction Thank you for purchasing our T9Pro OEM stream media mirror dash cam with detached front camera. Please read the manual carefully before using the product. The wrong operation will invalidate the manufacturer's warranty. This installation guide is only a reference to help you install the mirror dash cam, and it is not applicable to all types of vehicles. If you have any questions, please contact us by the customer support window at www.auto-vox.com or by sending an email to our aftermarket service via service@auto-vox.com.
  • Page 4: Table Of Contents

    ontents Package Contents ............................................Installation ................................................Installing the Mirror ............................................Installing the Detached Front Camera ....................................... Installing the Rear Camera ........................................... Wiring Diagram ..............................................Installing the Memory Card .......................................... Parameters ................................................Functions ................................................System Set Up ..............................................Playback Software ............................................Troubleshooting ..............................................
  • Page 5 ackage Contents Rear View Mirror* 1 Detached Front Rear Camera * 1 Bracket * 1 GPS Antenna * 1 Wrench * 1 Camera* 1 Stream Media Rear View Mirror English User Manual User Manual* 1 Power Cable * 1 Video cable * 1 Adapter * 4 Fuse Tap Adapter x2...
  • Page 6: Installation

    nstallation 1. Installing the Mirror a. Remove the original mirror. Hold the base of the bracket. Adhere to the glass, and pull out Take off the rear-view mirror. the old one towards the top roof of the car.
  • Page 7 b. Find the correct position and then Install the bracket of the mirror. Hold the bottom of the bracket and Adhere to the glass, and push it Clamp the base and twist the screw Done. find the correct position. to move forward. with a wrench or screwdriver.
  • Page 8 Adapter #1: For most Volkswagen and Audi car series (excluded the mirror brackets with a protective case).
  • Page 9 Adapter #2: For most Dodge, Chrysler, Jeep, Volvo compact, BMW compact and Peugeot 308 series (excluded the mirror brackets with a protective case).
  • Page 10 Adapter #3: For most Honda and Subaru car series.
  • Page 11: Installing The Detached Front Camera

    Adapter #4: If the adapters mentioned above are not suitable for your vehicle, please glue the bracket base on the windshield by UV glue, then install with mirror. Attention for replacement of mirror brackets: If all the adapters and original brackets mentioned are not suitable for your vehicle, please contact our customer service and we will send you a suitable one.
  • Page 12: Installing The Rear Camera

    3. Installing the Rear Camera 1. Install the rear camera on the license plate. ① Remove the screws and take off the license plate by a wrench or a screwdriver. ② Install the camera to a desired position on the top or bottom of the license plate. ③...
  • Page 13: Wiring Diagram

    2. Mount rear camera onto car rear window. ● Please remove the screws from the rear camerabracket. ● Replace the rear camera bracket with the windshield mounting bracket. ● Tear off the tape on the windshield mounting bracket. ● Please use water, alcohol, cloth, etc. to clean the rear windshield where the rear camera is scheduled installed. ●...
  • Page 14 2. Connect the power cable to the fuse box. Find the fuses and metal of the car which the yellow wire (B+), red wire (ACC) and the black wire (GND) connect to. 3. Connect the red wire (reverse trigger wire) on the video cable to the positive reverse light wire. Note: 1.
  • Page 15 2. The fuse box and constant fuse refers to the power supply components on the car. A. Connect the yellow wire (B +) to the fuse box (make sure the fuse tap adapter is connected to the yellow wire (B +)). This wire needs to be connected to the fuse which is a constant power source.How to find it? Using the car test light to check the fuses if there can get power or not when the car is OFF.
  • Page 16 Most cars have at least one obvious ground point near the fuses box, please connect the ground lug to the ground point (as shown in the picture). * If you have to remove a fuse from your car, you need to insert the removed fuse into the empty slot of the supplied fuse adapter.
  • Page 17: Installing The Memory Card

    nstalling the Memory Card Installing/Removing the Memory Card Note: If the Micro SD card is not inserted, the system can be used as a rear view monitor to display the real-time road conditions behind the vehicle. This product does not provide a Micro SD card. It needs to be purchased separately to use the continuous recording function.
  • Page 18: Parameters

    3. When the emergency recording files reach the limits, the dash cam will not be able to record. If necessary, please back up the files regularly before deleting the files or formatting the memory card. 4. To prevent damage to the recording videos,please turn off the dash cam before removing the SD card. arameters Display parameters display screen...
  • Page 19: Functions

    Working voltage 5V±0.2v Working voltage 5V±0.2v Working current Working current 120mA土15mA 180mA士10mA Storage temperature Storage temperature -20°C~+80° C ~20° C~70° C Working temperature Working temperature ~20° C~70° C 20° C~+70° C Output signal Connector M12*0.5 AHD (YUV / YcbCr / RGB) Resolution Resolution 1080P@27.5fps...
  • Page 20 Manually power off: Long press the power button for 3 seconds, dash cam will turn off.(dash cam will turn off) Set the Date and Time 1. Set the Date and Time Manually. - Tap > General Settings>Clock Settings. > - Tap to adjust the value of the selected field.
  • Page 21 2. Emergency Recording ● Automatic Emergency Recording. When recording is in progress, if a collision occurs and the G-sensor is activated, current recording will be locked automatically to avoid being overwritten by loop recording, ● Manual Emergency Recording then the current recording will be locked as emergency recording and cannot be overwritten by loop recording. Note: ●...
  • Page 22 You can turn the grid lines on or off by tapping > Movie Mode> Reverse Line Switch. 2. Grid Lines Show up Manually The screen will show the rear camera image with grid lines when your finger slides to the right on the screen before shifting into reverse. Sliding to the right on the screen again will end the reversing mode.
  • Page 23: System Set Up

    Driving mode In this mode, you can view the current speed. >Movie Mode>Driving Mode>On/Off. The driving mode will automatically appear on the display within 30 seconds after the dash cam starts. You can also press and hold the screen for 2 seconds to enter the driving mode. Playback Mode 1.
  • Page 24 Mute: Mute or unmute the current recording. ⑨ ⑧ Switch views: Switch the display view (front or rear/ front & rear). 12:28 Playback: Playback videos and photos. Start/pause: Start or pause recording manually. 07/10/2023 Mon. Shutter: Take photos. Emergency recording: Start/Stop emergency recording manually.
  • Page 25 Friendly Remind: When the mirror is recording, you need to press the screen and hold for 2 seconds to enter Driving Mode first, then press the screen and hold for 2 seconds again to turn off the screen. 2. Enter the Screen Saver Automatically Tap menu Settings>...
  • Page 26 Driving Mode View the current speed and direction On / Off (default) Parking Monitoring View current speed On / Off (default) General Settings Beep Turn on or off the keytone Off / High / Middle / Low Language Set the on-screen display menu language Spanish, German, Italian, Japanese, English (default) Set the desired duration for backlight, always "Off"...
  • Page 27: Playback Software

    Reset Setup Restore all settings to the factory default values Yes / No Format SD-Card Format a memory card (All data will be erased Yes / No FW Version Firmware Version ------ layback Software Use the AUTO-VOX GPS Player on your Windows/Mac to view recorded videos. Installing the Playback Software For Windows users, you can find a download link for the playback software "AUTO-VOX GPS Player"...
  • Page 28 roubleshooting 1. Time keeps resetting Please make sure the yellow wire (B+) connects to the constant power. Please refer to the connection of the yellow wire (B+) and detection method on the Power Cable Connection as described above. 2. Video recording/photography unavailable ●...
  • Page 29 5. Cannot turn on / off automatically Reset or restore the default settings arranty You (as the end user) receive a 12-month guarantee from the date of purchase. For products replaced within the one-year warranty period, the warranty period is the remaining warranty period of the original order. During the one-year warranty period, if there is a problem with the product quality within 30 days from the date of purchase, our company will provide a returns and refund service;...
  • Page 30 For speedy processing of your warranty claim you will need: 1. Copy of the receipt showing the purchase date. 2. Reason for the claim(description of defect). Note: Your product is covered with a 12-month warranty period. To thank you for your continued support, we will be very happy to extend our warranty up to 18 months if you contact us by the following means.
  • Page 32 www.auto-vox.com Email: service@auto-vox.com...
