Auto Vox T1000 User Manual

General Introduction

This rear view mirror monitor is designed for car rear view purpose. which
can work with a reversing camera (NTSC or PAL) to show the images behind
your car, with good compatibility with multimedia parking sensor system beside
the camera. With dual video input, it can be connected to a car DVD player, too.
When reversing gear is engaged the rear view system automatically starts to
work and when the monitor is powered off, the mirror functions just like a normal
rear view mirror with anti-glare function. Both OEM Replacement Style & Clip-on
Style are available for selection, with Bluetooth function optional,

Bluetooth Function

Connection:

Turn on the mirror monitor, activate the bluetooth function of your mobile phone,
then search the pairing device and find Car Kit. Select Car Kit, and enter pairing
code 1234 before pairing. After 2-3 seconds, pairing and connection is done, when
you can find CONNECTED in the center of the screen as well a bluetooth mark on
the left upper corner.
Caller ID Display, answering & ending:
After connection, when the connected mobile phone has an incoming call, the
signal goes automatically to the mirror monitor, and caller's number is displayed
on the screen, with the mobile phone ring coming out from the speaker of mirror.
Press AV1/AV2 button once to answer the phone, and again to end the conversation.
Disconnection & Reconnection:
Both the mirror monitor and mobile phone must be ON and connected.
Turn the bluetooth of mobile phone off for disconnection, and to reconnect it, just
repeat the operations according to Connection instruction above.
When the mobile phone and mirror monitor are 10 meters far away from each other
(or less than 10m when there is an obstacle between them), the Bluetooth will be
automatically disconnected, and when you bring them nearer and restart the mirror
monitor, they can get reconnected.
Turn off the mirror monitor, the Bluetooth gets disconnected, and you can simply
turn on the mirror monitor to get reconnection.

Volume Adjustment:

The mirror monitor comes out of factory with a moderate volume, but users can still
adjust it by pressing button to add or
4.3" Car Rear View Mirror Monitor
to decrease the volume.
4.3" Car Rear View Mirror Monitor
OEM REPLACEMENT STYLE
UNIVERSAL CLIP-ON STYLE
BLUETOOTH FUNCTION
Please read this manual carefully before operation.
