SOFA
Assembly Instruction
SKU:1063030003B/1063030004B
Any question please feel free to contact us:
support@merluxyhome.com TEL:
We will provide further assistance within 24 hours.
Dear customers,
Thank you for purchasing our product.Please read this instruction manual carefully after
receiving this product.It will help you assemble this product quickly, safely,and correctly.You
can keep this manual for future reference.
901-347-2181
Advertisement
Related Manuals for Merluxy 1063030003B
Summary of Contents for Merluxy 1063030003B
- Page 1 SOFA Assembly Instruction SKU:1063030003B/1063030004B Any question please feel free to contact us: support@merluxyhome.com TEL: 901-347-2181 We will provide further assistance within 24 hours. Dear customers, Thank you for purchasing our product.Please read this instruction manual carefully after receiving this product.It will help you assemble this product quickly, safely,and correctly.You...
- Page 2 Safety and care advice Important-Please read these instructions fully before starting assembly Thanks for your purchase. Before the assembly please follow the instructions to check if all the spare parts and screws are intact. Considering the size and weight of the sofa,we Please do not throw away any of the packaging or the recommend two adults to assemble the sofa,on a instruction until you have checked all the components...
- Page 3 Assembly Instruction of Sofa Hardware parts M8*16 M8*50 Allen Key Washer Bolts J(L) I(L) Allen Key J(R) A(L) I(R) Structural accessories Sofa Leg Middle Leg A(R) Main structure accessories B 1pc C 1pc A(L) A(R) Armrest(L) Armrest(R) Front Bezel Rear Bezel D 1pc E 1pc F 1pc...
- Page 4 Assembly Instruction of Sofa Step 1 Step 1 Step 2 Screw hole Mortise Screw hole Tenon A(R) A(L) Side view of the legs after installation. Step 2 Step 3 Step 1 Step 2 Step 1 Step 2 Hanging on screws. Hanging on screws.
- Page 5 Assembly Instruction of Sofa Step 4 Step 5 A(L) A(R) Step 6 Step 7 Step 1 Step 2 Move the fabric on the velcro for Hanging on screws. fixing A(L) A(L) A(R) A(R) to tighten the screws after installation.
- Page 6 Assembly Instruction of Sofa Step 8 Step 9 Move the fabric on the velcro for fixing A(R) A(R) A(L) A(L) Step 10 Step 11 Take out the Seat Foam(G). I(L) Open the sealed bag. I(R) Insert the Seat Foam(G) into the Seat Pad Cover(H). A(L) A(R) Please keep the white...
- Page 7 Assembly Instruction of Sofa Step 12 Step 13 J(L) J(R) I(L) I(L) A(R) A(R)
- Page 8 Assembly Instruction of Combination...
