Summary of Contents for EVOS Fleet Home22
- Page 1 Fleet Home22 - Operation Manual Australia Page 1/1 EVOS Fleet Home22 Operation Manual - Australia...
-
Page 2: Table Of Contents
Fleet Home22 - Operation Manual Australia Page 2/16 Contents CHARGING STATION SAFETY GETTING STARTED COMPONENT GUIDE CHARGING CABLE INFORMATION EVOS APP CHARGING A VEHICLE MAINTENANCE PRODUCT SPECIFICATION VERSION CONTROL INFORMATION... -
Page 3: Charging Station Safety
Fleet Home22 - Operation Manual Australia Page 3/16 Charging Station Safety The EVOS Fleet Home22 is designed to only be connected to a dedicated AC supply. The EVOS Fleet Home22 requires only Type A RCD + MCB upstream protection. The use of adapters or conversion adapters are not permitted with EVOS Fleet Home22. -
Page 4: Component Guide
Fleet Home22 - Operation Manual Australia Page 4/16 Component Guide Charging Cable with Phoenix Charging Cable with Phoenix Contact Type 1 Plug Contact Type 2 Plug... -
Page 5: Charging Cable Information
Fleet Home22 - Operation Manual Australia Page 5/16 Charging Cable Information Safety Do not use the charging cable with an extension cable or an adapter. Never use force to remove the plug from the vehicle. Dangerous electric arcs could result in serious injury or death. -
Page 6: Evos App
Fleet Home22 - Operation Manual Australia Page 6/16 EVOS App A login is required to access the EVOS App. Station connectivity to the internet is required for EVOS App control. Scan Scan the QR code with your phone or tablet to open the EVOS App. - Page 7 Fleet Home22 - Operation Manual Australia Page 7/16 Each Card represents an overview of the station. Clicking a station card will load the station screen. Station Screen Action Start Charge – start charging session Stop Charge – pause active charging session...
- Page 8 Enter the price per litre in cents. Saves as you type Dark Mode Enable / Disable darker colour pallet. Saves on toggle Logout Session token will be revoked for all active EVOS App instances. Page will redirect to the http://evos.app after 15 seconds.
- Page 9 Fleet Home22 - Operation Manual Australia Page 9/16 Tariff Panel Displays l cost of the last session l cost per kWh (Fixed Tariff) l total cost of the last 30 days Usage Information Panel Uses the values set in App Settings Panel to calculate energy and fuel costs.
- Page 10 Fleet Home22 - Operation Manual Australia Page 10/16 Station Settings Control the station mode and view information Mode l Open – Plug and charge l Auth – Plug, authorise, charge l Maintenance – Disabled Mode changes may not apply during an active charging session.
- Page 11 Fleet Home22 - Operation Manual Australia Page 11/16 Time Schedule When the Time schedule icon is clicked from the station screen, the “Your Charging Schedule” window will open. Click “Set New Schedule” to create a new charging schedule. Use the Arrow Icon to move the 12 hour window...
-
Page 12: Charging A Vehicle
Fleet Home22 - Operation Manual Australia Page 12/16 Charging a vehicle 1. Check EVOS Fleet Home22 status LED is White. 2. Follow vehicle preparation instructions for starting a charging session (unlock inlet / open door / remove inlet cover). 3. Remove the plug from the holster or remove the protective cap. - Page 13 Fleet Home22 - Operation Manual Australia Page 13/16 LED Status Colours The LEDs of the EVOS Fleet Home22 convey the state of the station as listed below. Constant LED Pulsing LED White White Fast Pulse Ready Authentication requested (RFID model only)
-
Page 14: Maintenance
Swap base unit Please see procedure “EVOS Fleet Home22 – Replace Base Procedure” Swap charging cable Please see procedure “EVOS Fleet Home22 – Replace Charging Cable Procedure” Swap shield Please see procedure “EVOS Fleet Home22 – Replace Shield Procedure”... -
Page 15: Product Specification
Fleet Home22 - Operation Manual Australia Page 15/16 Product Specification Communication Charging Mode Protocol OCPP 1.6 Wired Ethernet 10/100Mbit Wi-Fi: 2.4GHz IEEE 802.11.b/g/n Wireless Bluetooth: 4.1 Optional: LTE CAT-M1 Compliance Certification CE Certified Protection Class IEC 61851-1, IEC 61851-21-2 Standards... -
Page 16: Version Control Information
Fleet Home22 - Operation Manual Australia Page 16/16 Version Control Information Item Version Date Contributors Initial document creation 17/11/2022 Leslie Smith...
