- Page 1 User Guide EVGA X99 Classified Specs and Initial Installation (Part 1) - 1 -...
-
Page 2: Table Of Contents
Table of Contents Before you Begin………………………………………………………………………3 Parts Not in the kit…………………………………………………………………….4 Intentions of the kit……………………………………………………………………4 Motherboard Specifications……………………………………………………………5 Unpacking and Parts Descriptions……………………………………………………..7 Equipment……………………………………………………………………………..7 Hardware Installation…………………………………………………………………..8 Component legend………..……………………………………………………………8 PCI-E Slot Breakdown………………………………………………………………..9 Rear I/O Panel legend………………………………………………………………..10 Preparing the Motherboard…………………………………………………………...11 Installing the CPU…………………………………………………………………….11 Installing the Cooling Device……………………………………….…………...…….12 Installing System Memory (DIMMs)……………...…………………..…..………...13 Compliance Information……………………………………………………………...14 - 2 -... -
Page 3: Before You Begin
Before You Begin… EVGA welcomes you to the next generation of ground breaking performance, the X99 Classified. The X99 platform redefines high performance with the introduction of the first ever quad channel DDR4 architecture fueled by Intel’s Haswell-E/Broadwell-E CPU family for up to 128GB’s of RAM running at a maximum memory speed up to 3000MHz+ (OC), possible due to the 4 layer memory T-Routing design. -
Page 4: Parts Not In The Kit
Hard Drive or SSD Keyboard / Mouse Monitor (Optional) Optical Drive EVGA assumes you have purchased all the necessary parts needed to allow for proper system functionality. For a full list of supported CPUs on this motherboard, please visit www.evga.com/support/motherboard... -
Page 5: Motherboard Specifications
Motherboard Motherboard Specifications Size: EATX form factor of 12 inches x 10.375 inches (305x264mm) Microprocessor support: Intel Socket 2011-3 Processor Operating Systems: Supports Windows 8 / 7 Contains Intel X99 chipset System Memory support: Supports Quad channel DDR4 up to 3000MHz+ (OC). Supports up to 128GB of DDR4 memory. - Page 6 Ethernet Teaming Supported Onboard Audio: Creative Core3D Quad-Core Audio Processor (CA0132) Supports 6-channel (5.1) audio Supports Optical Output PCI-E 3.0 Support: Low power consumption and power management features Power Functions: Supports ACPI (Advanced Configuration and Power Interface) Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4 (Suspend to disk - depends on OS), and S5 (soft - off) Expansion Slots: 5x PCI-E 16x slot 2x16/8, 3x8, 4x8...
-
Page 7: Unpacking And Parts Descriptions
Unpacking and Parts Descriptions Equipment The following accessories are included with the EVGA X99 Classified Motherboard: The EVGA X99 Classified Motherboard This PCI-E motherboard contains the Intel X99 chipset. I/O Shield Installs in the system case to protect internal components from dust, foreign objects, and aids in proper airflow within the chassis. - Page 8 Intel X99 Classified Motherboard The EVGA X99 Classified Motherboard with the Intel X99 and PCH Chipset. Figure 1 shows the motherboard and Figure 2 shows the back panel connectors FIGURE 1. X99 Classified Motherboard Layout - 8 -...
-
Page 9: Pci-E Slot Breakdown
1. CPU Socket 2011-3 13. USB 3.0 Headers 25. EVGauge 2. Intel X99 Southbridge 14. USB 2.0 Headers 26. Thunderbolt GPIO Connector 3. CPU Fan Header (1 amp PWM) 15. CMOS Reset Button 27. MCU Firmware update connector 4. DDR4 Memory DIMM Slots 1-8 16. - Page 10 Figure 2. Chassis Rear Panel Connectors 1. USB 2.0 4. Intel i217 NIC 7. Analog Audio Output Jacks 2. USB 3.0 5. Intel i210 NIC 3. BIOS/CMOS Reset 6. Optical Out Analog Audio Port Breakdown 2/2.1 (Channel) 4.0/4.1 (Channel) 5.1 (6 Channel) Dark Green Head Phone Head Phone...
-
Page 11: Preparing The Motherboard
Preparing the Motherboard Installing the CPU Be very careful when handling the CPU. Hold the processor only by the edges and do not touch the bottom of the processor. Note: Use extreme caution when working with the CPU, not to damage any pins in the CPU socket on the motherboard! Use the following procedure to install the CPU onto the motherboard: Unhook the left socket lever by pushing down and... -
Page 12: Installing The Cooling Device
Align the notches on the CPU to the notches in the socket. Lower the processor straight down into the socket. Note: Make sure the CPU is fully seated and level in the socket. Lower the load plate so it is resting on the CPU. Press the right socket lever down to lock into place. -
Page 13: Installing System Memory (Dimms)
Installing System Memory (DIMMs) Your X99 Classified has (8) 288-pin slots for DDR4 memory. These slots support 2GB, 4GB, 8GB and 16GB DDR4 DIMMs. There must be at least one memory slot populated to ensure normal operation. The Intel X99 chipset supports quad channel memory;... -
Page 14: Compliance Information
Original Purchaser. Upon termination, for any reason, all copies of Software and materials must be immediately returned to EVGA and the Original Purchaser shall be liable to EVGA.com CORP for any and all damages suffered as a result of the violation or default. - Page 15 User Guide EVGA X99 Motherboard Installation (Part 2) - 1 -...
- Page 16 Clear CMOS Button…………………………………………………………11 RESET and POWER Button………………………………………………...11 Post Debug LED and LED Status Indicators………………………………..12 Post Port Debug LED……………………………………………………….12 LED Status Indicators……………………………………………………….12 Installing Drivers and Software……………………………………………...13 Windows 8/7 Driver Installation…………………………………………….13 POST Codes…………………………………………………………………14 EVGA Glossary of Terms…………………………………………………...18 Compliance Information …………………………………………………….21 - 2 -...
-
Page 17: Installing The Motherboard
Installing the Motherboard The sequence of installing the motherboard into a system case depends on the chassis you are using and if you are replacing an existing motherboard or working with an empty system case. Determine if it would be easier to make all the connections prior to this step or to secure the motherboard and then make all the connections. -
Page 18: Securing The Motherboard Into A System Case
Securing the Motherboard into a System Case Most system cases have a base with mounting holes you thread standoffs onto to allow the motherboard to be secured to the chassis and help to prevent short circuits. If there are studs that do not align with a mounting hole on the motherboard, it is recommended that you remove that standoff to prevent the possibility of a short circuit. - Page 19 Above, all locations safe to secure the board to a standoff with are circled in red, and the upper left side of that picture is a zoomed in view of the hole. Keep in mind that when the screws are installed but not fully tightened, ...
-
Page 20: Connecting Cables
Connecting Cables This section takes you through all the necessary connections on the motherboard. This will include: Power Connections 24pin ATX power ( EPS 8pin 12V power Internal Headers Front Panel connectors (power/reset/LED’s) Fan Headers (PWM for CPU and DC for case fans ) USB 2.0 Header USB 3.0 Header Audio Header... - Page 21 Connector Signal Signal +3.3V +3.3V +3.3V -12V PS_ON PWROK RSVD +5V_AUX +12V +12V +3.3V EPS 8-pin 12V Power (PWR , the 8-pin ATX 12V power connections, is used to provide EPS PWR 8P1 power to the CPU. Align the pins to the connector and press firmly until seated. The secondary is optional for improved overclocking.
-
Page 22: Connecting Internal Headers
Connecting Internal Headers Front Panel Header The front panel header on this motherboard is used to connect the following four cables. PWRLED Attach the front panel power LED cable to these two pins of the connector. The Power LED indicates the system’s status. When the system is powered on, the LED will be on. -
Page 23: Usb Headers
USB Headers Connector Signal This motherboard contains 5V_DUAL USB 3.0 and 2.0 ports that are USB 2.0 Header Connector exposed on the rear panel of the chassis. The motherboard also contains 10-pin internal header connectors onboard Empty that can be used to connect an Signal optional external bracket 5V_DUAL... -
Page 24: Audio
Audio The audio connector supports HD audio standard and provides two kinds of audio output choices: the Front Audio and the Rear Audio. Connector Signal PORT1_L Front Audio Connector AUD_GND PORT1_R PRECENCE_J PORT2_R SENSE1_RETURN SENSE_SEND Empty PORT2_L SENSE2_RETURN PCI-E x16/x8 Slot This board has a single PCI-E 16x slot. -
Page 25: Onboard Buttons
Onboard Buttons These onboard buttons include RESET, POWER and Clear CMOS. These functions allow you to easily reset the system, turn on/off the system, or clear the CMOS. Clear CMOS Button The motherboard uses the CMOS RAM to store all the set parameters. The CMOS can be cleared by pressing the Clear CMOS button either onboard or on the external I/O Panel. -
Page 26: Post Debug Led And Led Status Indicators
Post Debug LED and LED Status Indicators Post Port Debug LED Provides two-digit diagnostic POST codes which shows system boot status and can also show why the system may be failing to boot. It is very useful during troubleshooting situations. This Debug LED will display a series of hexadecimal (0-F) codes during the POST and upon a successful boot, will display current CPU socket temperatures after the system has fully booted into the Operating System. -
Page 27: Installing Drivers And Software
32bit and 64bit versions of Windows 8 or 7. The kit comes with a CD that contains utilities, drivers, and additional software. The CD that has been shipped with the EVGA X99 Motherboard contains the following software and drivers: Chipset Drivers ... -
Page 28: Post Codes
POST Codes This section provides the AMI POST Codes for the EVGA X99 Dark Motherboard during system boot The POST Codes are displayed on the Debug LED readout located directly onboard the motherboard. Debug LED with CPU Temperature Monitor This Debug LED will also display current CPU temperatures after the system has fully booted into the Operating System. - Page 29 information Memory initialization. Configuring memory Memory initialization (other). Reserved for ASL (see ASL Status Codes section below) Memory Installed CPU post-memory initialization is started CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) (AP) initialization CPU post-memory initialization. Boot Strap Processor (BSP) selection CPU post-memory initialization.
- Page 30 Recovery firmware image is found Recovery firmware image is loaded F5-F7 Reserved for future AMI progress codes Recovery PPI is not available Recovery capsule is not found Invalid recovery capsule FB–FF Reserved for future AMI error codes DXE Core is started NVRAM initialization Installation of the South Bridge Runtime Services 63-67...
- Page 31 SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below) Ready To Boot event Legacy Boot event Exit Boot Services event CPU Memory controller configuration Runtime Set Virtual Address MAP End...
-
Page 32: Evga Glossary Of Terms
DIMM - Dual In-line Memory Module DMI – Direct Memory Interface DRAM - Dynamic random access memory DVI – Digital Video Interface ELEET/ELEET X – EVGA motherboard monitoring and tuning software GHz – Gigahertz GPU – Graphics Processing Unit HDD - Hard Disk Drive HDMI - High-Definition Multimedia Interface HDR –... - Page 33 IRQ - Interrupt Request JBOD - Just a Bunch of Disks JEDEC - Joint Electron Device Engineering Council LAN - Local Area Network LCD - Liquid Crystal Display LGA – Land Grid Array LN2 – Liquid Nitrogen Cooling MAC - Media Access Control MCP - Media and Communications Processor Intel ME –...
- Page 34 SATA - Serial Advanced Technology Attachment SAS – Serial Attached SCSI SB - Southbridge SCSI - Small Computer System Interface SFR – Split Frame Rendering SLI - Scalable Link Interface SPD - Serial Presence Detect S/PDIF - Sony/Philips Digital Interconnect Format SPP - System Platform Processors SSD –...
-
Page 35: Compliance Information
Original Purchaser. Upon termination, for any reason, all copies of Software and materials must be immediately returned to EVGA and the Original Purchaser shall be liable to EVGA.com CORP for any and all damages suffered as a result of the violation or default.
