  • Page 1 User Manual KEEP THIS MANUAL FOR FUTURE NEEDS...

  • Page 2: Table Of Contents

    CONTENTS 1. SAFETY INSTRUCTIONS 2. FEATURES 3. FIXTURE OVERVIEW 4. DIMENSIONAL DRAWINGS 5. INSTALLATION INSTRUCTIONS 6. DMX-512 CONTROL CONNECTION 7. DMX-512 CONNECTION WITH DMX TERMINATOR 8. DEVICE DMX START ADDRESS SELECTION 9. OPERTING INSTRUCTIONS OF THE INTERNAL DMX WIRELESS SYSTEM 10.

  • Page 3: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. IMPORTANT SAFETY WARNING This device has left the factory in perfect condition.In order to maintain this condition and to ensure safe operation，it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. In order to install，operate，and maintain the lighting fixture safely and correctly we suggest that the installation and operation be carried out by qualified technicians and these instructions be carefully followed.
  • Page 4 Important: Damage caused by the disregard of this user manual is not subject to warranty.The dealer and manufacturer will not accept liability for any resulting defects or problems. • If the device has been exposed to temperature changes due to environmental conditions， do not power on immediately.The resulting condensation could damage the device.Leave the device powered off until it has reached room temperature.

  • Page 5: Features

    • Please use the original packaging if the device is to be transported. • The applicable temperature for the device is between -20°C to 45°C.Do not use the device outside of this temperature range. • The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
  • Page 6 • Stepless frost：0%~100% linear change frost • Stepless iris：5%~100% linear change iris，pulse iris effect • Dimmer：0%~100% full range dimming DISPLAY • Advanced and convenient full –color LCD • Locked automatically after standby for 15 seconds to prevent error；hold the button for 10 seconds to activate •...

  • Page 7: Fixture Overview

    3. FIXTURE OVERVIEW 1) Lens 2) Tilt Lock 3) Display 4) Up-button 5) Left-button 6) Center-button 7) Down-button 8) Right-button 9) Pan Lock 10) Handle 11) Power In 12) RJ45 In 13) RJ45 Out 14) DMX In 15) DMX Out...

  • Page 8: Dimensional Drawings

    4. DIMENSIONAL DRAWINGS 4.1. Fixture Dimension...
  • Page 9 4.2. Color Filter Dimension 1. CTB1/4 (6.03.05.03.2864) 2. Congo Blue (6.03.05.03.2855) 3. Green (6.03.05.03.2856) 4. Orange (6.03.05.03.2857) 5. Blue (6.03.05.03.2858) 6. Red (6.03.05.03.2859)
  • Page 10 4.3. Gobo Filter Dimension Rotating Gobo 1 ： 1. 314 – Dot Line 4 (6.03.03.05.1968) 2. 322 – Dot Ring 8 (6.03.03.05.1969) 3. 326 – Dot Triangle 3 (6.03.03.05.2026) 4. 332 – Square Beam 4 (6.03.03.05.1967) 5. 310 – Eccentric Dot (6.03.03.05.1970) 6.
  • Page 11 Rotating Gobo 2 ： 1. 074 – Star Dust (6.03.03.01.1172-A) 2. 077 - Water (6.03.03.01.1575-0) 3. 275 – Prison Bars (6.03.03.01.1576-0) 4. 049 – Smoke Rings (6.03.03.01.1177-A) 5. 101 – Deep Forest (6.03.03.01.1182-0) 6. 105 – Tree Bark (6.03.03.01.1183-A) 7. 112Y – Nested Ring Yellow (6.03.03.06.0124)
  • Page 12 4.4. Animation Dimension...

  • Page 13: Installation Instructions

    5. INSTALLATION INSTRUCTIONS 5.1. Rigging the device CAUTION! PLEASE CONSIDER THE RESPECTIVE NATIONAL NORMS DURING INSTALLATION. THE INSTALLATION MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON. • The applicable temperature for the lighting is between -20°C to 45°C. Do not use the lighting under or above the temperature range.
  • Page 14 5.2. Rigging using the omega brackets • Fix the clamp to the bracket by tightening the M12 nut and bolt to the bracket through the Ф13 hole in the middle of the bracket. • Insert the quick-lock fasteners of the first Omega holder into the respective holes on the bottom of the device.Tighten the quick-lock fasteners fully clockwise.
  • Page 15 5.3. RIGGING DRAWINGS • Be sure this fixture is kept at least 0.2 m away from any flammable materials (decoration etc.). • Always use and install a safety cable as a safety measure to prevent accidental damage and/or injury in the event the clamp fails. Important ：...

  • Page 16: Dmx-512 Control Connection

    6. DMX-512 CONTROL CONNECTION Connect the provided male side of the XLR cable to the female XLR output of your controller and the female side of the XLR cable to the male XLR input of the device.You can connect multiple devices together in a serial fashion.The cable needed should be two core， screened cable with XLR input and output connectors.Please refer to the diagram below.

  • Page 17: Device Dmx Start Address Selection

    8. DEVICE DMX START ADDRESS SELECTION All fixtures should be given a DMX starting address when using a DMX signal，so that the correct fixture responds to the correct control signals.This digital starting address is the channel number from which the fixture starts to “ listen” to the digital control information sent out from the DMX controller.The allocation of this starting address is achieved by setting the correct address number on the display located on the base of the device.
  • Page 18 2) When the fixture is power off, and the WDMX is in ON status，if the fixture is connected to DMX controller.After the fixture is power on，it can be controlled only by the DMX controller which connected.The fixture can log in the wireless transmitter，and receive only radio signal from transmitter，but not DMX from the transmitter.

  • Page 19: Display

    10. DISPLAY The Display offers several features：you can set the starting address，run the pre-programmed program or reset the device. The main menu is accessed by double clicking -button until the display starts flashing.Browse through the menu by pressing the -button， -button，...
  • Page 20 Hibernation OFF , 01M~99M Stand by Mode DMX Output ON/OFF DMX Output Service Password”=050” Service PIN Password=XXX Set Ip Set Ip xxx.xxx.xxx.xxx Set Mask Ip Set Mask Ip xxx.xxx.xxx.xxx Service PIN DHCP DHCP ON/OFF Cross Load SW Cross Load SW ON/OFF Clr LED Time Clr LED Time...
  • Page 21 Current Time XXXX(Hours) Ttl Life Hrs XXXX(Hours) Last Run Hrs XXXX(Hours) Time Info. LED Hours XXXX(Hours) Timer PIN Password=XXX Clr Last Run ON/OFF Temp. Info Head Temp. XXX℃/℉ Humidity Humidity Fan Info. xxxxRPM Fan information Software Ver V1.0…… Software version Network IP,Mask,Mac Network...
  • Page 22 10.1. Address 10.1.1. Set DMX Address With this function，you can adjust the desired DMX-address via the Display. 1. Double clicking center button to access main menu. 2. Tap the <Up/Down> button until“Address”is displayed. 3. Double clicking center button，the display will show“Set DMX Address”. 4.
  • Page 23 “Hold” ，Tap the <Up/Down> button to select“Close” ， “Auto”. 6. Double click the center button to confirm or long press the center button to return to the main menu. Sun Protection 1. Double clicking center button to access main menu. 2.
  • Page 24 “Status”. 4. Double clicking center button to access“Status”menu，Tap the <Up/Down> button to select“Pan Degree”. 5. Double clicking center button to access “ Pan Degree” ， The display will show “540” ， Tap the <Up/Down> button to select“630”. 6. Double click the center button to confirm or long press the center button to return to the main menu.
  • Page 25 Reset Mode 1. Double clicking center button to access main menu. 2. Tap the <Up/Down> button until“Options”is displayed. 3. Double clicking center button to access “ Options” ， Tap the <Up/Down> button to select “Status”. 4. Double clicking center button to access“Status”menu，Tap the <Up/Down> button to select“Reset Mode”.
  • Page 26 5. Double clicking center button to access“Zoom/Focus Spd” ，The display will show “Fast” ，Tap the <Up/Down> button to select“Fast” ， “Medium” ， “Slow”. 6. Double click the center button to confirm or long press the center button to return to the main menu.
  • Page 27 main menu. Set Mask IP 1. Double clicking center button to access main menu. 2. Tap the <Up/Down> button until“Options”is displayed. 3. Double clicking center button to access “ Options” ， Tap the <Up/Down> button to select “Service PIN”. 4. Double clicking center button to access“Service PIN”menu，Tap the <Up/Down> button to select“Set Mask IP”.
  • Page 28 6. Double click the center button to confirm or long press the center button to return to the main menu. 10.3.3. Fans Control Fans Speed With this function you can set the speed of the running fans.The selections have Auto、 Stage and Studio.
  • Page 29 1．Double clicking center button to access main menu. 2．Tap the <Up/Down> button until“Options”is displayed. 3．Double clicking center button to access “ Options” ， Tap the <Up/Down> button to select “Display Setting”. 4．Double clicking center button to access“Display Setting”menu，Tap the <Up/Down> button to select“Flip Display”.
  • Page 30 4．Double clicking center button to access “ Signal Select” ， The display will show “DMX” ， Tap the <Up/Down> button to select“DMX” ， “WDMX” ， “Art--Net” ， “sACN”. 5．Double click the center button to confirm or long press the center button to return to the main menu.
  • Page 31 5. Double click the center button to confirm or long press the center button to return to the main menu. 10.3.10. Refresh Select With this function you can select the refresh. 1. Double clicking center button to access main menu. 2.
  • Page 32 With this function you can display the DMX 512 value of each channel.The display automatically shows the channel with a value changing. 1．Double clicking center button to access main menu. 2．Tap the <Up/Down> button until“Options”is displayed. 3．Double clicking center button to access “ Options” ， Tap the <Up/Down> button to select “Trigger”.
  • Page 33 “Reset Default”. 4．Double clicking center button to access“Reset Default”menu，The display will show “OFF” ，Tap the <Up/Down> button to select“ON”. 5．Double click the center button to confirm or long press the center button to return to the main menu. 10.4. Info 10.4.1.
  • Page 34 5. Double clicking center button to access “Last Run Hrs” ， The display will show “XXXX (Hours)”. 6. Double click the center button to confirm or long press the center button to return to the main menu. LED Hours With this function， you can display the time of LED.The display shows “XXXX” ， “ XXXX” stands for the time of LED.
  • Page 35 With this function you can display the temperature on the display board of the base (near CMY-filter) in Celsius. 1. Double clicking center button to access main menu. 2. Tap the <Up/Down> button until“Info”is displayed. 3. Double clicking center button to access“Info” ，Tap the <Up/Down> button to select “Temp Info”.
  • Page 36 4. Double clicking center button to access“Network” ，The display will show“IP” ， Turn the center button to select“Mask” ， “Mac”. 5. Double click the center button to confirm or long press the center button to return to the main menu. 10.5.
  • Page 37 2．Tap the <Up/Down> button until“Test”is displayed. 3．Double clicking center button to access“Test” ，Tap the <Up/Down> button to select “Calibration”. 4．Double clicking center button to access “ Calibration ” ， The display will show “Password=050”. 5．Double click the center button to confirm or long press the center button to return to the main menu.
  • Page 38 Part 2，Part 3 repeat in accordance with the Part1’s repeat.For example：When Part 1 uses Program 2，Part 2 uses Program 4，Part 3 uses Program 6，Assume：Program 2 includes scene of 10，11，12，13；Program 4 includes scene of 8，9，10；Program 6 includes scene of 12，13，14，15；Then it will run as below. Example：...

  • Page 39: Dmx Protocol

    11. DMX PROTOCOL DMX channel´s functions and their values (70DMX channels): Mode/Channel Value Function PAN Movement 8bit : 0-255 Pan Movement Pan Fine 16bit 0-255 Fine control of Pan movement TILT Movement 8bit : 0-255 Tilt Movement Tilt Fine 16bit 0-255 Fine control of Tilt movement Speed Pan/Tilt movement:...
  • Page 40 201-255 AutoFocus Fine: 0-255 Continuous adjustment Fine Color Wheel: Open / white Color 1 8-11 Color 2 12-15 Color 3 16-19 Color 4 20-23 Color 5 24-27 Color 6 28-127 Color indexing 128-189 Forwards rainbow effect from fast to slow 190-193 No rotation 194-255...
  • Page 41 Reserved Reserved Reserved Rotating gobos, cont. rotation 1: Open 10-19 Rot. gobo 1 20-29 Rot. gobo 2 30-39 Rot. gobo 3 40-49 Rot. gobo 4 50-59 Rot. gobo 5 60-69 Rot. gobo 6 70-77 Rot. Gobo 7 78-93 Gobo 1 shake slow to fast 94-109 Gobo 2 shake slow to fast 110-125...
  • Page 42 158-173 Gobo 6 shake slow to fast 174-189 Gobo 7 shake slow to fast 190-221 Gobo wheel rotation forwards from fast to slow 222-223 No rotation 224-255 Gobo wheel rotation f backwards from slow to fast Rotating gobo index,rotating gobo rotation 2: 0-127 Gobo indexing 128-189...
  • Page 43 Rotating prism index, rotating prism rotation 2 0-127 Prism indexing 128-189 Forwards prism rotation from fast to slow 190-193 No rotation 194-255 Backwards prism rotation from slow to fast Rotating prism indexing Fine 2: 0-255 Fine indexing Frost 1: 0-255 0-100% Frost 2: 0-255...
  • Page 44 All Blade Rotation : 0-255 All Blade Rotation All Blade Rotation Fine : 0-255 All Blade Rotation Fine Control, reset, internal programs: unused Display Off 10-14 Display On 15-19 Display Invert Off 20-24 Display Invert On 25-26 Auto fan control mode 27-28 Stage fan control mode 29-30...
  • Page 45 Mode/Channel Value Function Domino Mode PAN Movement 8bit : 0-255 Pan Movement Pan Fine 16bit 0-255 Fine control of Pan movement TILT Movement 8bit : 0-255 Tilt Movement Tilt Fine 16bit 0-255 Fine control of Tilt movement Speed Pan/Tilt movement: 0-225 max to min speed 226-235...
  • Page 46 AutoFocus Fine: 0-255 Continuous adjustment Fine Color Wheel: Open / white Color 1 8-11 Color 2 12-15 Color 3 16-19 Color 4 20-23 Color 5 24-27 Color 6 28-127 Color indexing 128-189 Forwards rainbow effect from fast to slow 190-193 No rotation 194-255 Backwards rainbow effect from slow to fast...
  • Page 47 20-29 Rot. gobo 2 30-39 Rot. gobo 3 40-49 Rot. gobo 4 50-59 Rot. gobo 5 60-69 Rot. gobo 6 70-77 Rot. Gobo 7 78-93 Gobo 1 shake slow to fast 94-109 Gobo 2 shake slow to fast 110-125 Gobo 3 shake slow to fast 126-141 Gobo 4 shake slow to fast 142-157...
  • Page 48 Rotating gobo index,rotating gobo rotation 2: 0-127 Gobo indexing 128-189 Forwards gobo rotation from fast to slow 190-193 No rotation 194-255 Backwards gobo rotation from slow to fast Rotating gobo indexing Fine 2: 0-255 Fine indexing Animation wheel 1: open 1-239 Animation indexing 240-255...
  • Page 49 128-189 Forwards prism rotation from fast to slow 190-193 No rotation 194-255 Backwards prism rotation from slow to fast Rotating prism indexing Fine 2: 0-255 Fine indexing Frost 1: 0-255 0-100% Frost 2: 0-255 0-100% Blade 1A : 0-255 Open to Close Blade 1A Fine : 0-255 Open to Close Fine...
  • Page 50 0-255 All Blade Rotation All Blade Rotation Fine : 0-255 All Blade Rotation Fine Control, reset, internal programs: unused Display Off 10-14 Display On 15-19 Display Invert Off 20-24 Display Invert On 25-26 Auto fan control mode 27-28 Stage fan control mode 29-30 Silence fan control mode 31-32...
  • Page 51 Appendix: name color name (=DMX value) EC003 LAVENDER TINT EC004 MEDIUM BASTARD AMBER EC007 PALE YELLOW EC008 DARK SALMON EC009 PALE AMBER GOLD EC010 MEDIUM YELLOW EC013 STRAW TINT EC015 DEEP STRAW EC017 SURPRISE PEACH EC020 MEDIUM AMBER EC021 GOLD AMBER EC022 DARK AMBER EC024...
  • Page 52 EC118 LIGHT BLUE EC119 DARK BLUE EC120 DEEP BLUE EC124 DARK GREEN EC126 MAUVE EC127 SMOKEY PINK EC128 BRIGHT PINK EC132 MEDIUM BLUE EC134 GOLDEN AMBER EC136 PALE LAVENDER EC137 SPECIAL LAVENDER EC138 PALE GREEN EC139 PRIMARY GREEN EC140 SUMMER BLUE EC141 BRIGHT BLUE EC142...

  • Page 53: Error Messages

    12. ERROR MESSAGES When you turn on the device, it will first perform a reset.The display may show“Err channel is XX”should there be problems with one or more functions.“XX” stands for channel 1，2，3， 4，5，6 etc whose sensor has encountered a problem.For example，when the display shows“Err channel is Pan movement”...
  • Page 54 Cyan Color wheel Er (Cyan Color wheel- error) This message will appear after the reset of the fixture if the head’s magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the stepper motor is defective (or its driving IC on the main PCB).The CMY - movement is not located in the default position after the reset.
  • Page 55 Iris wheel Er (Iris wheel - error) This message will appear after the reset of the fixture if the head’s magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the stepper motor is defective (or its driving IC on the main PCB).The Iris - movement is not located in the default position after the reset.
  • Page 56 (Blade 3_Rot wheel - error) This message will appear after the reset of the fixture if the head’s magnetic-indexing circuit malfunctions (sensor failed or magnet missing) or the stepper motor is defective (or its driving IC on the main PCB).The Blade 3_Rot - movement is not located in the default position after the reset.

  • Page 57: Cleaning And Maintenance

    13. CLEANING AND MAINTENANCE CAUTION! ALWAYS RUN AN IP TEST USING THE AYRTON IP TEST KIT FOLLOWING ANY MAINTENANCE OPERATION! FAILURE TO COMPLY WITH THIS CLAUSE WILL VOID THE WARRANTY ! The following points have to be considered during inspection：...
  • Page 58 Head covers opening and closing procedure...
  • Page 59 Please, follow the order (1-5) to cross tightening the HEX screws at the right torque value. Use a Torque Screwdriver set at 1,2Nm (10,6in/lbf) to fasten correctly the (10) HEX head screws for each cover Use the Ayrton IP TEST KIT to control the IP rating of the fixture.
