- Page 1 IM3063 12/2023 REV02 LACI Production Monitoring Module OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 4 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
-
Page 5: Installation And Operator Instructions
Installation and Operator Instructions General Description LACI with PC Connection The Lincoln ArcLink Communication Interface (LACI) According to network infrastructure we can distinguish 2 Module is designed to connect your Welding Power different connection types: Source to your computer or the network. a) Direct Connection b) Local Area Network Using Power Wave®... - Page 6 LACI default factory settings Static IP Addresses DHCP When LACI is connected to the network which is IP Address 192.168.0.2 equipped with a Hub or Switch (no DHCP server) it is Subnet Mask 255.255.255.0 required to set proper IP address from the actual Default gateway 192.168.0.1 subnetwork range to LACI and PC.
- Page 7 Dynamic IP Addresses (DHCP Server, e.g. Router) When LACI is connected to the network which is equipped with DHCP server it is required to set proper configuration of the LACI and PC. Router (DHCP on) LACI LACI settings DHCP Obtain an IP address automatically PC network settings DHCP Obtain an IP address automatically...
-
Page 8: Mounting Instruction
Mounting Instruction English English... - Page 9 We respond to our customers warranty. based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or Any noticeable damage should be reported immediately guarantee such advice, and assumes no liability, with and repaired.
-
Page 10: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 11: Suggested Accessories
Suggested Accessories K14124-1 Case of remote control (PENDANT). K14132-1 5-PIN/12-PIN adapter. K14131-1 ArcLink ® "T" Connector Kit. English English... -
Page 12: Connection Diagram
Connection Diagram English English...
