- Page 1 Installation guide Wall system Version 1.5 · English Series 3...
- Page 2 Studio SA. Copyright © 2021-2022 · iNUI Studio SA. BRANDS AIR TOUCH® and AIRxTOUCH® brands and logos are the exclusive property of iNUI Studio SA. All other trademarks and copyrights are the property of their respective owners. STAFF DURATION...
- Page 3 Be sure to consult the AIRxTOUCH® Customer Service center if you want to install the device in such a place.
- Page 4 IMPORTANT Mandatory: the bottom edge of the system must be 100 cm above the ground. Please refer to page 14 for more info. 80 cm Plug here · Power + Ethernet Wall 100 cm Floor Total weight = 72 Kg · Kiosk weight = 49 Kg...
- Page 5 CONTENT Keyboard Body · 55" Screen + Sensors Intermediate plate Intel NUC (PC) + Alim Wireless touch Keyboard + batteries PC Box Wall mount plate TV remote + batteries...
- Page 6 ASSEMBLY PART 1/3 PC BOX GENERAL INFORMATION › Several connectors are already installed inside the PC Box: - Internal AC power sockets (x2) for additional requirements - Electric hub - PC Box power supply (with on/off switch) - Ethernet ports (x2) + RJ45 cables - Display power cable - Additional cable Illustration: internal organization of the PC Box...
- Page 7 PREPARATION 1.1 Group the cables listed below together and bring them out of the PC Box, by the rear face of the box (see below: yellow arrow). The cables to be grouped are: - Display power cable - Additional cable (no need to plug this cable) Display power Additional cable...
- Page 8 SETTING UP THE NUC (PC) 2.1 Place the NUC support plate inside the PC Box – in the dedicated area – and fix it. Support plate and screws are provided. PC Box Take care of the orientation of the NUC support plate (illustration above).
- Page 9 2.2 Put the NUC right in place and insert it on its support plate 2.3 Connect the wireless keyboard USB dongle to the NUC, using one of the USB frontal ports. 2.4 Plug the HDMi-HDMi cable (provided) to the NUC HDMi port 1 then, ...
- Page 10 SETTING UP THE LED BAR 3.1 Connect the LED Bar 5v 6A power supply (with a blue led on it) to the internal power cable (pre-installed). WARNING: DO NOT INTERCHANGE THE 2 POWER SUPPLIES AS THIS CAN LEAD TO POWER SURGE / HARDWARE DAMAGE. 3.2 Pull the power cable out on the back of the PC Box.
- Page 11 CLOSING THE PC BOX 5.1 Place the top cover back on the PC Box. Holes on the left & right sides of the top cover has to be aligned with the ones of the PC Box. 5.2 Screw on both sides of the plate (screws are provided).
- Page 12 PC BOX SUPPORT WINGS 6.1 Fix the 2 support wings on each sides of the PC Box (2 screws for each side). NOTE: the wings has to exceed a bit from the front side of the PC Box, not on the back. 6.2 Remove the original parts from the kiosk that will be replaced by the PC Box support wings.
- Page 13 ASSEMBLY PART 2/3 INTERMEDIATE PLATE ADDING THE INTERMEDIATE PLATE TO THE KIOSK 8.1 Bring the intermediate plate to the back of the kiosk and insert it on the 4 rods coming from the back of the kiosk. WARNING: ensure not to pinch the cables. 8.2 Once the intermediate plate is in place, screw it with the 4 provided bolts.
- Page 14 ASSEMBLY PART 3/3 WALL MOUNT PLATE HANGING THE WALL MOUNT PLATE 9.1 Fix the Wall mount plate to the wall using the provided 4 screws 2 on top, 2 on the bottom. WARNING: pay attention to the 2 hanging screws that has to be up ...
- Page 15 ADDING THE KIOSK TO THE WALL MOUNT PLATE 10.1 Grab the kiosk (2 people are required here), lift it up and put it on the 2 hanging screws The kiosk is now perfectly held! 10.2 Final step: bring the electricity (from the wall, from the floor or from the ceiling) to your kiosk and plug it to the power socket of the PC Box.
-
Page 16: Driver Settings
DRIVER SETTINGS 11.1 Please right click on the Driver tray icon / Driver settings in order to configure your system. 11.2 When the Driver is correctly launched, the Driver tray icon is green. During the Driver initialization, the Driver tray icon is yellow. Driver is launched Driver is initializing PC ADMIN... - Page 17 I DO NOT RECEIVE ANY TOUCH POINT 1. Check if the Driver is running The Driver tray icon must been green, not yellow. Type here to search Launched Initializing AN OFFSET IS ALWAYS APPLIED TO THE TOUCHPOINT (X AND Y COORDINATES) 2 screen resolutions are supported: ›...
- Page 18 Type here to search If the shortcut is missing, you can find the executable (.exe) file in Program Files: C:\Program Files\AIRxTouch\AIRxTouch Kiosk\AIRxTouch Driver\iNUI.AIRxTouchDriver.exe THE TOUCH POINT (X,Y,Z) IS TOTALLY INCORRECT Double-check on the NUC Player that the AIR TOUCH® Sensors is correctly connected.
- Page 19 THE DRIVER IS CRASHING DURING THE LAUNCH (AND DISAPPEARS FROM THE TASKBAR) Double-check if the 3 AIR TOUCH® sensors are visible by Windows. Launch the Windows Camera application via the Windows Search bar. If the sensors are not visible: jump to Step 2. Apps Documents More...
- Page 20 MY SCREEN IS BLACK (AFTER A CERTAIN TIME OF INACTIVITY) PC CHECKUP › Several verifications: Go to the Windows Settings / Power & sleep and ensure to have the correct settings: › Screen | When plugged in, turn off after → “Never" ›...
- Page 21 ONE MORE THING ENERGY SAVING PROCEDURE You can set ON and OFF times easily. Here's how to do: Samsung Remote control → press HOME On the screen, go to the On/Off Timer section Now, you will set the On Timer and the Off Timer. 3.1 ·...
