- Page 1 Installation guide Kiosk 32 Version 1.0 English Kiosk 32...
- Page 2 Studio SA. Copyright © 2021-2023 · iNUI Studio SA. BRANDS AIR TOUCH® and AIRxTOUCH® brands and logos are the exclusive property of iNUI Studio SA. All other trademarks and copyrights are the property of their respective owners. STAFF DURATION...
- Page 3 Be sure to consult the AIRxTOUCH® Customer Service center if you want to install the device in such a place.
-
Page 4: Wall Installation
WALL INSTALLATION... -
Page 5: Power Supply
Wall installation POWER SUPPLY POSITION: BEHIND THE KIOSK Neat installation, hidden power outlet. Instruction · The middle of Instruction · The electrical socket is the electrical socket to be accessible via the aperture on the wall installed at a distance of mount. -
Page 6: Wall Mount
Wall installation WALL MOUNT Holes ø 6 mm Centre-to-centre = 24 cm Mounting holes ⚠ The center of the 2 top mounting holes must be 186 cm from the floor. That way your kiosk will be correctly positionned Support screw (x3) Mounting holes Floor... - Page 7 Wall installation THE RESULT AIRxTOUCH Kiosk 32 Payment Pack 66cm Floor...
-
Page 8: Countertop Installation
COUNTERTOP INSTALLATION... - Page 9 Countertop install POWER SUPPLY When the kiosk is installed on your countertop, you have 2 ways of connecting it: either the power cable simply comes out the back of the system, or it passes through the countertop. METHOD 1 METHOD 2 OUT THE BACK OF THE KIOSK THROUGH THE COUNTERTOP —...
- Page 10 Countertop install COUNTERTOP BASE The base is designed to stabilize the kiosk on your countertop. A large opening allows cables to pass through the counter, and holes are provided for attaching the kiosk to your furniture (screws are not provided). 14 cm Fixation holes ø 8 mm Centre-to-centre = 37,5 cm...
- Page 11 Countertop install THE RESULT AIRxTOUCH Kiosk 32 Payment Pack...
