To use upper tool cabinets with Tekton rolling tool cabinets,
you'll first need to install a
Laminated
Without Sturdy Top
888-648-3371
tekton.com/support
Tekton Stainless
Wood, or equivalently sturdy top.
Warps top surface of lower
cabinet, causing misalignment
and tilted drawers
Upper Tool Cabinet
INSTALLATION GUIDE
Steel,
Stainless Steel
With Sturdy Top
Laminated Wood
How to Install a
Cabinet Top
Scan to View PDF
Advertisement
Related Manuals for tekton OCU30101
Summary of Contents for tekton OCU30101
- Page 1 Upper Tool Cabinet INSTALLATION GUIDE To use upper tool cabinets with Tekton rolling tool cabinets, you’ll first need to install a Tekton Stainless Steel, Laminated Wood, or equivalently sturdy top. Stainless Steel Laminated Wood Without Sturdy Top With Sturdy Top...
-
Page 2: Parts List
Hex Screw (4x) RECOMMENDED TOOLS TEKTON 3/8 Inch Drive x 8 Inch Quick-Release Ratchet (#SRH11108) TEKTON 3/8 Inch Drive x 1/2 Inch 6-Point Deep Socket (#SHD13013) TEKTON 1/4 Inch Center Punch (#66081) TEKTON 26 oz. Flat Steel Face Dead Blow Hammer (#HDB40026) - Page 3 STEP 1: Align drill template and mark drill locations. Align the drill template with the corner and outer edges of cabinet. Once aligned, mark the center of each black circle with a 1/4 inch center punch. Align 3-7/8 Inches 16-1/4 Inches 24 x 18 Inch Drill Template 3-7/8 Inches To ensure proper alignment and to prevent...
- Page 4 STEP 2: Remove marking template(s) and drill mounting holes. Stainless Steel Tops Using a 5/16 inch drill bit, drill through only the 1/8 inch Drill each location 1-1/4 inches deep with a thick stainless steel layer at each marked location. 7/32 inch drill bit.
- Page 5 STEP 3: Remove all drawers and carriages from the upper tool cabinet. To remove each drawer, pull it out to its fully open position, lift the front of the drawer upward, then lift the drawer up and out. Remove Open Fully Carriage Lift Up To remove the carriage, pull it straight out of the cabinet.
- Page 6 STEP 4: Place the upper tool cabinet on the cabinet top. Lift upper tool cabinet and place it onto the tool cabinet. CAUTION We recommend having two people lift each upper tool cabinet to avoid injury and damage to the product. Align the upper tool cabinet with the appropriate drilled locations.
- Page 7 STEP 5: Insert screws into proper hole locations and tighten. Insert each of the included 5/16 x 1-1/4 inch flanged hex screws into the pre-drilled holes and tighten down using a 3/8 inch drive x 1/2 inch socket. Upper Tool Cabinet Tool Cabinet Top Lower Tool Cabinet Side View...
-
Page 8: Installation Complete
While inserting, align the carriage with channel mounts inside of cabinet. Carriage Crossmember Top View of Cabinet Angle Crossmember To install the drawers, set the drawer slides onto the front bearings then push the drawer straight in. Drawer Drawer Slide Front Bearing INSTALLATION COMPLETE Have more questions? 888-648-3371 tekton.com/support...
