MTS-No.: 29919
2

SERVICE

2.1 Changing fuse of 230 V AC supply

Inside of the appliance plug there are the fuses F1 and F2. Defective fuses have to
be changed by fuses of the same type. Pull out the fuse holder at zero-current-unit
(power cable removed at the outside of the Shielding Box) to get access to the fuses.
Attention:

2.2 Cleaning

Maintenance work essentially only includes the cleaning of the unit.
Inform competent authorized personnel if damages are determined.
Attention:
29919.MANUAL / MSB-0410 / V 1.0 / 18 January 2022
MTS Systemtechnik GmbH
Gewerbepark Ost 8
D-86690 Mertingen
To change fuses, first switch off power at power switch S1 a n d
remove the power cable (outside of the Shielding Box)!
Defective fuses have to be replaced by new fuses of the following type!
F1, F2 = T3.15/250 (3.15 A, 250 V AC, slow blow)
To clean the Shielding Box, first switch off power at power switch S1
a n d remove the power cable (outside of the Shielding Box)!
Then disconnect the Shielding Box from all connected lines.
Depending on the degree of contamination, the Shielding Box has to be
cleaned with a lint-free, soft and dry cloth or brush. Do not use cleaning
liquids except for mild detergents (moisten cloth) for cleaning!
