Jefferson JEFTRCH29 User Manual

INTRODUCTION
• High quality 10W (880Lumens) COB LED inspection lamp with 3W LED directional torch.
• USB rechargeable li-ion battery with magnetic charging dock.
• Strong magnet on the base of the housing, allows for flexible positioning in
your workspace for easy hands-free operation.
• 180° tilt allowing you adjust the angle of illumination as required.
• Heavy-duty, ergonomic housing with IK07 impact rating and IP65 ingress protection.
• Powerful, reliable & durable 10W COB LED provides up to 880L luminosity with superior.
quality, efficiency and light density compared with other standard LED technologies.
SPECIFICATION
Model Number:
Luminosity: 10W COB LED Lamp
880 Lumens (High)
440 Lumens (Low)
Operating Time: 1.5 Hours (High)
2.5 Hours (Low)
Charging Time:
Impact Rating:
Ingress Protection:
Battery: Li-ion 18650 3.7V 2600mAh
Weight:
Dimensions: Light D35 x W56 x H203mm
Base D84 x W118 x H75mm
OPERATION
The light has four switching stages. Press once on the On/Off switch to go to the next setting, the following setting are possible:
COB full power - COB half power - torch ON - OFF. Grip the lamp housing and base simultaneously, then rotate magnetic base 180°.
• Charging: Note:
• All light are partially charged when delivered.
• Charge the product before use fully.
• Please do not use the light when charging.
Cleaning:
Allow the light to cool down sufficiently! Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required.
Do not use cleaners that contain abrasives or solvents.
• Warning: Bright light DO NOT shine directly into the eyes.
JEFTRCH29
• The lamp must only be used on flat, stable surfaces which are
3W LED Torch
clean and free from dust, debris or grease.
• This equipment should never be immersed in water or other or
160 Lumens
other liquids.
• Do not operate with wet or greasy hands.
4 Hours
• Do not cover the lamp during operation.
• Must never be operated with an open housing, missing or
2.5 Hours
damaged wiring, compartment, or missing or damaged lens.
IK07 • Must never be sprayed or cleaned using a steam pressure
cleaner since this can damage the insulation and seals.
IP65
• Must never be repaired by the user, repairs must only be carried
out by the manufacturer or an authorized service representative.
410g
• Please do not leave the lamp be in charging over 24 hours.
• Please do not disassemble the lamp.
• Please recharge the lamp every six months when in stock.
www.jeffersontools.com
USER MANUAL / JEFTRCH29
10W COB LED Inspection Lamp
SAFETY
