Jefferson JEFTRCH30 User Manual

INTRODUCTION
Super powerful COB/LED produces extremely bright, white
light with an outputs ranging from 300 - 12000 lumens and
a working range of 100- 200 metres. Zoom type can
be changed from spotlight to wide area by a twist action
of the head.
Durable aluminium housing. Three power options, full power
medium and low. Powered by rechargeable Li-ion batteries.
Supplied with micro USB charging lead.
IP67
USB-C Port
OPERATION
Before first use, unscrew the battery compartment screw cap and
remove the white disc from beneath the contact. The On/Off button
will flash red when the battery level becomes low. Lift up USB cover
to reveal USB charging point, where the provided USB charging cable
can be inserted). Plug in the cable to an appropriate power source.
Charging will take approximately 6hrs. When charged remove USB
cable and close the USB cover. To switch on press on/off button (side
of the torch), press again to change to low beam, press again to switch
off. Twist to adjust light beam from flood light to spotlight.
SPECIFICATION
– 1pc COB led bulb
– 2 X 26650 lithium battery,7.4V 5000mAh
– Mode: High-Medium-Low-off ,dual press strobe mode, long press
ultra bright/Turbo mode
– Brightness:7000lm / 3000lm / 300lm Turbo mode reach 12000 lm
– Runtime:2h-3h-12h,Turbo mode is just 30 seconds at a time
– Product size :68*42*295mm,
– Product weight:903g ( includes battery )
– Include battery, 80cm type C cable
– Waterproof grade: IP67
– Charger: 5V2A (excluded),
– Charging time 6h
– Power bank function, output 5V2A 13.Twist to zoom
– Low battery warning function, the switch will change to red when low battery
– Comes with lanyard
SAFETY
• Warning: Bright light DO NOT shine directly into the eyes.
• This equipment should never be immersed in water or other liquids.
• Do not operate with wet or greasy hands.
• Do not cover the lamp during operation.
• Must never be operated with an open housing, missing or damaged
wiring, compartment, or missing or damaged lens.
• Must never be sprayed or cleaned using a steam pressure cleaner
since this can damage the insulation and seals.
• Must never be repaired by the user, repairs must only be carried out
by the manufacturer or an authorized service representative.
MAINTENANCE
Keep the torch clean by wiping with a damp cloth. Remove batteries if
not being used for a long period of time. Store torch and batteries in a
dry childproof area.
www.jeffersontools.com
USER MANUAL / JEFTRCH30
COB LED Flashlight
