Instructions for Use
Tumble Dryer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRY73CS-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg DRY73CS-1

Summary of Contents for Smeg DRY73CS-1

  • Page 1 Instructions for Use Tumble Dryer...

  • Page 2: Table Of Contents

    Thank you for your trust and for buying our tumble drier. We congratulate you on your wise decision. This appliance is designed for drying clothes for home use only. The dryer enables quick drying of your laundry, leaving it soft and tender without affecting its shape.

  • Page 3: Appliance Description

    Appliance description 1. Front panel 2. Drying program button 3. Water container 4. Door 5. Condenser Technical data (depending on model) 6. Evacuation slots 7. Cooling air slot 8. Legs 9. Front (depending on model) Dimensions of the appliance (w x d x h): 600 mm x 600 mm x 850 mm Weight (net): evacuation dryer 33 kg, condensation dryer 38 kg (40 kg (depending on model))

  • Page 4: Warnings

    Warnings In case of condenser dryer it is not recommended to reduce temperature or switch off the heater, as the drying time is thus extended because of poor condensation of evaporated water. • Use the dryer to dry only the laundry washed with water. Do not attempt to dry the laundry, washed or cleaned with flammable detergents or solutions (gasoline, trichloroethylene etc.), as it may cause explosion.

  • Page 5: Installation And Connection

    The belt can be replaced by a servising engineer only, who incorporates an original spare part with the marking OPTIBELT EPH 1906, code 104265, OPTIBELT 8 EPH 1941, code 160165 (depending on model). The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
  • Page 6 Installation Installation Moist air outlet Moist air outlet 1 Lid 1 Lid 2 Evacuation tube 2 Evacuation tube in the condensation water receptacle or in the pump may damage the dryer. • Appliance can either stand on its own or can be placed on top of a washing machine of the same dimensions - minimum width 517 mm, depth 476 mm.

  • Page 7: Power Connection

    Power connection Power connection The distance between the dryer and the moist air outlet (vent shaft, window) should not exceed 2 meters, otherwise water can accumulate in the tube. B - Condenser dryer • Laundry moisture is eliminated through the water condenser and collected in the condenser tank.

  • Page 8: Operation

    Operation A - program selection jog B - MENU key C - SELECTION key Program selection jog Function keys B key (MENU) - Scrolling within main menu. C key (SELECTION) - Selecting sub-menu categories. D key (START /PAUSE) - Starting, interrupting and restarting the program. D - START/PAUSE key E - display Program symbols...
  • Page 9 Drying procedure Drying procedure Operating the dryer Operating the dryer Open the dryer door by pushing the left-hand side of the door towards the appliance. Sort the laundry according to the type of fabrics. Do the buttons and zippers, tie the strings and pull out the pockets.
  • Page 10 Turn the appliance off by turning the program selector jog A to the position “0”. - Selecting basic drying programs • For the programs cotton , synthetics laundry select the final moisture level (see program chart). To start drying cycle press START or select additional settings.
  • Page 11 Certain programs do not allow selection of this function. After drying is completed, this function returns to the initial higher temperature. Anti-crease program The anti-crease program is set at 1 hour by default. You may also select either to switch off the program (0 h) or prolong the program to last 2 hours (2 h).
  • Page 12 Drying procedure Drying procedure four second pressing of B button (MENU), while the A button is turned to position “0”, so you can select the drying program or additional functions. Sound signal (audible warning) In default setting the sound signal is on. You may select to switch the sound signal off, or increase volume.
  • Page 13 • The display indicates different drying stages in their sequence, according to the selected program. EXAMPLE: Selected program: cotton, slightly moist, functions selected: delayed start, decreased temperature, child lock, no sound signal). Press the START button to confirm commencement of drying Press the START button to confirm commencement of drying (program starts when the delayed start time elapsed) (program starts when the delayed start time elapsed)
  • Page 14 Interruptions Interruptions • By the user Changing the program or the functions After drying be careful when extracting laundry from the appliance, as it may be hot! Prior any changes child lock must be deactivated! By pressing button D (START/PAUSE) the drying program is paused;...

  • Page 15: Tips For Drying And For The Economic Use Of The Dryer

    Special functions Special functions Tips for drying and for the economic use of the dryer • Drying is economically most effective if you dry the recommended quantity of laundry per one charge (see Program Chart). • Do not dry the laundry made of especially sensitive fibers (wool, silk), which may shrink or lose shape.

  • Page 16: Cleaning And Maintenance

    Cleaning and maintenance Cleaning the filter Cleaning the filter Cleaning the Cleaning the condensation dryer condensation dryer • After every drying clean the filter, located in the inner part of the door. • Lift the filter lid (Fig.). • Pull your fingers over the filter to remove fibers and threads lining.
  • Page 17 Cleaning of evacuation Cleaning of evacuation drier drier Replacing the bulb Replacing the bulb (only with some models) (only with some models) so use absorbing cloth for this operation. • Open the exterior lid of the condenser by grabbing the handle on the lower left part of the appliance housing and pull it downwards.

  • Page 18: Troubles

    Troubles Interferences from the ambient (for example electrical wiring) could induce signalization of different faults. In such cases: - switch the appliance off, and wait for a few seconds; - plug in the appliance and repeat the drying program. If the fault repeats, call authorized service shop. Warranty shall not apply in case of failures due to interferences from the environment (lightning stroke, power supply circuit faults, natural disasters).

  • Page 19: Tables

    Tables Program chart Program Type of laundry COTTON Thick or multiple layer laundry. Very dry Thick laundry not requiring ironing Uniformly thick laundry, requiring little or Dry for storage no ironing. Fine laundry requiring ironing. Slightly damp Normally thick cotton or flax laundry. Iron dry SYNTHETICS Thick or multiple layer synthetic or mixed...

  • Page 20: Additional Functions

    Program Type of laundry WOOL Finish Short program for loosening of woolen products. MIXED LAUNDRY Mixed cotton and combined fabrics Dry for storage laundry. Program chart / additional functions Program Delayed start Cotton  Synthetics  Delicate  Larger pieces of ...
  • Page 21 Table of consumption values Rounds/ Remaining min. moisture 6 kg 7 kg 1000 1200 1400 1600 * Energy efficiency class B Table of textile symbols For illustration the chart gives values for 6/7 kg of testing laundry (measured by the EN61121 standard) on different RPM of final spin in washing machine (program dry for storage).
  • Page 24 SP PG3,4 OEM 236170/en (07-08)
