Thane Fitness H2O Dual Buff User Manual

Thank you for purchasing the H2O Dual Buff™, All-In-One Steam Mop Head, Floor Polisher and Scrubber!
This product is designed to be used with the H2O HD™ Steam Cleaner for cleaning sealed hard floors with smooth
surfaces only.
IMPORTANT: Please read the contents of this User Guide before first use and always follow all Instructions and Warnings in
the Manual supplied with the H2O HD™ Steam Cleaner.
Scan this QR code to access the H2O HD™ Manual.
Included:
1 x H2O Dual Buff™ unit
1 x USB-C to USB-A cable
2 x Cleaning Pad
Optional accessory:
H2O Dual Buff™ Scrubbing Pad*
*To order H2O Dual Buff™ scrubbing pads please contact the customer service or website where you purchased your unit from.
Specifications:
Model #: KB-068
Li-ion Battery: 11.1 V, 1500 mAh, 16.65 Wh
DC Input: 5V 2A
Rated Power: 72 W
Household Use Only
How to Charge H2O Dual Buff™
1. Make sure to charge the unit fully before first use. The full charge time is around 2.5 - 4 hours.
2. Connect the USB-C connector to the charging port on the unit and plug in the USB-A connector into a 5V 2A rated
USB Wall Charger. The Battery Light Indicator will turn red while charging. When the unit is fully charged the Battery Light
Indicator will turn green.
3. Once the charging is done, unplug the cable from the charging port on the H2O Dual Buff™
NOTE: When the battery power is low the Battery Light Indicator will start flashing red to warn you to charge the battery.
WARNINGS:
- Never use the H2O Dual Buff™ unit while it is charging!
- Avoid charging or storing the H2O Dual Buff™ unit at high temperatures greater than 120°F (50°C). High
temperatures might ignite the battery and cause a fire. Avoid charging lithium batteries below freezing (32°F or 0°C),
as this will permanently reduce the battery capacity.
NOTE: The average charging time for this product will vary based on
the type of charger and power source used.
How to attach H2O Dual Buff™ to H2O HD™ Steam Mop
1. Take the H2O Dual Buff™ Cleaning Pads and attach them to
the two round discs located at the bottom of the H2O Dual Buff™
unit. Press and fit together ensuring a snug fit. (fig. 1)
On/Off Button
Dual Discs
Connector
Cleaning
Pads
USER GUIDE
USB-C Charging Port
Battery Light
Indicator
USB Cable
FIG. 1
