WorldWEIGH E302 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E302 INDICATOR
(P.N. 305669264, Revision L1, August 2013)
81320475 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E302 and is the answer not in the manual?

Questions and answers

Related Manuals for WorldWEIGH E302

Summary of Contents for WorldWEIGH E302

  • Page 1 E302 INDICATOR (P.N. 305669264, Revision L1, August 2013) 81320475 en...
  • Page 2 Easy Reference: Model name of the indicator: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place:...

  • Page 3: Table Of Contents

    10 OPERATION ..................15 10.1 ZEROING ..................15 10.2 TARING .................... 15 10.2.1 MANUAL TARE ................15 10.2.2 PRESET TARE (NOT AVAILABLE ON E302-M APPROVED INDICATORS) ..................16 10.3 WEIGHING ..................17 10.4 PARTS COUNTING ................. 17 10.5 CHECK-WEIGHING ................. 21 10.5.1 SETTING UP WHILE WEIGHING ..........
  • Page 4 15.3.8 F8 –ZERO MODE ..............60 15.3.9 F9 –LOW VOLTAGE DETECTION ..........60 15.3.10 F10 –CALIBRATION COUNT (E302-M ONLY) ......61 15.3.11 F10 –AUTO ZERO RANGE (NOT AVAILABLE ON E302-M) ... 61 16 REPLACEMENT PARTS AND ACCESSORIES ........62 17 SERVICE INFORMATION ..............63 18 APPENDIX .....................

  • Page 5: Introduction

    The E302 has LEDs to indicate when a weight is below the low limit, between the limits or above the high limit next to the display. These can work in conjunction with an audible alarm for check weighing as well as LCD showing LO, OK and HI.

  • Page 7: Specifications

    DIGITAL SECTION Maximum Range Typically 1kg – 30000kg Divisions Up to 30,000, (E302 –M, 3000 or less) Weigh units kg / g / lb for Europe, Asia, Africa kg / g / lb / oz / lb:oz for USA kg only for E302-M series...

  • Page 9: Installation

    3 INSTALLATION UNPACKING This indicator must be connected to a load cell platform and calibrated as necessary to match the platform and user requirements. See Section 15 for set-up information. The users application and the technical specifications of the platform or load cell will determine the necessary configuration.

  • Page 10: Connection

    E302-M model must use the 6 wire connection and has certain limitations for wire size and length. Refer to the Approval Test Certificate for details.

  • Page 11: Keypad

    Figure 1A shows the connections to a 6 wire load cell. Figure 1B shows a preferred method to attach a 4 wire load cell, using a 6 conductor cable to go from the indicator to the platform or load cell where it connects to the 4 wires from the load cells.
  • Page 12 [Low It sets the limits for check weighing and None Limit] allows setting of either the low limit or the high limit or both. & [High Limit] [Lim] It stores and recalls any of 10 preset limits None [Func] This is used to select percent weighing, RS- None 232 parameters, Operation of the bar graph, RTC settings, User ID and Scale ID.

  • Page 13: Display

    5 DISPLAY 5.1 SYMBOLS AND INDICATORS The LCD has unique symbols to indicate the following: 0 The display is at Zero The scale is Stable Net weight- The scale has been tared kg / lb Symbols shown for the units Capacity Tracker- A bar graph indicating the proportion of the scale capacity being used by the weight on the pan Low battery...

  • Page 14: Calibration Counter For Approved Indicators

    Low to OK to High. 6 CALIBRATION COUNTER FOR APPROVED INDICATORS With approved (E302-M Model) indicators we have the ability to control access to the calibration or metrology parameters using a passcode to limit access. The requirements for doing this stipulate the code should be apparent and recorded in a suitable location on the indicator.
  • Page 15 The Counters are incremented any time the calibration section or the Factory parameters section have been modified. At power on, the display will show the current software revision number followed by the message of the Calibration Count “[AL[nt” then a number i.e. “123”. The number from the counter memory.

  • Page 16: Battery

    7 BATTERY The indicators can be operated from the rechargeable battery, if desired. The battery life is determined by the number and impendence of the load cells connected. With a single load cell and backlight disabled the life is approximately 70 hours before needing to be recharged.

  • Page 17: Operation

    10 OPERATION 10.1 ZEROING You can press the [Zero] key at any time to set the zero point from which all other weighing and counting is measured. This will usually be necessary when the platform is empty. When the zero point is obtained the display will show the zero indicator.

  • Page 18: Preset Tare (Not Available On E302-M Approved Indicators)

    Press [Tare] or [Zero] to remove the tare value and display zero. The Net indicator will disappear. 10.2.2 PRESET TARE (NOT AVAILABLE ON E302-M APPROVED INDICATORS) When the indicator is at zero with no weight on the platform it is possible to enter a preset tare.

  • Page 19: Weighing

    10.3 WEIGHING To determine the weight of a sample, first tare an empty container if used, then place the sample in the container. The display will show the weight and the unit of weight currently in use. To change the weighing unit press the [Unit] key. The only alternative weighing unit is pounds.
  • Page 20 Either place 10 parts on the platform for determining the average piece weight or use a different number of parts. For example, place 20 parts on the platform, press [CE] to clear the last values and then enter the value 20 using the numeric keypad.
  • Page 21 weight, unit weight and number of parts by each time pressing the [Func] key.
  • Page 22 To count a different sample quantity, press the [Count] key. The display will show the last used sample size. Either use this sample size with a different part or enter a new sample size as above. To return to weighing, press [Unit] when “XX pcs” is displayed.

  • Page 23: Check-Weighing

    10.5 CHECK-WEIGHING Check-weighing is a procedure to display an indicator or sound an alarm when the weight on the platform meets or exceeds the values stored in the memory. The memory holds values for a high limit and a low limit. Either or both the limits can be set by the user.

  • Page 24: Setting Up While Weighing

    10.5.1 SETTING UP WHILE WEIGHING Press the [Low Limit] key. It will show the current low limit. The “LO” symbol will appear on the display. Press the [CE] key to clear the old value and then enter the new low limit using the numeric keys.

  • Page 25: Setting Up While Parts Counting Or % Weighing

    10.5.2 SETTING UP WHILE PARTS COUNTING OR % WEIGHING During parts counting and percent weighing the limits are set in the same way as above. The limits are displayed in pcs or %. See Section 10.4 for the description of parts counting and Section 10.7 for percent weighing.
  • Page 26 Press the [Lim] key. If you are already in the check weighing mode the display will ask if you wish to store the current limits by showing “StOrE” or recall another set of limits by showing “rECALL”. The [Lim] key can be used to toggle between “StOrE”...

  • Page 27: Percent Weighing

    NOTE: 1. If the recalled limit is for parts counting, the display will show the last sample value used, ready for a new sample to be counted. 2. If the recalled unit is a percent weighing limit, the display will show the last sample value used, ready for a new sample to be weighed.
  • Page 28 Press [Tare] again to enter percent weighing. The indicator will set the sample mass on the platform as 100% reference weight. NOTE: If there is no reference weight on the pan and percent weighing function is entered, pressing [Tare] again will return the indicator to normal weighing.
  • Page 29 If the indicator shows “x x . x x %”, which is the last weight used as a reference, press [CE] to clear and use the numeric keypad to enter a new value. Press [Tare] to accept the new reference weight. The weight entered must be greater than 50 scale divisions.

  • Page 30: Animal (Dynamic) Weighing

    10.8 ANIMAL (DYNAMIC) WEIGHING The indicator can be set to animal (dynamic) weighing for weighing any items that are unstable or may move. See Section 13.4. The indicator uses a special filter to minimise the effects of any movement on the platform.

  • Page 31: Animal Weighing Procedure

    10.8.1 ANIMAL WEIGHING PROCEDURE With the platform empty the display will show zero weight.. Place containers or blankets onto the platform and press the [Tare] key to zero the display. The indicator may go into the animal weighing procedure when the items are placed on the platform but will return to showing zero when the [Tare] key is Place the animal to be weighed on the platform.

  • Page 32: Accumulated Total

    10.9 ACCUMULATED TOTAL The indicator can be set to accumulate when a weight is added to the platform automatically or manually by pressing [Print]. See Section 13.2. NOTE: 1. The accumulation function is available only during weighing. It is disabled during parts counting or percent weighing.
  • Page 33 When the indicator is at zero place a second weight on the platform. When stable press [Print] to accumulate the weight. The display will show "ACC 2" for 2 seconds and then show the new total. Continue until all weights have been added. This can continue for up to 99 entries until the capacity of display is exceeded.

  • Page 34: Automatic Accumulation

    10.9.2 AUTOMATIC ACCUMULATION When the indicator has been set to Automatic Accumulation the value is stored in memory automatically. Place a weight on the platform. The beeper will sound when the display is stable indicating the value is accepted. Remove the weight. The display will show "ACC 1"...

  • Page 35: Rs-232 Specification

    11 RS-232 SPECIFICATION The E302 indicator is supplied with bi-directional RS-232 interface as standard. The indicator when connected to a printer or computer outputs the weight with the selected weighing unit through the RS-232 interface. Default Specifications: RS-232 output of weighing data...
  • Page 36 LABEL = On Label Formats are printed Data Format-Normal Output: Only weight value along with the weighing unit is printed. If Percent weighing is used then % is shown in place of weighing units. <cr><lf> <cr><lf> 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf>...
  • Page 37 <cr><lf> <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> Net Wt. 1.234 kg <cr><lf> Net Wt. (or Gross Wt.) Unit Wt. 123 g <cr><lf> g for metric and lb for pounds 10 pcs <cr><lf>...
  • Page 38 Data Format- Memory Recall Output: <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> ------------------<cr><lf> TOTAL <cr><lf> 1.234 kg <cr><lf> 10 pcs <cr><lf> <cr><lf> ------------------<cr><lf> <cr><lf> Data Format- Continuous Output- Normal weighing: 1.234 kg <cr><lf>...
  • Page 39 LABEL = Off single line output Fixed line width, leading zeros are spaces. 1.234 Kg<lf><cr> Data Format-Normal Output: TOTAL No. 1.234 Kg, 10 pcs<lf><cr> Data Format- Memory Recall Print: NOTE: 1. The accumulated total will not be sent to the RS-232 when the continuous print is turned on.
  • Page 40 Description ENGLISH FRENCH GERMAN SPANISH Net Wt. Pds Net Net-Gew Pso Net Net weight Unit Wt. Pds unit Gew/Einh Pso/Unid Weight per unit counted Stck. Piezas Number of items counted Anzhl Num. Number of weighing added to subtotals Total Total Gesamt Total Total weight and...

  • Page 41: Input Commands Format

    11.1 INPUT COMMANDS FORMAT The indicator can be controlled with the following commands. Press the [Enter] key of the PC after each command. T<cr><lf> Tares the indicator to display the net weight. This is the same as pressing [Tare]. Z<cr><lf> Sets the zero point for all subsequent weighing.

  • Page 42: Calibration

    12 CALIBRATION The E302 indicator can be calibrated using kilogram weights or using pounds weights, depending on the weighing unit selected at the time of calibration. To start the calibration, either get into the calibration section through the Indicator Settings (“FUnC 3”- see Section 13.3) or turn the indicator off and switch on again and then press [Tare] during the self-test.

  • Page 43: Parameter Settings

    13 PARAMETER SETTINGS Pressing the [Func] key allows the user to access the parameters for customising the indicator. The parameters are split into 4 groups- 1. Check weighing parameters, 2. RS-232 parameters 3. Indicator parameters 4. Percent and Animal Weighing Functions When [Func] is pressed, display will first show “FUnC 1”...
  • Page 44 Press [Func] to view the options for setting. Press [Tare] to confirm the change and then advance to the next parameter by pressing the [Func] key. This group of parameters- - enables or disables the percent weighing - sets the lock for re-setting the check weighing limits - enables or disables the check weighing LED indicator - enables or disables the check weighing alarm - sets the User Password for check weighing...
  • Page 45 F2 LEd This parameter sets the LED - Bar type indicator to off or on and the Spot - Spot type LED type (whether LED’s are Segment on in the form of a - Off continuous bar or a spot LED or a segment of colour).

  • Page 46: Rs-232 Parameters

    13.2 RS-232 PARAMETERS Shortcut to enter this group is to press and hold the [Print] key for 4 seconds. The display will go directly to “C1 on”. Press [Func] to view the list of parameters. Press [Tare] to enter a parameter. Press [Func] to view the options for the parameter settings.
  • Page 47 C3 PrM mA StA mA Sta Printing Mode- Manual as soon as stable, *mA AnY Manual as soon as the key is pressed stable or not, *Au StA Automatic As soon as stable Au End Automatic when weight is removed *Ct StA Continuous only when stable...
  • Page 48 The indicator will perform the following, depending on the Accumulation and Print Settings: AC on AC Off CCUMULATION SETTINGS PRINT SETTINGS Accumulate and Print as soon Print as soon as the [Print] key is as the [Print] key is pressed. pressed, and the scale is stable.
  • Page 49 Accumulate and print when Print after the scale is stable and the the scale has reached weight has been removed. stability after the weight is Au End If the [Print] key is pressed it is removed. ignored. If the [Print] key is pressed it Do not accumulate.

  • Page 50: Indicator Parameters

    13.3 INDICATOR PARAMETERS Shortcut to enter this group is to press and hold the [Count] Key for 4 seconds. The display will go directly to “S1 Un ”. Press [Func] to view the list of parameters. Press [Tare] to enter a parameter. Press [Func] to view the options for the parameter settings.
  • Page 51 S3 AoF SLP 0 SLP 0 Auto Off- Disable or set time increment to turn off SLP 1 the indicator SLP 5 SLP 10 S4 dt 00:00:00 Set Time and Date format Enter the time manually and settings mm:dd:yy Enter the date manually S5 diS Display all weights or only...

  • Page 52: Percent Weighing And Animal Weighing

    13.4 PERCENT WEIGHING AND ANIMAL WEIGHING See section 10.7 and 10.8 for details of these special weighing modes. Parameter Description Options Default setting F4 PCt This parameter allows the None Enabled user to enter the Percent always weighing Function. Section 10.7. F4 AnL Enter the Animal Weighing Set the filter value.

  • Page 53: Error Messages

    14 ERROR MESSAGES During the initial power-on testing or during operation, the indicator may show an error message. The meaning of the error messages is described below. If an error message is shown, repeat the step that caused the message. If the error message is still shown then contact your dealer for support.
  • Page 54 and high limit not equal to zero. Err 9 Low limit input error High limit is set first, then the low limit is set higher than the high limit and low limit not equal to zero. FAIL H or Calibration error Improper calibration (should be within +10% of the factory FAIL L...

  • Page 55: Service Parameters

    15 SERVICE PARAMETERS 15.1 ACCESS TO PARAMETERS APPROVED INDICATORS Access to the indicator parameters and calibration is controlled in all approved indicators either by limiting access to be after the Calibration Jumper is put on the PCB, location J1, pins 1 & 2. In this case the display will show the passcode request screen, “...

  • Page 56: Using "2006" To Enter The Service Parameters

    [Tare] If Calibration is complete, “SPAn PASS” will be “SPAn” “PASS” displayed. Remove the calibration weight. This means calibration has failed. Remove the Or, “SPAn” “FAiLEd ” calibration weight and repeat the process. Remove the jumper or shorting of the pins “JP On”...
  • Page 57 Apply power to the indicator. If the jumper has been used the display will ask for a code number, “Pn “ on the Weight Display immediately. Or press the [Tare] key during the time the calibration counters are being displayed. Enter the number 2006 when “Pn “...

  • Page 58: F1 -Calibration

    15.3.1 F1 -CALIBRATION To enter the calibration parameter, press the [Tare] key when “F1” is displayed. The indicator will be calibrated using 2 masses of approximately 1/3Maximum and Maximum. If the indicator has been calibrated once the values will be stored. If this is the first time the indictor is calibrated the user must enter the values for the calibration masses.

  • Page 59: F2-Decimal Point Position

    Switch off the indicator, and switch it on again to continue with the other Service parameters. 15.3.2 F2–DECIMAL POINT POSITION To set the value for the decimal point location. The options are 0, 0.0, 0.00, 0.000, 0.0000 To enter this parameter, press the [Tare] key when “F2 dEC” is shown. The display will show the current setting.

  • Page 60: F4 -Initial Zero Range

    The display will show the current increment value as used with the current decimal point position. Press the [Func] key to change the value. Select from 1,2,5,10, 20 or 50 Not all increments may be available for the capacity you selected. For EC Approved versions the indicator will determine the increment that maintains the number of divisions to be 3000 or less.

  • Page 61: F6 -Successive Tare

    Press [Tare] to accept the value. Press [Zero] to return to weighing. 15.3.6 F6 -SUCCESSIVE TARE To enter this parameter, press the [Tare] key when “F6 SCS” is shown. The display will show if the successive tare is on or off. Press the [Func] key to change the value.

  • Page 62: F8 -Zero Mode

    15.3.8 F8 –ZERO MODE To enter this parameter, press the [Tare] key when “F8 ZEm” is shown. Select the Zero mode desired. In all but special cases Zero Mode 1 is used. other 2 zero modes are for unique locations in the world and effect the +/- range of the zero.

  • Page 63: F10 -Calibration Count (E302-M Only)

    Press [Tare] to accept the displayed value. Press [Zero] to return to weighing. 15.3.11 F10 –AUTO ZERO RANGE (NOT AVAILABLE ON E302-M) This parameter set the range the autozero is active within. To enter this parameter, press the [Tare] key when “F10 Az” is shown.

  • Page 64: Replacement Parts And Accessories

    16 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Cooperativa Bilanciai. A partial list of such items is as follows- Main Power cord or adaptor for In use cover USA versions. Printer, etc.

  • Page 65: Service Information

    17 SERVICE INFORMATION This manual covers the details of operation. If you have a problem with the indicator that is not directly addressed by this manual then contact your supplier for assistance. In order to provide further assistance, the supplier will need the following information which should be kept ready:...
  • Page 66 A. Details of your company -Name of your company: -Contact person’s name: -Contact telephone, e-mail, fax or any other methods: B. Details of the unit purchased (This part of information should always be available for any future correspondence. We suggest you to fill in this form as soon as the unit is received and keep a print-out in your record for ready reference.) Model name of the indicator: Serial number of the unit:...

  • Page 67: Appendix

    18 APPENDIX PARAMETER LAYOUT for E302 / E302-M SCALES Key functions while in this section [Tare] enter a parameter or accept the changes Press the [Func] key to [Func] move to next parameter or option enter Functions mode. [Zero] return to previous parameter or return to weighing...
  • Page 68 This symbol on the weighing instrument you have purchased means that: • this electric or electronic appliance cannot be disposed of as solid municipal waste; • it must be collected separately; • it can be returned to the dealer when a new one is purchased; •...

  • Page 69: Declaration Of Conformity

    19 DECLARATION OF CONFORMITY SOCIETÀ COOPERATIVA BILANCIAI CAMPOGALLIANO Via S. Ferrari, 16 41011 Campogalliano (MO) - Italia Declare under our responsibility that the product: Electronic weighing terminal E 302 and its options described in this declaration complies with: Directive EMC 2004/108/CEE Directive Low voltage 2006/95/CE Conformity is censure by complying with EN 61000-6-3, EN 61000-6-4...
