Summary of Contents for AUDMIC TE-106
- Page 1 TE-106 Portable Suitcase Record Player Turntable Instruction Manual Turntable with USB and Bluetooth Reception User’s Guide...
- Page 2 Instructions Before Start Read the manual before using this product. Keep these instructions for future reference. About Records Never use a record with cracks or warps. Never use a record that is cracked or warped, as this may cause extreme wear and destruction of the needle. Never use unusual play methods such as scratching.
- Page 3 PARTS ILLUSTRATION: 1. Turntable Platter 11. Stylus 2. Turntable spindle 12. USB connector 3. 45 RPM adaptor 13. TF connector 4. Tone arm lift lever 14. Modes select key/Record button 5. Tone arm holder 15. Next music track 6. Auto stop ON/OFF switch 16.
-
Page 4: Rear Inputs
Rear Inputs DC Power Input Audio Output Connect to send audio signal to an external source. Connecting the main unit to Power 1. Plug the power cord into the DC Input on the back of the unit. 2. Then plug the USB side into a the DC adapter included. 3. - Page 5 Operation---Playing a Record It is recommended that you use extreme care when manipulating the tone arm, stylus, and other components of this turntable. These parts are very sensitive and can easily break or become damaged if they are carelessly handled. Lock Unlock 1.
- Page 6 Bluetooth Input--- pairing with Bluetooth 1. Set the auto-stop to "ON" and short press “M” button on the control panel to switch mode to "bt" on the display. 2. Using the controls on your Bluetooth device, search for and select "BLTD"in your Bluetooth settings to pair. If your device requests a password, enter the default password "0 0 0 0 "...
-
Page 7: Rca Audio Output
RCA Connecting to External Systems RCA Audio Output Requires RCA audio cables (red/white, not included). Use to connect the turntable to an external stereo, television, or other source. 1. Connect RCA audio cables to the RCA Audio Output on the back of the turntable, and to the audio input of an external stereo system. - Page 8 AUX IN Connecting to Audio Source Requires 3.5 mm audio input cable (not included). Note: When the Source selector is set to Aux In, When a 3.5mm audio cable is plugged into the unit, it will automatically detect the input and power ON in Aux In mode. 1.
-
Page 9: There Is No Power
Troubleshooting There is no power • Power adaptor is not connected correctly. • No power at the power outlet. • Use the wrong adapter instead of he original one included. • Power button is not turned on, turn the volume/ON/OFF button clockwise to turn on. My record is skipping. - Page 10 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure Statement The distance between user and products should be no less than 20cm. Model: TE-001 FCC ID: AUD-TE001 Made In China AUDMIC INDUSTRIAL LIMITED...
