- Page 1 AirMetER-AX HEATED INLET INSTALLATION GUIDE Revision | November 2023 Air-Met Scientific...
- Page 2 HEATED INLET INSTALLATION Ensure the O-ring is installed on the heated inlet. Feed the heated inlet cable through the adapter. Air-Met Scientific...
- Page 3 HEATED INLET INSTALLATION Push the heated inlet into the heated inlet adapter, pulling the heated inlet cable all the way through the adapter to prevent it getting caught. Begin screwing the heated inlet clockwise, using the other hand to assist the heated inlet cable in twisting around the tube adapter.
- Page 4 HEATED INLET INSTALLATION Install the TSP head onto the top of the heated inlet, ensure the heated inlet’s grub screw is loose, and carefully push the TSP head towards the instrument whilst holding the tube adapter still to secure the heated inlet shaft to the tube adapter.
- Page 5 HEATED INLET INSTALLATION On the left side of the enclosure plug, secure the heated inlet cable and the plug on the side of the enclosure. Verify the flow rate is 2L/m ± 5% with a 0.4- 5L/m rotameter. Should the flow rate not be within this range, navigate to the flow rate calibration section of this guide.
-
