Operation
STEP 5.
To reset the Loadbuster tool for the next
operation, hold as shown in Figure 7. Extend
the tool slightly and lift the resetting latch with
the thumb. With the latch up, press down on
the inner tube assembly until the tool is closed
completely so the trigger can reset itself. When
reset properly, the orange paint on the inner
tube assembly will no longer be visible. Check
for proper resetting by extending the tool about
3 inches (76 mm). Throughout this travel an
increasing spring resistance should be felt.
14
S&C Instruction Sheet 811-505
Figure 7. Resetting the Loadbuster tool.
Press down
on the inner
tube
Resetting
latch
