TEJAS NETWORKS TejNEOS TJ1400P-H Enterprise Hardware Description Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TejNEOS TJ1400P-H Enterprise
10.0.12.2 Hardware Description Guide
Version: 1.0
Issue Date: 21-Feb-2024
www.tejasnetworks.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TejNEOS TJ1400P-H Enterprise and is the answer not in the manual?

Questions and answers

Related Manuals for TEJAS NETWORKS TejNEOS TJ1400P-H Enterprise

Summary of Contents for TEJAS NETWORKS TejNEOS TJ1400P-H Enterprise

  • Page 1 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide Version: 1.0 Issue Date: 21-Feb-2024 www.tejasnetworks.com...
  • Page 2 Copyright Notice Copyright © Tejas Networks Ltd. All rights reserved. No part of this book or manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or by any information storage and retrieval system, without the express written permission from Tejas Networks Ltd.
  • Page 3 Revision history Version Document ID and Issue Updates Date 421-DOC000041-E Standard Release 21-Feb-2024...

  • Page 4: Table Of Contents

    Table of Contents Document overview Target audience ..................5 Additional resources ................5 Chapter organization ................6 TJ1400P-H overview TJ1400P-H system System specifications ................13 Fan tray unit ..................15 Power supply unit ................16 DC PSU ....................16 AC PSU ....................19 Interfaces ...................

  • Page 5: Document Overview

    Additional resources For more information, refer to the following guides. Document Name and Version Description TejNEOS TJ1400P-H Enterprise The document details the procedures to install the 10.0.12.2 Installation and product and to initially configure it to the point of Commissioning Guide verifying its proper operation in the network.

  • Page 6: Chapter Organization

    TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Chapter organization This document is organized as follows: Chapter Scope TJ1400P-H overview Provides an overview of TJ1400P-H product. TJ1400P-H system Provides the chassis views, physical specifications, and field replaceable units of the product.

  • Page 7: Tj1400P-H Overview

    TJ1400P-H overview TJ1400P-H overview The TJ1400P-H product model is an ultra-converged industry’s packet access and aggregation platforms. This is suitable for mobile backhaul, enterprise, business, data center, cloud and infrastructure services. Supports efficient delivery of residential triple- play and video-on-demand services. Following are the key features: ...
  • Page 8 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 This page is intentionally left blank ©Tejas Networks Ltd.

  • Page 9: Tj1400P-H System

    TJ1400P-H equipment can be configured in various topologies such as Linear, Ring and Bus. TJ1400P-H supports up to 300Gbps bidirectional switching capacity. Front panel view of TJ1400P-H chassis The following figure shows the front panel view of the TJ1400P-H: Figure 1: TJ1400P-H - Front panel view ©Tejas Networks Ltd.
  • Page 10 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Numbering Description Numbering Description Chassis Grounding BITS Data port 2XCFP2 100GE (P1 and P2) USB port 1XQSFP28 100GE (P3) NMS port/LAN 10GE/1GE Ports (P9-P31) DIAG port 25G Ports (P5 and P7) All the bottom ports are odd...
  • Page 11 The following table lists the port symbols present on the TJ1400P-H chassis and their representation. Table 1: TJ1400P-H Port symbol representation Symbol / Port Port or Connector Name Active LED Status LED Diag Bits Alarm in Alarm out Power ©Tejas Networks Ltd.
  • Page 12 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 LED indication details The LED indications present on the front panel of TJ1400P-H include the following:  Two LEDs namely Active and Status on the front panel that indicate chassis status ...

  • Page 13: System Specifications

    Installation rack Installation rack type 19 inch Chassis installation rack height 1 Rack Unit (RU) Air flow direction in the chassis Front to rear Mechanical Height 44mm specifications Width With mount angles 478mm Without mount angles 442mm ©Tejas Networks Ltd.
  • Page 14 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Type Parameter Value Depth Excluding Air Filter latch 483mm handle Weight Chassis with Mount angles, 9.5kgs Backplane, one PSU, and PSU filler panel Electrical specifications Power rating 290W (Typical), 360W (Maximum) Input voltage range...

  • Page 15: Fan Tray Unit

    The FTUs are designed to be replaceable at the field.  Air-flow direction is from the front to the rear. Rear panel The following figure shows the FTU on the rear view of TJ1400P-H. Figure 3: Fan Tray Unit of TJ1400P-H ©Tejas Networks Ltd.

  • Page 16: Power Supply Unit

    TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 LED indication details There is one visual indicator present on TJ1400P-H FTU. The following table describes the LED color indications of the FTU. Table 6: TJ1400P-H FTU LED status and their significance...
  • Page 17 Table 8: TJ1400P-H DC PSU - Operational Specifications Specification Range MTBF 46 years PSU weight 1.1kg Input voltage range -40V to -60V DC Output voltage 12V ± 10% DC Output Current 70.8 A Output power 850 W ©Tejas Networks Ltd.
  • Page 18 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Specification Range Maximum Power 360W consumption Input Specifications Input Voltage: -40V to -60V DC Inrush Current: 40A, Pk Input Current: 27A, DC Efficiency: 89% Output Specifications Output Ripple & Noise on output: 120 mV, Pk-Pk Environmental Storage Temperature: -40°C to 85°C...

  • Page 19: Ac Psu

    AC PSU converts the input AC to output DC to supply a stable power to other cards/units present in the TJ1400P-H chassis. Front panel view The following figure shows the front panel of TJ1400P-H AC PSU. Figure 5: TJ1400P-H AC PSU ©Tejas Networks Ltd.
  • Page 20 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Functional description The AC Power Supply Unit (PSU) is a part of the common unit of TJ1400P-H. The PSU functions on a load-sharing basis to provide redundancy. That is, if one PSU fails, the other PSU becomes the active load driver and continues to supply stable 12V DC power to the system.
  • Page 21 Storage Temperature: -40°C to 70°C Specifications Operating Temperature: -40°C to 60°C Operating/Storage Humidity: 95%, Non-condensing Under Voltage Recovery: 85V+/- 3V Protection Shutdown: Recovery -3V Protections Input Under Voltage (Auto Retry Mode) Over-temperature (Auto-recovery) Output Over-Current Output Over-Voltage ©Tejas Networks Ltd.
  • Page 22 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Specification Range  EN55022 Class A EMI/EMC, Safety, Environment  EN 55032 Class A Compliance  IEC61000-4-2 (4.0kV contact discharge and 8.0kV Air Discharge)  IEC61000-4-3 (80-1000MHz, level 2 (3V/m), 690MHz-6GHz, level 3(10V/m) ...

  • Page 23: Interfaces

    RJ45 connector and used to manage the product. The following table provides the details on NMS LED indications and its significance. Table 11: TJ1400P-H - NMS LED status and their significance Card Status NMS LED (Green) NMS LED (Amber) Link Present Blink (10/100/1000) Link Absent ©Tejas Networks Ltd.
  • Page 24 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 BITS Interface A BITS DATA/CLK interface through a RJ45 connector is used for OAM.  One RJ-45 interface with no LED indication.  Supports one BITS data port and one BITS clock port.

  • Page 25: Data Interfaces

    TJ1400P-H has the following data interfaces: Table 12: TJ1400P-H port matrix Feature Description System switching capacity Up to 300Gbps Maximum number of 1GE ports Maximum number of 10 GE ports Maximum number of 25G ports Maximum number of 100 GE ports ©Tejas Networks Ltd.
  • Page 26 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 This page is intentionally left blank ©Tejas Networks Ltd.

  • Page 27: 1G Optical Interface Specifications

    1310 nm 1310 nm 1310 nm 1550 nm (nominal) Connector Type Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC Optical pluggable slot- cage-packaging Fiber Type Multi mode Single mode Single mode Single mode Single mode ©Tejas Networks Ltd.

  • Page 28: Optical Interface Specifications

    TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 10G optical interface specifications Table 14: Specifications for 10 Gigabit (10G) Specifications 10GBASE-LR 10GBASE-ER 10GBASE-ZR Minimum Output Power -8.2 dBm -4.7 dBm 0 dBm Maximum Output 0.5 dBm 4 dBm 4 dBm...

  • Page 29: 100G Optical Interface Specifications

    1294 to 1310 nm 1528.77 to 1566.72 nm @ 50 GHz Tuning OSNR for BER 10e-15 14 dB with SD-FEC Chromatic dispersion ± 22000 ps/nm (~1200 Km of tolerance G.652 fiber) Connector Type Fiber Type Single mode Single mode ©Tejas Networks Ltd.
  • Page 30 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 This page is intentionally left blank ©Tejas Networks Ltd.

  • Page 31: Regulatory Standard Compliance

    RoHS standards in this chapter is not exhaustive. The standards listed are generally regarded as the primary applicable standards. The conformity status on additional national and international standards not listed in this section can be provided upon request. ©Tejas Networks Ltd.
  • Page 32 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 Table 17: Regulatory standards compliance Specification Standard  FCC Part-15, Subpart B, Class-A EMI/EMC  ICES-003, Class-A  EN 55032 Class-A / CISPR-32 Class-A  EN 61000-3-2 and EN 61000-3-3  EN 55035 / CISPR-35 ...

  • Page 33: System Availability And Mtbf Calculation

    When a line card x is used in redundant configuration, then A= 1- (1-Ax)^2 Card MTBF in years MTBF in Hrs MTTR in Hrs STOLT-1H 192720 CEF8-1 (Cross 201480 connect card) DPU1250 (Power 709560 supply) 595680 315360 ©Tejas Networks Ltd.
  • Page 34 TejNEOS TJ1400P-H Enterprise 10.0.12.2 Hardware Description Guide v1.0 This page is intentionally left blank ©Tejas Networks Ltd.

  • Page 35: Acronyms

    Local Craft Terminal Light Emitting Diode Loss Of Signal Manufacturer Part Number MTBF Mean Time Between Failures Network Management System Operation, Administration and Management Power Supply Unit Packet Transmission Network Small Form-factor Pluggable Time of Day Tejas Part Number ©Tejas Networks Ltd.
