Use and maintenance manual
ECON.INDEX 92848 CCIAA TE
VAT and TAX NUM. IT 00732060678
S.C. 2,000,000 Euro f.p.
USE AND MAINTENANCE INSTRUCTIONS
MOBILE SCAFFOLD
TSA 320

Advertisement

Table of Contents
loading

Related Manuals for Faraone TSA 320

Summary of Contents for Faraone TSA 320

  • Page 1 Use and maintenance manual ECON.INDEX 92848 CCIAA TE VAT and TAX NUM. IT 00732060678 S.C. 2,000,000 Euro f.p. USE AND MAINTENANCE INSTRUCTIONS MOBILE SCAFFOLD TSA 320...

  • Page 2: Table Of Contents

    Use and maintenance manual This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden Table of contents CHAPTER 1 - GENERAL 1.1. I NTRODUCTION 1.2. D ESIGNATION 1.3.
  • Page 3 ANNEX 1 - PANTOGRAPH FOR TSA 320 ORKING POSITION TSA 320.P TSA 320 SSEMBLY NSTRUCTIONS ATTACHMENT 2 - CANTILEVER DECK FOR TSA 320 SUBSTITUTE ELEMENTS FOR TSA 320 ORKING POSITIONS TSA 320 NSTRUCTIONS FOR SE OF MOBILE SCAFFOLD WITH CANTILEVERED DECK ATTACHMENT 3 - TSA 320.SP FOR TSA 320...

  • Page 4: Chapter 1 - General

    Use and maintenance manual Chapter 1 - GENERAL 1.1. Introduction This USE AND MAINTENANCE MANUAL Is aimed at providing users with the essential information to carry out the procedures intended for the appropriate operation of the mobile elevating scaffold, in accordance with the purposes it has been manufactured for. All information in this manual must be READ and UNDERSTOOD before making any attempt to operate the machine.

  • Page 5: Designation

     The mobile working scaffold can have Access Classes to the working decks according to the following list: o Type D access: Vertical ladder. 1.3. Manufacturer The manufacturer of the model TSA 320 mobile work platforms described in this Instruction Manual is: FARAONE INDUSTRIE Spa Tel: +39 0861 772221...

  • Page 6: Normative References

    Faraone Industrie Spa. with registered office in Tortoreto (TE) Zona Industriale Contrada Salino DECLARES:  That the mobile working scaffold named TSA 320 is constructed in accordance with the Consolidation Act on Health and Safety in the Workplace Lgs.Dec. 81/08;...

  • Page 7: Chapter 2 - Safety Instructions

    Keep this document carefully for further reference. Installation must be carried out in compliance with applicable regulations and in accordance with the manufacturer’s instructions. MOBILE SCAFFOLD TSA 320 – Rev 00 Page 7...
  • Page 8 (e.g. use of ballast weights and outriggers) are described in these user instructions and limits of use (Chapter 5). FIG. B FIG. B: Damaged components must not be used for the assembly of mobile working towers. MOBILE SCAFFOLD TSA 320 – Rev 00 Page 8...
  • Page 9 If the safety distances cannot be complied with, the lines must be de-energized and secured against re-energizing, in agreement with the owners or operators of the lines. Observe the indications in fig. P. MOBILE SCAFFOLD TSA 320 – Rev 00 Page 9...
  • Page 10 FIG. L: Before use, it must be ensured that all safety measures have been taken prevent accidental displacement, by using the appropriate wheel brakes and, if necessary, by using adjustable bases. MOBILE SCAFFOLD TSA 320 – Rev 00 Page 10...
  • Page 11 Only components supplied by the manufacturer should METRES be used as anchoring elements (refer to the instructions in this manual for their correct arrangement). MOBILE SCAFFOLD TSA 320 – Rev 00 Page 11...
  • Page 12 THE MAXIMUM HORIZONTAL LOAD THAT CAN BE APPLIED, FOR EXAMPLE AS A RESULT OF WORK BEING CARRIED OUT ON AN ADJACENT STRUCTURE, IS 25KG, WHICH IS THE SUM OF THE LOADS APPLIED BY THE VARIOUS OPERATORS ON THE SCAFFOLD. MOBILE SCAFFOLD TSA 320 – Rev 00 Page 12...

  • Page 13: Chapter 3 - Limits Of Use

    The total permissible load on the work surface is therefore 150 kg. 3.3. Maximum heights in different configurations The maximum height of the working surface without the use of bracing is, for all TSA 320 scaffold models, 3.8m. The maximum working surface height with the use of bracing is, for all TSA 320 scaffold models, 4.4m.

  • Page 14: Chapter 4 - Identification

    Use and maintenance manual Chapter 4 - IDENTIFICATION 4.1. Identification points Each TSA 320 mobile scaffold is identified by an adhesive label bearing the following information:  Manufacturer's website (1)  Manufacturer's logo (2)  Article code (3)  Article barcode (4) ...

  • Page 15: Chapter 5 - Mounting Configurations

    Chapter 5 - MOUNTING CONFIGURATIONS 5.1. Description of the system The TSA 320 mobile scaffold is a wheeled tower scaffold system, used only for finishing, maintenance or similar work. The system consists of two side towers on wheels, which have a hand-...

  • Page 16: Framework Of Models

    Working position 1: minimum height attainable by the operator REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 1436 WORK DECK HEIGHT 1618 SIDE HEIGHT 4187 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 16...
  • Page 17 Working position 2: maximum height attainable by the operator without bracing REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 3396 WORK DECK HEIGHT 3578 SIDE HEIGHT 4626 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 17...
  • Page 18 4236 WORK DECK HEIGHT 4418 SIDE HEIGHT 5466 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 Working position 4: maximum free height for climbing over the vehicle. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 18...
  • Page 19 GROUND 3557x1881 LANDING WIDTH 2401 Working position 5: height within which bracing is required for working operations, when the scaffold is used at the side of the vehicle. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 19...
  • Page 20 Use and maintenance manual REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 2556 WORK DECK HEIGHT 2738 SIDE HEIGHT 4187 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 LANDING WIDTH 2401 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 20...

  • Page 21: Component Elements: Tsa 320

    Use and maintenance manual 5.3. COMPONENT ELEMENTS: TSA 320 PARTS LIST ELEMENT PART NUMBER WORK DECK WITH RAILINGS BRACINGS KNOBS SLIDING CROSSBARS WINCH FIXED LADDER ON REMOVABLE BASE OUTRIGGER BASES ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 21...

  • Page 22: Work Deck With Railings

    Bracings must be mounted if work is being performed on one side of the scaffold, from a height above the ground of 2706 mm on up (see working position 5). ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 22...

  • Page 23: Knobs

    Ladder sliding system, anchored to the work deck and moved by means of a manually operated winch to move the work deck up or down. The sliding column is equipped with an auto-locking system for height adjustment of the work deck. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 23...

  • Page 24: Winch

    Use and maintenance manual 5.3.5. Winch 5.3.6. Outriggers The outrigger is the element that ensures the stability of the mobile scaffold during its operation. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 24...

  • Page 25: Chapter 6 - Assembly, Disassembly And Maintenance

    Use and maintenance manual Chapter 6 - ASSEMBLY, DISASSEMBLY AND MAINTENANCE ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 25...

  • Page 26: General Information

    Mounting operations can only begin when there is no wind; d) It must be verified that all components, any accessories, tools and safety equipment for erecting the scaffold are available on site. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 26...

  • Page 27: Product-Specific Assembly Instructions

    1)Insert the outrigger bases into the two guide bases as far as they will go on both sides (Fig.1). Fig.1: Insertion of outrigger bases 2) Secure the outrigger bases with the clamping pin (Fig.2). Fig.2: Locking of outrigger bases ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 27...
  • Page 28 Fig.3: Inserting the deck between the two sides Fig.4: Deck assembly Fig.5: Deck attachment plate detail 5) Mount the foot board strips (Fig.5a) on the side uprights using the appropriate screws ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 28...
  • Page 29 (Fig.6) and to the uprights of the vertical ladders (Fig.7) Fig.5b : Mounting the railings on the deck ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 29...
  • Page 30 (Fig.10). WARNING: Levelling must be carried out with the utmost care as any small deviations of the floor could lead to considerable vertical deviations. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 30...
  • Page 31 After reaching the place of use, lock the wheels by applying the brake levers and restore contact of the outrigger feet with the ground. If necessary, adjust the outrigger feet until the mobile scaffold is in a horizontal position. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 31...

  • Page 32: Use

    N.B. : THE WORK DECK LIFTING OPERATION MUST BE CARRIED OUT BY TWO PERSONS WORKING SIMULTANEOUSLY ON BOTH SIDES, TRYING TO KEEP THE ROTATION SPEED EQUAL AND AS CONSTANT AS POSSIBLE ON BOTH WINCHES. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 32...
  • Page 33 Fig.13: Access to the work deck N.B. : ACCESS TO THE DECK IS ONLY ALLOWED WHEN THE LOCKING DEVICE HAS GONE OVER THE RUNGS ON BOTH SIDES OF THE SCAFFOLD. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 33...

  • Page 34: Removal

    During transport to or from the storage location, the scaffold components must be secured against slipping, bumping and falling. The scaffold components must not be thrown away during loading. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 34...

  • Page 35: Scaffolds And Temporary Works

    The fall arrest device, the safety belt and the restraint rope must be of an approved type, and must have sections that can withstand the stresses resulting from a worker falling. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 35...
  • Page 36 Use and maintenance manual Chapter 7 - TSA 320 accessories Additional accessories to the TSA 320 are listed in the following attachments: Attachment 1: TSA 320.P pantograph Attachment 2: Cantilever deck TSA 320.SB Attachment 3: TSA 320.SP tipping deck Attachment 4: TSA 320.AN anchoring system Attachment 5: Access gate TSA 320.CN...
  • Page 37 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 37...
  • Page 38 Annex 1 - Pantograph for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a pantograph railing: TSA 320.P. It is a railing that can be attached to one side of the mobile scaffold and provides perimeter protection on top of the vehicle.
  • Page 39 REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 4234 WORK DECK HEIGHT 4414 LATERAL HEIGHT 5464 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 LANDING WIDTH 2401 PANTOGRAPH FOOTPRINT 2465X2500 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 39...
  • Page 40 Use and maintenance manual Assembly Instructions TSA 320.P on TSA 320 The coupling between the TSA 320.P and the TSA 320 is carried out before lifting the deck, by hooking the couplings on the TSA 320.P to the tubes of the deck’s railings.
  • Page 41 (Section 6.4 Step 2) to the height where the vehicle can be supported. Step 2 Climbing of the operator onto the work deck instructions given in the TSA 320 mobile scaffold use and maintenance manual (Section 6.4 Step 3).
  • Page 42 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 42...
  • Page 43 Use and maintenance manual Attachment 2 - Cantilever deck for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a cantilever deck. It is an additional deck segment to the standard work deck and is supplied as an element already incorporated into the work deck.
  • Page 44 Use and maintenance manual Substitute elements for TSA 320 1) Work deck with overhang 2)Outriggers ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 44...
  • Page 45 DIMENSIONS [mm] SUB-DECK HEIGHT 2556 WORK DECK HEIGHT 2739 SIDE HEIGHT 4193 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 LANDING WIDTH 1210 CANTILEVER DECK FOOTPRINT 1990X400 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 45...
  • Page 46 DIMENSIONS [mm] SUB-DECK HEIGHT 4236 WORK DECK HEIGHT 4419 SIDE HEIGHT 5466 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 LANDING WIDTH 1210 CANTILEVER DECK FOOTPRINT 1990X400 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 46...
  • Page 47 Use and maintenance manual Instructions for Use of TSA 320 mobile scaffold with cantilevered deck ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 47...
  • Page 48 (Section 6.4 Step 2) to the height that allows you to get off on the on the vehicle roof. Step 2 Climbing of the operator onto the work deck instructions given in the TSA 320 mobile scaffold use and maintenance manual (Section 6.4 Step 3). Step 3 Unhook the front railing of the cantilever deck in order to work on the vehicle.
  • Page 49 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 49...
  • Page 50 Attachment 3 - TSA 320.SP for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a Tipping Deck: TSA 320.SP It is an additional deck portion to the standard work deck that is supplied as an element that can be assembled.
  • Page 51 Use and maintenance manual REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 4236 WORK DECK HEIGHT 4419 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 3557x1881 LANDING WIDTH 2410 TIPPING DECK FOOTPRINT 2410X475 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 51...
  • Page 52 Use and maintenance manual Additional elements to TSA 320 1) Tipping Deck ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 52...
  • Page 53 Assembly Instructions TSA 320.SP on TSA 320 The assembly of the TSA320.SP Tipping Deck and the TSA 320 is carried out before lifting the work deck by first inserting the anchor plates to the tipping deck and then attaching them to the work deck of the TSA.320.
  • Page 54 Use and maintenance manual Operating Instructions for TSA 320 Mobile Scaffold with Tipping Deck TSA320.SP ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 54...
  • Page 55 (Section 6.4 Step 2) to the height that allows you to get off on the on the vehicle roof. Step 2 Climbing of the operator onto the work deck instructions given in the TSA 320 mobile scaffold use and maintenance manual (Section 6.4 Step 3). Step 3 Unhook and rotate the tipping deck by placing it on the vehicle until contact is made between the two.
  • Page 56 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 56...
  • Page 57 Use and maintenance manual Attachment 4 - TSA 320.AN for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a system for anchoring the scaffolding to the vehicle: TSA 320.AN. Required when the TSA exceeds 4 metres and the stabilising crossbars cannot be applied.
  • Page 58 Use and maintenance manual Additional elements to TSA 320 1)Anchoring system ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 58...
  • Page 59 Use and maintenance manual Assembly Instructions TSA 320.AN on TSA 320 Mounting the TSA320.AN Anchorage System to the TSA 320 is carried out before lifting the work deck by hooking it onto the steps of the TSA 320. ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00...
  • Page 60 Use and maintenance manual Mobile scaffold TSA 320 with anchorage system TSA320.AN operating instructions ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 60...
  • Page 61 Pass the belt under the truck axle and tension it by tightening it using the jack system on both sides. Step 3 Climbing of the operator onto the work deck instructions given in the TSA 320 mobile scaffold use and maintenance manual (Section 6.4 Step 3).
  • Page 62 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 62...
  • Page 63 Use and maintenance manual Attachment 5 -TSA 320.CN for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a gate to get on the deck: TSA 320.CN. This accessory is an alternative for accessing the deck using the classic hatch system.
  • Page 64 After the correct assembly of the foot board strips and railings according to the instructions in the TSA 320 mobile scaffold use and maintenance manual (Section 6.3 Step 5), secure the gate to the two adjacent railings by means of the appropriate ties.
  • Page 65 MOBILE SCAFFOLD TSA 320 This document is the property of Faraone Industrie Spa Any total or partial reproduction without written authorisation by the author or owner is forbidden ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 65...
  • Page 66 Use and maintenance manual Attachment 6 -TSA 320.SB50 for TSA 320 The TSA 320 MOBILE SCAFFOLD can be equipped with a cantilevered deck that can be reached via a telescopic ladder and access gate: TSA 320.SB50. This accessory may only be used as an alternative access to the main work deck.
  • Page 67 Use and maintenance manual REFERENCES DIMENSIONS [mm] SUB-DECK HEIGHT 4236 WORK DECK HEIGHT 4419 DECK LENGTH 3155 OVERALL DIMENSIONS ON THE GROUND 4526x2079 CANTILEVER DECK FOOTPRINT 3125X575 ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 67...
  • Page 68 After the correct assembly of the foot board strips and railings according to the instructions in the TSA 320 mobile scaffold use and maintenance manual (Section 6.3 Step 5), follow the steps below: 1) Mounting of foot board strips on SB50 landing surface...
  • Page 69 Use and maintenance manual 4) Assembly of the cantilever deck on the mobile scaffold Fixing plate ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 69...
  • Page 70 Use and maintenance manual 5) Mounting of reinforcement crossbars: mount crossbars using the dedicated plates 6) Attach the adjustable ladder ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 70...
  • Page 71 Use and maintenance manual Attachment 3 - Operations and repair sheet Date Operation description Technician signature ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 71...
  • Page 72 Use and maintenance manual Date Operation description Technician signature ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 72...
  • Page 73 Use and maintenance manual Notes ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 73...
  • Page 74 Use and maintenance manual Notes ATTACHMENT 3 - TSA 320 MOBILE SCAFFOLD - Rev 00 Page 74...
  • Page 75 Faraone Industrie Spa Contrada Salino – Via San Giovanni, 20 64018, Tortoreto (TE) – ITALY Tel.:+39.0861.77.22.21 – fax: +39.0861.77.22.22 www.faraone.com info@faraone.com...
