- Page 1 Sortimo International GmbH Dreilindenstrasse 5 86441 Zusmarshausen, Germany direct@sortimo.de en -Instructions for use Side profile extension ProClick SR5 accessories GA 00037 / 2023.02.07 / Rev.0 / en...
-
Page 2: Table Of Contents
Requirements for the user ....................... 5 Maintenance and care .......................... 5 Note on the adapter ..........................5 ProClick SR5 accessories for the side profile ..................6 ProClick Paper Towel Dispenser ..................... 6 ProClick Storage Pocket Insetbox H95 .................... 6 ProClick C-BOXX Holder ......................... 7 ProClick Hose Holder ........................ -
Page 3: Preface
Do you have questions about the product? You can find your personal contact on our website. Intended use The ProClick system is used to tidily store and transport tools and consumables. It is primarily designed for mobile use. © Sortimo International GmbH... -
Page 4: Foreseeable Misuse
▶ When using, make sure that all tools and consumables are held securely in place. ▶ Danger from falling objects ▶ Pay attention to the information in the handbook and in the vehicle documentation regarding: Maximum permissible axle load, Maximum permissible total weight. © Sortimo International GmbH... -
Page 5: Requirements For The User
Accessories with heavy adapter plate: 25 kg C-BOXX holder: 20 kg ProClick Tool bags: 5 kg ProClick battery holder: 1 kg Note: Accessories with a “light” adapter plate are secured in place by engaging the “position anchor” in the ProSafe hole. © Sortimo International GmbH... -
Page 6: Proclick Sr5 Accessories For The Side Profile
Accessories with a “heavy” adapter plate and “C-BOXX holder” are secured in place with a screw! Note: ProClick “Tool bags” are secured by hanging the hook in the ProSafe hole! ProClick SR5 accessories for the side profile ProClick Paper Towel Dispenser Ref. No. 1000018385... -
Page 7: Proclick C-Boxx Holder
ProClick C-BOXX Holder Ref. No. 1000018390 Load capacity: 20 kg ProClick Hose Holder Ref. No. 1000018391 Load capacity: 25 kg / 8 kg per single hook ProClick Threaded Bolt Holder Ref. No. 1000018389 Load capacity: 25 kg © Sortimo International GmbH... -
Page 8: Proclick Plaster Dispenser
ProClick Plaster Dispenser Ref. No. 6000013925 ProClick Silicone Cartridge Holder Ref. No. 1000018387 Load capacity: 5 kg ProClick Aerosol Can Holder Ref. No. 1000018388 Load capacity: 5 kg © Sortimo International GmbH... -
Page 9: Office Organiser
Office Organiser Ref. No. 6000013636 Load capacity: 5 kg ProClick Disinfectant Dispenser Ref. No. 1000018631 © Sortimo International GmbH... -
Page 10: Proclick Tool Bags
ProClick Tool Bags ProClick Tool Bag M 14 Ref. No. 6000013928 Maximum load: 5 kg ProClick Nail Bag M Ref. No. 6000013929 Maximum load: 5 kg ProClick Tool Bag L 16 Ref. No. 6000013930 Maximum load: 5 kg © Sortimo International GmbH... -
Page 11: Proclick Tool Bag L 36
ProClick Tool Bag L 36 Ref. No. 6000013931 Maximum load: 5 kg ProClick Tool Bag L 39 Ref. No. 6000013932 Maximum load: 5 kg ProClick Tool Card S 6 Ref. No. 6000015240 Maximum load: 5 kg © Sortimo International GmbH... -
Page 12: Proclick Hammer Holder S
ProClick Hammer Holder S Ref. No. 6000015241 Maximum load: 5 kg ProClick Equipment Bag S Ref. No. 6000015242 Maximum load: 5 kg ProClick Battery Holder Ref. No. 6000013935 Maximum load: 1 kg © Sortimo International GmbH...
