- Page 1 NSTALLATION UIDE YPERION ASTER ECURITY NCLOSURE HYP-MSEWEN-W Hyperion MSE Installation Guide www.wrensolutions.com 7L580 Rev A 190707...
-
Page 2: Product Support
RADEMARK CKNOWLEDGMENTS Wren®. the Wren logo, Hyperion® and the Hyperion logo are trademarks of Wren. The trademarks that are followed by ® are registered trademarks in the U.S. All other trademarks and/or registered trademarks mentioned herein are properties of their respective owners and are for reference purposes only. -
Page 3: Before Beginning Installation
OU ARE ONLY USING THE YPERION POWER SUPPLY • OU HAVE TESTED AND CERTIFIED CABLE CONNECTIONS • T -568B FOR PROPER PINOUT ALIGNMENT PER STANDARD MPROPER CABLING COULD DAMAGE THE GATEWAY AND VOID PRODUCT WARRANTY Hyperion MSE Installation Guide www.wrensolutions.com 7L580 Rev A 190707... -
Page 4: Tools And Accessories
Insert the sleeve anchor through the fixture into the hole in the wall until the washer and nut are tight • against the mounting plate. Turn the nut until finger tight then use a wrench to set the anchor by turning the nut three to four full • turns. Hyperion MSE Installation Guide www.wrensolutions.com 7L580 Rev A 190707... -
Page 5: Hook Installation
Refer to the masonry sleeve anchor instructions in this document for proper installation of anchors. Install the Anchors REP THE WALL FOR MOUNTING Hang the MSE on the Mounting hook. Mark all four anchor locations and the cable entry location. Hyperion MSE Installation Guide www.wrensolutions.com 7L580 Rev A 190707... - Page 6 Install the anchors per the instructions provided in this document. Drill a 3/4” cable entry hole in the marked location. OUNT THE MSE Hang the MSE on the hanger and secure the device to all four installed anchors. Hyperion MSE Installation Guide www.wrensolutions.com 7L580 Rev A 190707...
- Page 7 ABLES RUNS SHOULD NOT EXCEED FEET Before connecting cables from devices, refer to the Gateway Configuration Plan to ensure Hyperion devices are plugged into their respective ports. For Gateways that were not factory-configured, please complete the Gateway Configuration Plan before making any connections.
- Page 8 ABLES RUNS SHOULD NOT EXCEED FEET Before connecting cables from devices, refer to the Gateway Configuration Plan to ensure Hyperion devices are plugged into their respective ports. For Gateways that were not factory-configured, please complete the Gateway Configuration Plan before making any connections.
