Page 1: Dc Cable With Ø5.5 Plug (Approx. 3 Meters [9.9 Ft.]) [Model No. Veeb0115A]
Operating Instructions AC Adaptor AW-PS551PJ Model No. Before operating this product, please read the instructions carefully and save this manual for future use. Please carefully read the “Read this first!” (P.2 to 3) of this Manual before use. ENGLISH FJ1215KT0 -PS... - Page 2 Read this first! WARNING: CAUTION • To reduce the risk of fire or electric shock, do not RISK OF ELECTRIC SHOCK expose this equipment to rain or moisture. DO NOT OPEN • To reduce the risk of fire or electric shock, keep CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, this equipment away from all liquids.
- Page 3 Read this first! FCC NOTICE (USA) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Table Of Contents
Contents Accessories ................4 Troubleshooting ...............10 Overview ................5 Appearance ...............11 Precautions .................6 Specifications ............Back cover Parts and their functions ...........7 Connections ................7 Accessories Power cable ................ 1 DC cable with ø5.5 plug (approx. 3 meters [9.9 ft.]) [Model No. VEEB0115A] <UL Style 2464 2 x 18 AWG> ... 1 DC cable with ø6.5 plug (approx. -
Page 5: Overview
Overview This AC adaptor is designed to be used with convertible cameras and their peripherals, with multi-purpose cameras and their peripherals, and with live switchers. How to identify the cables • DC cable with ø5.5 plug • DC cable with ø6.5 plug <Background color : Blue / Font color : White>... -
Page 6: Precautions
Precautions Be sure to confirm the polarity display of the apparatus to connect. Use the DC cable that meets the DC input polarity display of the apparatus to connect. • This AC adaptor cannot be connected in series or in •... -
Page 7: Parts And Their Functions
Parts and their functions Power connector Connect the power cable supplied with the unit. DC 12 V output connector [12V OUT] (4-pin round connector) Connect one end of the supplied DC cable to this connector and the other end to the DC 12 V input connector [DC 12 V IN] on the convertible camera and its peripherals, on the multi- purpose camera and its peripherals or on the live switcher. -
Page 8: Power Cable
Connections AC adaptor AW-PS551PJ Power cable Compatible equipment: Convertible cameras, AK-HC1500, AW-SW350, etc. DC cable with ø6.5 plug [Model No. VEEB0116A] Compatible equipment: AW-RP555, AW-RC400, AW-IF400, AW-DU600, etc. DC cable with ø5.5 plug [Model No. VEEB0115A] Compatible equipment: AW-RP655, AW-RP400,... - Page 9 Connections AC adaptor AW-PS551PJ Power cable Indoor Pan-tilt Head: AW-PH360 DC cable side: Black (supplied with the AW-PH360) side: Red Depending on the time of manufacture, a DC cable may not have been supplied with the AW-PH360. For details, consult your dealer.
-
Page 10: Troubleshooting
Troubleshooting Symptom Cause and remedial action If a unit whose output exceeds the rating has been connected or the The DC 12 V voltage is not output connected unit is short-circuited, the DC 12 V voltage will not be output properly. -
Page 11: Appearance
Appearance Unit : mm (inch) 115 (4-1/2) Cable length: Approx. 780 (30-11/16) -
Page 12: Specifications
Mass and dimensions shown are approximate. The provided power cable is for 125 V AC or less. Specifications are subject to change without notice. Use it within AC 100 V to 120 V. Web Site: http://www.panasonic.com © Panasonic Corporation 2015...
