Optoma ZW410UST User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DLP
Projector
®
User manual

Advertisement

Table of Contents
loading

Related Manuals for Optoma ZW410UST

Summary of Contents for Optoma ZW410UST

  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ....................4 Important Safety Instruction....................... 4 Laser Radiation Safety Information ................... 5 Laser Notice ..........................6 Copyright ........................... 7 Disclaimer ..........................7 Trademark Recognition ......................7 FCC ............................7 Declaration of Conformity for EU countries ................8 WEEE ............................
  • Page 3 Compatible resolutions ......................54 Image size and projection distance ..................58 Projector dimensions and ceiling mount installation ..............60 IR remote control codes ......................62 Troubleshooting ........................64 Warning indicators ........................66 Specifications ........................... 67 Optoma global offices ....................... 68 English...

  • Page 4: Safety

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 5: Laser Radiation Safety Information

    ‡ When switching the projector off, please ensure the cooling cycle has been completed before disconnecting power. Allow 90 seconds for the projector to cool down. ‡ Turn off and unplug the power plug from the AC outlet before cleaning the product. ‡...

  • Page 6: Laser Notice

    ‡ Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation. ‡ Do not stare into beam when the projector is on. The bright light may result in permanent eye damage. Not following the control, adjustment or operation procedure may cause damage by the the exposure of laser radiation.

  • Page 7: Copyright

    Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2023 Disclaimer The information in this document is subject to change without notice.

  • Page 8: Declaration Of Conformity For Eu Countries

    Operation Conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003.

  • Page 9: Introduction

    INTRODUCTION Thank you for purchasing an Optoma laser projector. For full list of features please visit the product page on our website, where you will also find additional information and documentation such as FAQs. Package Overview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase.

  • Page 10: Product Overview

    INTRODUCTION Product Overview Note: ‡ Do not block projector intake and exhaust vents. ‡ When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake and exhaust vents. Item Item IR Receivers Ventilation (outlet) Keypad Lens Focus Lever...

  • Page 11: Connections

    INTRODUCTION Connections WXGA model 1080p model Item Item HDMI 1 Connector DC Jack HDMI 2 Connector Kensington Lock Port RS-232 Connector RJ-45 Connector USB Power Out (5V 1.5A) Connector 3D SYNC Out (5V, 0.75A) Connector* Audio Out Connector Note: ‡ Signal mode support varies from different model in each sales region.

  • Page 12: Keypad

    INTRODUCTION Keypad Item Item Information Power, Power LED, and IR Receiver Menu Temp LED Keystone Correction Lamp LED Re-Sync Four Directional Select Keys Enter 10. Source English...

  • Page 13: Remote Control

    INTRODUCTION Remote control Item Item Aspect Ratio Freeze Power On / Off AV Mute Mode 11. Volume + Enter Menu Return 13. Four Directional Select Keys Mute 14. Settings/Setup Menu Volume - 15. Source Keystone Correction Note: ‡ Some keys may have no function for models that do not support these features. ‡...

  • Page 14: Setup And Installation

    SETUP AND INSTALLATION Installing the projector Your projector is designed to be installed in one of four possible positions. Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.
  • Page 15 SETUP AND INSTALLATION Projector installation notice ‡ 360° free orientation operation ‡ Allow at least 30 cm clearance around the exhaust vent. Minimum 100mm Minimum 300mm Minimum 300mm (3.94 inches) (11.81 inches) (11.81 inches) Minimum 100mm Minimum 100mm (3.94 inches) (3.94 inches) ‡...

  • Page 16: Connecting Sources To The Projector

    SETUP AND INSTALLATION Connecting sources to the projector Item Item HDMI Cable Power Cable HDMI Dongle RS232 Cable USB Power Cable RJ-45 Cable Audio Out Cable 3D Emitter Cable* Power Adapter Note: ‡ To ensure the best image quality and avoid connection errors, we recommend the use of High Speed or Premium Certified HDMI cables up to 5 meters.

  • Page 17: Adjusting The Projector Image

    SETUP AND INSTALLATION Adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Focus...

  • Page 18: Remote Setup

    SETUP AND INSTALLATION Remote setup Installing / replacing the batteries Press firmly and slide the battery cover off. Install new battery into the compartment. Remove the old battery and install new one (CR2025). Ensure that the side with a “+” is facing Put the cover back.
  • Page 19 SETUP AND INSTALLATION Effective range Infra-Red (IR) remote control sensor is located on the top and front sides of the projector. Ensure that the remote control is held at an angle 30 degrees perpendicular to the projector’s IR remote control sensor to ensure correct functionality.

  • Page 20: Using The Projector

    USING THE PROJECTOR Powering on / off the projector Powering on Securely connect the power lead and signal/source cable. When connected, the Power LED starts breathing red. Turn on the projector by pressing the button on the projector keypad or the button on the remote control.

  • Page 21: Selecting An Input Source

    USING THE PROJECTOR Selecting an input source Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, etc. The projector will automatically detect the source. If multiple sources are connected, press the button on the projector keypad or remote control to select the desired input.

  • Page 22: Menu Navigation And Features

    USING THE PROJECTOR Menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press the button on the projector keypad or remote control.

  • Page 23: Osd Menu Tree

    USING THE PROJECTOR OSD Menu tree Note: The OSD menu tree items and features are subject to models and region. Optoma reserve the right to add or remove items to improve product performance without notice. Main Sub Menu Sub Menu 2...
  • Page 24 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Blackboard Light Yellow Wall Color Light Green Light Blue Pink Grey 3D Mode DLP-Link 3D Sync Type 3D Sync Image 3D-2D Conversion Auto 3D Format Top and Bottom Frame Sequential...
  • Page 25 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu -5 ~ 5 V Keystone H Keystone -5 ~ 5 Geometric Correction Four Corners Reset -5 ~ 25 Digital Zoom Zoom Display -100 ~ 100 -100 ~ 100 Image Shift Reset...
  • Page 26 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Top left Top right Menu Location Center Bottom left Bottom right Menu Settings Menu Timer Information Hide High Altitude Filter Usage (read only) Hours Optional Filter Installed...
  • Page 27 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu None Blue Background Color Green Grey Setup Logo Reset OSD Reset Reset to Default Auto Source Auto Input Switch HDMI Link Inclusive of TV Input HDMI CEC Mutual...
  • Page 28 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Crestron (Port 41794) Extron (Port 2023) PJ Link (Port 4352) Control AMX Device Control Discovery (Port 9131) Telnet (Port 23) HTTP (Port 80) Reset Regulatory Serial Number...

  • Page 29: Image Picture Mode Menu

    USING THE PROJECTOR Image menu Image picture mode menu There are several predefined display modes that you can choose from to suit your viewing preference. Each mode has been fine-tuned by our expert colour team to ensure superior colour performance for wide range of content. Vivid: Selecting this mode balances colour saturation and brightness for a brighter display.

  • Page 30: Image Contrast Menu

    USING THE PROJECTOR Image brightness menu Adjust the brightness of the image. Image contrast menu The contrast controls the degree of difference between the lightest and darkest parts of the picture. Image sharpness menu Adjust the sharpness of the image. Image gamma menu Set up gamma curve type.

  • Page 31: Image 3D Menu

    USING THE PROJECTOR Image 3D menu Note: ‡ This projector is a 3D ready projector with DLP-Link 3D solution. ‡ Please ensure that 3D glasses are in use for DLP-Link 3D content before enjoying your video. ‡ This projector supports frame sequential (page-flip) 3D via HDMI1/HDMI2 ports. ‡...

  • Page 32: Display Projection Orientation Menu

    USING THE PROJECTOR Display menu Display projection orientation menu Select the preferred projection between front, rear, ceiling-top, and rear-top. Display light source mode menu Select a light source mode depending on the installation requirements. Display dynamic black menu Use to automatically adjust the picture brightness in order to give optimum contrast performance. Display gaming mode menu Enable this feature to reduce response times (input latency) during gaming to 8.6ms (1080p@120Hz).

  • Page 33: Display Aspect Ratio Menu

    USING THE PROJECTOR Display aspect ratio menu Select the aspect ratio of the displayed image between the following options: 4:3: This format is for 4:3 input sources. ‡ 16:9: This format is for 16:9 input sources, like HDTV and DVD enhanced for Wide screen TV. ‡...
  • Page 34 USING THE PROJECTOR WXGA scaling table (screen type 16:9): 16 : 9 screen 480i/p 576i/p 1080i/p 720p Scale to 960x720 16:9 Scale to 1280x720 21:9 Scale to 1280x548 Native mode 1:1 mapping centered. 1:1 mapping 1280x720 1:1 mapping display centered. centred.
  • Page 35 USING THE PROJECTOR 1080p scaling table: 16:9 screen 480i/p 576i/p 1080i/p 720p Scale to 1440x1080 16x9 Scale to 1920x1080 21:9 Scale to 1920x822 Native mode - 1:1 mapping centered. - No scaling will be made; the image is displayed with the resolution based on input source. Auto - If auto format is selected, the screen type will automatically become 16:9 (1920x1080).

  • Page 36: Display Geometric Correction Menu

    USING THE PROJECTOR Display geometric correction menu V Keystone Adjust image distortion vertically and make a squarer image. Vertical keystone is used to correct a keystoned image shape in which the top and bottom are slanted to one of the sides. This is intended for use with vertically on-axis applications.

  • Page 37: Setup Test Pattern Menu

    USING THE PROJECTOR Setup menu Setup test pattern menu Select the test pattern from green grid, magenta grid, white grid, white, or disable this function (off). Setup language menu Select the multilingual OSD menu between English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Swedish, Norwegian, Danish, Finnish, Greek, Traditional Chinese, Simplified Chinese, Japanese, Korean, Russian, Hungarian, Czechoslovak, Arabic, Thai, Turkish, Farsi, Vietnamese, Indonesian, and Romanian.

  • Page 38: Setup Power Settings Menu

    USING THE PROJECTOR Setup power settings menu Direct Power On Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “Power” key on the projector keypad or on the remote control. Signal Power On Choose “On”...

  • Page 39: Setup Startup Logo Menu

    USING THE PROJECTOR Setup startup logo menu Logo Use this function to set the desired startup screen. If changes are made, they will take effect the next time the projector is powered on. ‡ Default: The default startup screen. Neutral: Logo is not displayed on startup screen. ‡...

  • Page 40: Input Auto Source Menu

    USING THE PROJECTOR Input menu Input auto source menu Choose this option to let the projector automatically find an available input source. Input auto input switch menu When HDMI input signal is detected, the projector will automatically switch the input source. Input HDMI CEC settings menu Note: When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them...

  • Page 41: Audio Volume Menu

    USING THE PROJECTOR Audio menu Audio volume menu Adjust the volume level. Audio mute menu Use this option to temporarily turn off the sound. ‡ On: Choose “On” to turn mute on. ‡ Off: Choose “Off” to turn mute off. Note: “Mute”...

  • Page 42: Control Device Id Menu

    USING THE PROJECTOR Control menu Control device ID menu ID definition can be set up by menu (range 0-99), and allow user control an individual projector by using RS232 command. Note: For a full list of RS232 commands, please refer to the RS232 user manual on our website. Control remote settings menu IR Function Set the IR function setting.
  • Page 43 USING THE PROJECTOR How to use web browser to control your projector How to use web browser to control your projector Turn “On” the DHCP option on projector to allow a DHCP server to automatically assign an IP address. Open the web browser in your PC and type in the projector’s IP address (“Control >...

  • Page 44: Control Control Menu

    USING THE PROJECTOR Control control menu This projector can be controlled remotely by a computer or other external devices through the wired network connection. It allows the user to control one or more projectors from a remote control center, such as powering the projector on or off, and adjusting the image brightness or contrast.

  • Page 45: Setup Network Control Settings Menu

    USING THE PROJECTOR Setup network control settings menu LAN_RJ45 function For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN / RJ45 function of the projector through a network, such as remotely manage: Power On / Off, brightness, and contrast settings.
  • Page 46 USING THE PROJECTOR LAN RJ45 Connect an RJ45 cable to RJ45 ports on the projector and the PC (laptop). On the PC (Laptop), select Start > Settings > Network & Internet. In the Ethernet section, select Properties. In the IP settings section, select Edit. English...
  • Page 47 USING THE PROJECTOR Type in the IP address and Gateway, then select “Save”. Press the “Menu” button on the projector. Open on projector Control > LAN. Enter the following connection parameters: ± DHCP: Off ± IP Address: 192.168.0.100 ± Subnet Mask: 255.255.255.0 ±...
  • Page 48 USING THE PROJECTOR The projector is setup for remote management. The LAN / RJ45 function displays as follows: Log in When you open the web page for the first time, you will see a screen like the one below. Please enter valid user password. When you open the web page after entering a valid password, you will see a screen like the one below.
  • Page 49 USING THE PROJECTOR System Status The current status of the projector is displayed.You can check projector model name, firmware version, current LAN configuration, and change the interface language if needed. The version name displayed on the web page in the diagram may differ from the actual display. General Setup The projector name set here is also used in PJLink control.Only alphanumeric characters can be used as projector name.
  • Page 50 USING THE PROJECTOR Projector Control You can control the projector with this item. The items for control are described in this section. Control button: When you click a button, the corresponding function will be performed. Network Setup Set the network of the projector. English...
  • Page 51 USING THE PROJECTOR Alert Setup You can send email alerts when an error occurs. You can carry out settings for alert mail in this section. 1. Alert types: Check the type of error for which you want to send alert mail. 2.

  • Page 52: Control Reset Menu

    Telnet connection should be ready for RS232 command control. Specification for “RS232 by TELNET”: Telnet: TCP. Telnet port: 23 (for further details, please contact the Optoma service team). Telnet utility: Windows “TELNET.exe” (console mode). To end the Telnet session, just close the Command Prompt app window.

  • Page 53: Information Menu

    USING THE PROJECTOR Information menu Information menu View the projector information as listed below: ‡ Regulatory ‡ Serial Number ‡ Source ‡ Color Info ‡ Light Source Hours ‡ Picture Mode ‡ Device ID ‡ Filter Usage Hours ‡ Light Source Mode ‡...

  • Page 54: Additional Information

    ADDITIONAL INFORMATION Compatible resolutions Input Signal for HDMI Signal Resolution Refresh Rate(Hz) Notes for Mac 60/67/72/75 Mac 60/72 SVGA 56/60(*1)/72/75 Mac 60/72 1024 60(*1)/70/120(*1) Mac 60/70/75/85 SDTV(480I) SDTV(480P) SDTV(576I) SDTV(576P) HDTV(720p) 1280 50(*1)/60/120(*1) Mac 60 WXGA 1280 60/120 Mac 60 WXGA(*2) 1366 1280...
  • Page 55 ADDITIONAL INFORMATION True 3D Video Compatibility Input timing 1280 x 720P @ 50Hz Top-and-Bottom 1280 x 720P @ 60Hz Top-and-Bottom 1280 x 720P @ 50Hz Frame packing HDMI 1.4a 1280 x 720P @ 60Hz Frame packing 3D Input 1920 x 1080i @ 50Hz Side-by-Side(Half) 1920 x 1080i @ 60Hz Side-by-Side(Half)
  • Page 56 ADDITIONAL INFORMATION EDID (Digital) WXGA B0 / B0 / B0 / B1 / B1 / Established Timing Standard Timing Detail Timing Video Mode Detail Timing 720 x 400 @70Hz 1024 x 768 @120Hz Native timing: 640 x 480p 4:3 @60Hz 1366 x 768 @60Hz 640 x 480 @60Hz 1280 x 720 @60Hz...
  • Page 57 ADDITIONAL INFORMATION 1080p B0 / B0 / B0 / B1 / B1 / Established Timing Standard Timing Detail Timing Video Mode Detail Timing 4096 x 2160p 256:135@25Hz 4096 x 2160p 256:135@30Hz 4096 x 2160p 256:135@50Hz 4096 x 2160p 256:135@60Hz English...

  • Page 58: Image Size And Projection Distance

    ADDITIONAL INFORMATION Image size and projection distance WXGA model Image Size (W x H) DF (±5%) DR (±13%) Offset= 121% ~ 131% Image Size (inch) Width Height Width Height inch inch inch (inch) (inch) 85" 1.83 1.14 72.08 45.05 0.54 21.30 0.21 8.39...
  • Page 59 ADDITIONAL INFORMATION 1080p model Image Size (W x H) DF (±5%) DR (±14%) Offset= 121% ~ 131% Image Size (inch) Width Height Width Height inch inch inch (inch) (inch) 85" 1.77 69.73 39.22 0.53 20.87 0.20 7.96 0.105 ~ 0.211 4.125 ~ 8.292 90"...

  • Page 60: Projector Dimensions And Ceiling Mount Installation

    ADDITIONAL INFORMATION Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...
  • Page 61 ADDITIONAL INFORMATION For ceiling mounting, you could purchase a Hook & Loop whose length is over 250mm to fix the AC adapter if needed. Install the Hook & Loop to the designated holes on the bottom of the projector. Holes for Hook &...

  • Page 62: Ir Remote Control Codes

    ADDITIONAL INFORMATION IR remote control codes Customer Code Key Code Description format Byte 1 Byte 2 Byte 3 Byte 4 Power Format 1 Press to turn on / off the projector. Press to change the aspect ratio of a Aspect ratio Format 1 displayed image.
  • Page 63 ADDITIONAL INFORMATION Customer Code Key Code Description format Byte 1 Byte 2 Byte 3 Byte 4 Press to momentarily turn off / on the Mute Format 1 audio. Volume + Format 2 Press to increase the volume. Freeze Format 1 Press to freeze the projector image.

  • Page 64: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...
  • Page 65 ADDITIONAL INFORMATION Other problems The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Remote control problems If the remote control does not work ‡...

  • Page 66: Warning Indicators

    ADDITIONAL INFORMATION Warning indicators When the warning indicators (see below) light up or flash, the projector will automatically shutdown: ‡ “Lamp” LED indicator is lit red and if “Power” indicator flashes red. ‡ “Temp” LED indicator is lit red and if “Power” indicator flashes red. This indicates the projector has overheated.

  • Page 67: Specifications

    ADDITIONAL INFORMATION Specifications Item Description ‡ WXGA: 1280 x 800 Native Resolution ‡ 1080p: 1920 1080 ‡ WXGA: 0.266 Throw ratio ‡ 1080p: 0.253 ‡ WXGA: 2.44 Lens F-stop ‡ 1080p: 2.44 ‡ WXGA: -3.70mm / e-line 546nm Focal length ‡...

  • Page 68: Optoma Global Offices

    ADDITIONAL INFORMATION Optoma global offices For service or support, please contact your local office. Japan Optoma Technology, Inc. 888-289-6786 https://www.optoma.com/jp/ 47697 Westinghouse Drive. 510-996-4794 Fremont, Ca 94539 services@optoma.com Taiwan https://www.optoma.com/tw/ Canada Optoma Technology, Inc. 888-289-6786 China 47697 Westinghouse Drive. 510-996-4794...
  • Page 69 www.optoma.com...
