ASSEMBLY AND MOUNTING INSTRUCTIONS
PLEASE READ THE ASSEMBLY INSTRUCTION SHEET CAREFULLY BEFORE PROCEEDING. Carefully unpack
and identify all parts prior to building the unit. Each part is identified on the drawing for reference.
DO NOT DISCARD THE ORIGINAL PACKAGING. If after careful inspection, you must return the item for any
reason. Please repack the unit using the original carton and inserts.
STEP 1: Unpack all the parts and classify them
according to the illustration shown. Place the
parts on a scratch free surface.
STEP 2: Install the glass panels into the body
and fix it using the clips.
STEP 3: Install the correct bulb (provided).
STEP 4: Secure the bracket to the fame using
the screw. Twist the nipple into the bracket.
STEP 5: Attach the cover to the frame and
secure them with the loop.
STEP 6: Make sure the power is turned off at
the main power cable where the fixture is to
be installed. Use the wire nuts to connect the
positive and neutral wires, connect the ground
wire to the junction box ground port.
STEP 7: Secure the fixture to the post fitter
using the screws.
Turn on the power at fuse or circuit box.
CAUTION:
To reduce the risk of fire, use the specified lamp wattage (or smaller) and bulb type identified on the product.
CLEANING INSTRUCTIONS:
Do not use polish or cleaners on your product. Just wipe clean with a soft cloth.
CAUTION – RISK OF FIRE
This product requires installation by a qualified electrician. Before installing be sure to read all instructions
and TURN THE POWER TO THE ELECTRICAL JUNCTION BOX OFF.
ITEM NO: 60-5835
ITEM NO: 60-5835
ARTÍCULO Nº: 60-5835
ARTICLE N°: 60-5835
