- Page 1 EXPLORE 2 Touch Screen QSG-Quick Setup Guide English Deutsch Nederlands Français Español Product Quick Setup Guide - Version 1.0...
- Page 2 QUICK SETUP GUIDE EXP-XX10 1. INCLUDED WITH THE SCREEN 2. INSTALLATION 2.1 PRECAUTIONS ON INSTALLATION For the wall mount installation please make sure that two professional installers are available. Netto weight 39kg/ 49kg/ 61kg. During installation make sure the wall mount is installed on to a firm wall and not on plaster or any other material that is not properly reinforced.
- Page 3 QUICK SETUP GUIDE EXP-XX10 MOUNTING 2.3 INSTALLATION PROCEDURE M8 Screws Mounting Holes Four M8 screws corresponding to the size of the VESA holes are used to lock the two vertical bar hangers on the VESA mounting holes on the touch screen’s back plate.
- Page 4 QUICK SETUP GUIDE EXP-XX10 3. INPUT / OUTPUT CONNECTOR INFORMATION Minijack 3,5 Stereo (x1 in + x1 Out) USB-A 2.0 (x1) / USB-A 3.0 (x5) RS-232 (Serial) USB-B 2.0 (x2) (Touch) HDMI 2.0 (x3) USB-C 3.1 (x1) (DP 1.2 + 65W) 4.
