- Page 2 Model: Anycool-66 Version: V1.0 Code: R33010845 Shenzhen Megmeet Welding Technology Co., Ltd. provide customers with a comprehensive technical support. Users can contact with local distributors or Megmeet Service Center in Shenzhen headquarters. Shenzhen Megmeet Welding Technology Co.,Ltd Address:3rd Floor, Block C Unisplendour Information Harbor,Langshan Road, Shenzhen, Guangdong, 518057, China www.megmeet.com...
- Page 3 Preface Preface Thank you for purchasing water cooling unit AnyCool-66 (hereinafter referred to as water cooler) produced by Shenzhen Megmeet Welding Technology Co., Ltd. This manual stipulates installation guidance, operation and routine maintenance precautions. Please read this user manual carefully before installing, so as to ensure correct installation and operation, and give full play to its superior performance.
- Page 4 Do not operate the water cooler in the process of handling. Otherwise falling may result in personal injury or property damage. Do not install near water pipes or other places where water droplets may splash. Otherwise it User Manual of Water Cooling Unit Anycool-66...
- Page 5 Only personnel with safe operation knowledge and welding skill can perform welding to ensure safety. The water cooler shall not be used for any purpose other than connecting with Megmeet welding power source. Installation, debugging and maintenance of water cooler must be performed by professionals.
- Page 6 Safety Precautions The electrolytic capacitor on water pump may explode in the process of incineration. Toxic gas will generate when plastic parts are burned. Please handle it as industrial solid waste. User Manual of Water Cooling Unit Anycool-66...
-
Page 7: Table Of Contents
3.5 About Coolant .................................... 9 Chapter 4 Maintenance and Troubleshooting ............................10 4.1 Routine Inspection ..................................10 4.2 Regular Inspection and Maintenance ............................10 4.3 Troubleshooting ..................................11 4.4 After-sales Service ................................... 11 Appendix I Structure Diagram ................................13 User Manual of Water Cooling Unit Anycool-66... -
Page 8: Chapter 1 Product Overview
Chapter 1 Product Overview 1.1 Product Introduction AnyCool-100 is original water cooler of MEGMEET welding power source, which is used for cooling-water welding torch and controlled by the microprocessor of welding power source. It is suitable for Megmeet Dex 315/350/400/500 series. -
Page 9: Technical Specification
380Vac / 50Hz Power of water pump 260W Cooling power 1.5KW Maximum start-up 0.38MPa pressure Cooling liquid Pure water (environment temperature > 0℃)/all-organic coolant Technical MAX 6.8L specification EMC classification IEC 60974:10（Class A） User Manual of Water Cooling Unit Anycool-66... -
Page 10: Chapter 2 Installation And Wiring
After unpacking, please confirm whether all parts of welding power source are complete and whether the model are consistent with the contract order. In case of missing or wrong parts, please contact with Megmeet in time. 2.2 Installation Requirements Environmental Requirements When selecting an installation environment, pay attention to the following matters: ... -
Page 11: Electrical Connection
Figure 2-2 Power connection diagram of water cooler Pipe connection of water cooler Step Insert water inlet and outlet pipes of combined cable into the water inlet and outlet pipes of water cooler, as shown in Figure 2-3. User Manual of Water Cooling Unit Anycool-66... - Page 12 4．Please use pure water or all-organic antifreeze. Otherwise, it may damage the water cooler; 5．The cooling liquid in kettle must be kept above the lowest water level scale. User Manual of Water Cooling Unit Anycool-66...
-
Page 13: Chapter 3 Function Description And Operation
1．If the water cooler is used for the first time without water injection, water pump may be damaged; When using the water cooler, it is necessary to activate the water cooling function, check the water cooler on front panel. User Manual of Water Cooling Unit Anycool-66... -
Page 14: Water Injection/Drainage
3．If coolant is found to leak into the welding power source or water cooler, there may be a fault, and the water drops must be wiped immediately. 3.4 Filter (Optional) Connect one end of the filter to the water cooler, and connect the other end to the inlet pipe, as shown in Figure 3-3. User Manual of Water Cooling Unit Anycool-66... -
Page 15: About Coolant
It needs to avoid damage to cooling equipment.). Handle with tank sediment in time. Please clean the water cooler and replace the coolant regularly to avoid water cooler to produce coolant sediment. User Manual of Water Cooling Unit Anycool-66... -
Page 16: Chapter 4 Maintenance And Troubleshooting
Drain the coolant from water cooler, use high pressure air rifle to clean water Once per cooler regularly loop, then inject pure water, let tank run for 15 minutes to discharge the pure quarter User Manual of Water Cooling Unit Anycool-66... -
Page 17: Troubleshooting
Please read the warranty card carefully and keep it properly. Maintenance User shall check according to fault codes and countermeasures in the user manual of welding power source, troubleshooting the fault or recording the fault information. User Manual of Water Cooling Unit Anycool-66... - Page 18 MEGMEET . Warranty period of this product is one year, starting from the warranty card or purchase invoice. Abnormal use and artificial damage isn’t included in the free warranty coverage. User Manual of Water Cooling Unit Anycool-66...
-
Page 19: Appendix I Structure Diagram
Appendix I Structure drawing 11 Appendix 1 Structure Diagram Figure 1 Structure Diagram User Manual of Water Cooling Unit Anycool-66... - Page 20 Signature of technical support engineer: DD/MM/YYYY Signature of technical support engineer: DD/MM/YYYY Notes: This card is invalid when the user cannot be interviewed. Notes: This card is invalid when the user cannot be interviewed. User Manual of Water Cooling Unit Anycool-66...
- Page 21 Customer Service Center Address:Address:3rd Floor, Block C Unisplendour Information Harbor,Langshan Road, Address:Address:3rd Floor, Block C Unisplendour Information Harbor,Langshan Road, Shenzhen, Guangdong, 518057, China Shenzhen, Guangdong, 518057, China Customer service hotline: 4006662163 Customer service hotline: 4006662163 User Manual of Water Cooling Unit Anycool-66...
