- Page 1 SUNRISE HYDRAULIC TIPPER KIT USER MANUAL MODEL: HTKS 03 9794 0415 sales@sunriseint.com.au...
-
Page 2: Specifications
HYDRAULIC TIPPER KIT The Sunrise hydraulic tipper kit cylinder is made of high-grade carbon steel tubes, ensuring excellent stability and flexibility during tipping. Its mechanical properties allow it to withstand higher stress levels, making it ideal for heavy-duty applications. Our cylinders have a signifi- cantly higher loading capacity than those made with light-duty welded tubes commonly found in other cylinders. -
Page 3: Parts List
PARTS LIST Tipper Ram Hoist Power pack pump tank Part Number: HTR Part Number: HTPP Sunrise Wired Tipper Hydraulic Tipper Ram Remote Cradle Part Number: HTRPP Part Number: HTCS Fluid Connection Hose 5m Battery Lead Part Number: HTBL Part Number: HTFCH... -
Page 4: Optional Parts
Get the best view for the loading and unloading process More information: https://sunriseint.com.au/product/hydraulic-tip- per-wireless-remote/ Tipper Kit Rear Pivot Hinge Part Number: RPHG7T Capacity: 7000kg (7T) 2 pivots per kit Weldable design 25mm Greaseable bars Made from quality steel Maximum safety and service life More information: https://sunriseint.com.au/product/tipper-kit-rear-piv- ot-hinge-greaseable-7t-l-r-set/ https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/... -
Page 5: Tech Sheet
4.5T 108mm 123mm 123mm 123mm 40mm 40mm 40mm 40mm 40mm 40mm 40mm 40mm 148mm 148mm 148mm 148mm 233mm 234mm 276mm 230mm 160mm 160mm 160mm 148mm 389mm 377mm 435mm 393mm 45mm 88mm 45.5mm 18mm 33mm 105mm 140mm 37mm 15mm https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/... -
Page 6: Wiring Diagram
WIRING DIAGRAM Remote cable (Plug & Play) Positive Negative https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/... - Page 7 If the load becomes stuck or the body does not tip smoothly, lower the body completely, very slowly, and without any sudden interruption before resuming the tipping operation. If the issue persists, manually unload the dump body or trailer or use alternative mechanical means. https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/...
- Page 8 In case of any uncertainties or if assistance is required, please contact your supplier or reach out to the Sunrise Sales & Customer Service nearest to you. • The hydraulic cylinder is designed exclusively for lifting purposes and should never be utilized as a stabilizer for supporting the body of the equipment.
- Page 9 During oil draining, take care to prevent spills and dispose of the old oil in an environmen- tally responsible manner. • Apply grease to non-painted and moving parts if the tipping system is to be stored for an extended period. https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/...
-
Page 10: Troubleshooting
If the body still won1 come down, put the tipper lever in “hold”, prop the body, switch the PTO to “out” and turn off the engine. And contact Sunrise Sales&Service Agent Remove all the pneumatic hoses (except the feed and exhaust ones). Check if air passes... - Page 11 “hold” position Keep the engine revs going for 5 seconds If the body still will not stay up, lower the body and contact Sunrise Sales&Service Not enough oil Refill with the oil recommended Excessive noise...
-
Page 12: Warranty
8. Cylinder Warranty: Please note that failure to observe our advice and instructions will auto- matically void any warranty on the cylinders. Please keep in mind that the above warranty terms are subject to Sunrise’s discretion and should be read in conjunction with any specific warranty documentation provided with the product and other warranty material stated on our website. -
Page 13: Registration Form
TIPPING CYLINDER INFORMATION: Name Code First Last Phone Number Serial No Power Take Off Pump Email Address Gearbox Valve Name of the Body or Trailer Producer Steel Body Aluminum Body Cubic Meters of the Vehicle Service/Dealer Date of Mounting https:/ /sunriseint.com.au/product/sunrise-hydraulic-complete-tipper-kit/... - Page 14 03 9794 0415 sales@sunriseint.com.au...
