800A POWER PACK WITH COMPRESSOR (MP7435)
USER GUIDE
Please read this operating manual fully and abide by all safety
instructions when using this device.
Keep these instructions for future reference. When passing the
device on to others be sure to also include all documentation. The
instruction leaflet is also available on our website:
www.maypoleltd.com
Advertisement
Table of Contents
Related Manuals for MayPole MP7435
Summary of Contents for MayPole MP7435
- Page 1 800A POWER PACK WITH COMPRESSOR (MP7435) USER GUIDE Please read this operating manual fully and abide by all safety instructions when using this device. Keep these instructions for future reference. When passing the device on to others be sure to also include all documentation. The instruction leaflet is also available on our website: www.maypoleltd.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Explosive gases may escape from the battery during the use of this product. This is normal, but please follow the below guidelines: • Do not use near flames or sparks – do not smoke in the area. •... -
Page 3: Product Layout
COMPONENTS Box contains: 800A power pack & compressor Output cable jump lead Type C USB charging cable & adaptor Tyre, ball & inflatables adaptors PRODUCT LAYOUT 1. Inflate button 6. Power button 11. USB charging port 2. LCD display 7. Light button 12. - Page 4 CHARGING • Insert the USB charging cable (14) into the USB charging port (11) on the device. • Insert the type A USB port into a 5V 2A supply adaptor. • When the power is connected; the ‘charging icon’ on the LCD display will flash. When the device is fully charged the charging icon will stop flashing.
-
Page 5: Lcd Display
LCD DISPLAY 1. Reverse connection or connected to a battery which is <2V 2. Charging icon (flashing indicates charging, solid icon indicates fully charged) 3. Vehicle battery voltage 4. Device battery capacity percentage 5. Cooling status 6. Ready to jumpstart CHARGING DEVICES VIA USB A wide selection of portable devices such as mobile telephones, tablets and portable media devices can be charged via this device. -
Page 6: Switching Off The Device
USING AS A COMPRESSOR • Remove the air hose (15) from the storage location. • Press and hold the power switch (6) for 3 seconds to turn on the device. • Securely connect the screw on valve connector on the air hose (and an accessory if required) to the item to be inflated. -
Page 7: Technical Specifications
Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Declaration This apparatus meets the requirements of: EMC EN 61000-6-3; 2007+A1/ EN IEC 61000-6-1:2019/ EN IEC 55015:2019+A11/ EN 61547:2009 RoHS Directive (EU) 2015/863 amending 2011/65/EU Technical Manager, Maypole Ltd, May 2023 Email: sales@maypoleltd.co.uk Web: www.maypoleltd.com...
