A
C
IR
LASSICS
Flight Timer
TIMER-3
USER'S MANUAL
Features ...................................................2
Controls and Indicators .........................4
Display ....................................................4
Buttons ...................................................4
Parts and Assembly ...............................4
Getting Started ........................................4
Battery Replacement ..............................5
Button Functions ....................................5
Clock Function ........................................6
Display Formats ......................................6
Setting Time ............................................7
Setting UTC Hour ...................................7
Fuel Timer Function ................................7
Count-up Operation ................................8
Countdown Operation ............................8
Fuel Timer Alarm ....................................8
Canceling the Fuel Timer Alarm .............8
®
Chronograph Function ...........................9
Chronograph Operation .........................9
Approach Timer Function ......................9
Selecting an Approach Time ................10
Count-up Operation ..............................10
Countdown Operation ..........................10
Approach Timer Alarm ......................... 11
Recalling Stored Approach Times ........11
Note/Scratchpad Function ................... 11
Backlight Operation ..............................12
Device Reset ..........................................12
Care ........................................................12
Specifications ........................................12
Limited Warranty ...................................13
Advertisement
Table of Contents
Related Manuals for ASA Electronics AIR CLASSIC TIMER-3
Summary of Contents for ASA Electronics AIR CLASSIC TIMER-3
-
Page 1: Table Of Contents
LASSICS ® Flight Timer TIMER-3 USER’S MANUAL Features ...........2 Chronograph Function ......9 Chronograph Operation ......9 Controls and Indicators ......4 Display ............4 Approach Timer Function ......9 Buttons ...........4 Selecting an Approach Time ....10 Parts and Assembly .......4 Count-up Operation ......10 Countdown Operation ......10 Getting Started ........4 Approach Timer Alarm ...... -
Page 2: Features
Instruction Manual Congratulations on your purchase of the Flight Timer from Aviation Supplies & Academics, Inc. (ASA). This is a quality timekeeping instrument engineered to meet the needs of pilots. We hope you enjoy the functionality and convenience of your new Flight Timer. FEATURES Large, readable LCD display ... - Page 3 Instruction Manual Figure 1 — Display, buttons, and parts (see legend on next page) – 3 –...
-
Page 4: Controls And Indicators
Instruction Manual CONTROLS AND INDICATORS Display 1. Mode indicators 2. Home/Destination approach time memory banks 3. Low battery indicator 4. 5-digit note scratchpad 5. Clock and timer display Buttons 6. CLOCK 7. START/STOP 8. FUEL/CHRONO 9. APPROACH 10. RESET 11. DIAL 12. -
Page 5: Battery Replacement
Instruction Manual BATTERY REPLACEMENT Follow these steps to replace the batteries: Turn the mounting clip to a horizontal position. Press snap tab down and remove battery cover. Install 2 AAA alkaline batteries according to polarity diagram. Check to see that timer display is on. ... -
Page 6: Clock Function
Instruction Manual CLOCK FUNCTION The Flight Timer keeps track of the current time and provides three display options: Standard time (AM/PM) Military time (24-hour) Universal coordinated time (UTC or “Zulu”) The “CLOCK” icon appears in the upper portion of the display when clock mode is active. -
Page 7: Setting Time
Instruction Manual Setting Time With standard or military time formats displayed, push and hold DIAL until the hour digits flash (about 2 seconds). Trick—Press RESET at 0 seconds to reset to 12:00:00, then seconds will not need resetting later. Rotate DIAL to set the hours. -
Page 8: Count-Up Operation
Instruction Manual Count-up Operation Count-up operation can be used to track the duration of events up to 99 hours and 59 minutes long. No alarm will sound when counting up. If timer is running press START/STOP to stop timer. Press RESET to zero timer as shown in Figure 5. -
Page 9: Chronograph Function
Instruction Manual CHRONOGRAPH FUNCTION The Flight Timer includes a chronograph (stopwatch) function for precise measurement of time intervals. The features of this timer are: Count-up measurement only. Precise 1/10th and 1/100th second digit display. Counts up to 99 minutes. ... -
Page 10: Selecting An Approach Time
Instruction Manual The “APPROACH” icon appears in the upper portion of the display when approach mode is active. If a different mode is active, press the APPROACH button to display the approach timer. Figure 7—Approach timer display Selecting an Approach Time There are 12 approach times stored in memory. -
Page 11: Approach Timer Alarm
Instruction Manual APPROACH TIMER ALARM When the approach timer counts down to zero the Flight Timer sounds an audible and visible alarm then begins to count up, measuring the time since the alarm. If approach mode is active, the hour, minute and second digits flash. -
Page 12: Backlight Operation
Instruction Manual BACKLIGHT OPERATION The Flight Timer includes a LED backlight system for night visibility. Toggle on and off by pressing the LIGHT button. If left on, the backlight will automatically shut itself off after 5 minutes. Prior to auto shut-off, the backlight will flash ten times to announce that it is shutting off. -
Page 13: Limited Warranty
Instruction Manual LIMITED WARRANTY Aviation Supplies & Academics, Inc. (ASA) warrants this ASA Flight Timer to the original purchaser for a period of five years from the initial date of purchase, against defects in material and workmanship. Batteries are not covered by this warranty. - Page 14 Aviation Supplies & Academics, Inc. 7005 132nd Place SE Newcastle, Washington 98059 USA 425-235-1500 | asa2fly.com TIMER-3...
