- Page 1 BG-EXHD-70UCWP-W 18Gbps HDBaseT 230ft Wall Plate Kit with MDP/HDMI Wall Plate Transmitter & HDBaseT to HDMI receiver User Manual...
- Page 2 BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Statement Safety Precaution Surge protection device recommended Introduction Features Packing List Specifications Product Dimensions Operation Controls and Functions Receiver Panel Connection Diagram Troubleshooting Tech Support Warranty Mission Statement Copyright · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 4: Statement
● This product does not contain parts that can be maintained or repaired by users. Damage caused by dismantling the product without authorization from BZBGEAR is not covered under the warranty policy. ● Installation and use of this product must strictly comply with local electrical safety standards. -
Page 5: Introduction
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Introduction Introducing the BG-EXHD-70UCWP-W 18Gbps HDBaseT 230ft Wall Plate Kit, complete with an MDP/HDMI Wall Plate Transmitter and an HDBaseT to HDMI Receiver. Designed for seamless integration into your AV setup, this kit offers advanced connectivity and transmission capabilities while maintaining a sleek aesthetic with its Decora-style wall plate design. -
Page 6: Specifications
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 DP Compliance Display Port 1.2a DP: 5.4 Gbps Video Bandwidth HDMI: 18 Gbps Video Resolution 480i~1080p50/60Hz, 4Kx2K@24/30Hz, 4K2K@60Hz Color Space RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0... - Page 7 BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Mechanical Housing Metal Enclosure Color White Wall plate: 1.31in x 2.6in x 2.7in [33.3mm x 65.7mm x 68.7mm] Dimensions (W x D x H) Faceplate: 2.8in x 0.12in x 4.5in [69.9mm x 3mm x 114.3mm] Receiver: 7.9in x 4.0in x 0.87inin [200mm x 102.8mm x 22mm]...
-
Page 8: Product Dimensions
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Product Dimensions · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 9: Operation Controls And Functions
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Operation Controls and Functions Front and Rear Panel Transmitter Panel Name Function Description The power LED indicator will illuminate in green Power LED when the product is powered on, and red when the product is on standby. -
Page 10: Receiver Panel
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Receiver Panel Name Function Description Power LED When the product is powered on, the red LED indicator will be on. DC 24V DC 24V power supply port. Firmware update port. HDBaseT IN Connect to the HDBaseT OUT port of Transmitter with a CAT6/6a/7 cable. -
Page 11: Connection Diagram
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Connection Diagram · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 12: Troubleshooting
BZBGEAR BG-EXHD-70UCWP-W PRODUCT MANUAL Troubleshooting Problems Causes Solutions No Power / All LED off Power supply not connected, Check if the power supply is connected fully, or wrong power connected correctly and the supply. output voltage value is within recommended specifications. -
Page 13: Tech Support
1.888.499.9906 support@bzbgear.com bzbgear.com Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of five years. For complete warranty information, please visit bzbgear.com/warranty. For questions, please call 1.888.499.9906 or email support@bzbgear.com. -
Page 14: Mission Statement
AVoIP, professional broadcasting, conferencing, home theater, to live streaming solutions. We pride ourselves on unparalleled customer support and services. Our team offers system design consultation, and highly reviewed technical support for all the products in our catalog. BZBGEAR delivers quality products designed with users in mind. ·... -
Page 15: Copyright
PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
