- Page 1 INSTALLATION GUIDE Hanging divider Statement Design Flawless Acoustics - Beautiful design and brilliant acoustics - Detachable canvas for easy cleaning and unlimited design options without replacing the frame and panel Sounds Beautiful - Quick to install...
- Page 2 Restrictions suspended with wires from the ceiling. They arrive fully assembled, We recommend not to use Rockfon Canva Hanging divider in high and are a safe, flexible, durable and modern solution that can be humidity areas like swimming pools or outside environments. Also, custom-designed to fit any space or location.
-
Page 3: System Components
Rockfon Canva Hanging divider ® ™ System components Panel Components 1. Design wire set (top) 2. Design wire set (bottom) L = 1500 mm L = 500 mm Tool List Drill machine Screw machine Wire cutter Level Laser (optional) Tools... -
Page 4: Before Installation
Rockfon Canva Hanging divider ® ™ Before installation Positioning of wire locks 600 mm 900 mm 1200 mm 480 mm 780 mm 1080 mm 600 x 1800 mm 900 x 1800 mm 1200 x 1800 mm... -
Page 5: Installation
Attach the Design wire set (top) to the ceiling as illustrated below. Ø = 5,1 mm Wire lock Note: Ensure that the wire going into the Rockfon Canva Hanging divider does not exceed 50 mm (use wire cutter). For levelling the Rockfon Canva Hanging divider, press the wire lock down and use the level. - Page 6 Attach the Design wire set (bottom) to the floor as illustrated below. Ø = 5,1 mm Wire lock Attach the Design wire set, but do Put the wire into the Rockfon Canva Fully secure the wire by fastening the not fasten completely! Hanging divider until the wire is Design wire set completely.
-
Page 7: Care And Maintenance
Machine wash: Always follow the specific manufacturer’s instructions. Remove the canvas fabric by pulling the Rockfon handtag in the Steam cleaning: bottom right corner until it comes loose from the frame. The canvas supports frequent machine wash up to 70 degrees celsius. -
Page 8: Additional Features
Tools www.soundsbeautiful.com Rockfon has developed specific tools that are available on Visit our online CAD Library or BIM portal to Generate specification texts for our products Explore our vast library of reference projects on assist you in your project design. - Page 9 Sounds Beautiful Part of ROCKWOOL Group / www.rockfon.co.uk...
