- Page 1 PORTABLE POWER STATION USER MANUAL www.acdc.co.za Recommended to fully charge PBU-PS-P1000 before use www.acdc.co.za T H I N K E L E C T R I C A L National Sales Centre - 010 202 3400 | Technical - 010 202 3500...
-
Page 2: General Specifications
GENERAL SPECIFICATIONS The PBU-PS-P1000 is a portable battery pack with the ability to supply 1000W of pure sine wave AC power via the onboard AC output. Additionally, The PBU-PS-P1000 is able to support USB quick charging via the onboard 1 x USB PD port and 3 x USB A ports. - Page 3 It is advisable to replace it if any such severe events occur. •DO NOT expose PBU-PS-P1000 to moisture, rain, or snow. •DO NOT charge, use or store PBU-PS-P1000 in a bathroom or in an area exposed to rain or moisture.
-
Page 4: Feature Details
11.Air Intake Vent with Cooling Fan 12.Solar Charging Input 13.AC input Note: No user-serviceable parts inside. Recommended to fully charge the PBU-PS-P1000 before use. BUTTON FEATURE 1. Power ON/OFF Button 2.USB Output Power ON/OFF Button 3.SOS mode & LED light Button AC Output Power ON/OFF Button 5.SOS mode &... -
Page 5: Lcd Features
LCD FEATURES A.Battery Level Indicator B. total Outputs Status C.LED Status D.AC Outputs Status E.UPS Status F.abnormality Status G.USB Outputs Status H.DC Outputs Status I.LED Status J. Inputs Status HOW TO CHARGE By solar panels 400W (12-75V 12A Max) about 3-5 hours depending on solar conditions By Car Port 12V 10A about 11-13 hours when car running... -
Page 6: What It Powers
WHAT IT POWERS Laptops (41.4Wh) 32" TV(60W) CPAP without heated Go pro (5.9Wh) Floodlight(4W) Around Around humidifier (15W) Around Around 19 Recharges 13 hours 53hours 135 Recharges 200 hours +MORE Mini Fridge(40W) DJ Drone(89.2Wh) Smartphone(10Wh) Switch(16Wh) Around Around Around Around 20 hours 9 Recharges 80 Recharges... -
Page 7: Function Buttons
FUNCTION BUTTONS PBU-PS-P1000 POWER ON/OFF Button ① is the master switch. Press Button ① to activate all buttons. Press Button ① to shut down the output(s)When not in use. SOS MODE & LED LIGHT Function available only when the Button ① activate . - Page 8 PORTABLE POWER STATION PBU-PS-P1000 utilizes an internal cooling fan to ensure the product is operating within the appropriate temperature range. PORTABLE POWER STATION PBU-PS-P1000, when it experiences a higher output load, will automatically turn on the fan. During discharge, and possibly charging, the fan may operate intermittently to keep internal temperature within operating range.
- Page 9 INPUT Status J: The PBU-PS-P1000 is capable of providing input energy in watts. DC Output Status H: The display will provide output watts of the DC port on position of B.
- Page 10 CHARGING PORTABLE POWER STATION PBU-PS-P1000 Connect the provided AC power cord to Input, and allow PORTABLE POWER STATION PBU-PS-P1000 to fully charge prior to use, approx. 2.5 When charging, the LCD Screen will be illuminated, and the LCD display will -3.5 hours.
- Page 11 PS-P1000 allows it to charge a connected device via DC output & USB output while charge the PORTABLE POWER STATION PBU-PS-P1000. PBU-PS-P1000 support AC output during AC power cord charging PBU-PS-P1000 itself. OVERLOAD CONDITION If an overload condition occurs on the OUTPUT port, PORTABLE POWER STATION PBU-PS-P1000 will: Automatically turn off AC Output power.
- Page 12 After taking out of storage, visually inspect to make sure PORTABLE POWER STATION PBU-PS-P1000 and all accessories look satisfactory. This increase review the intake and exhaust side vents to ensure they are clear of debris. Allow PORTABLE POWER STATION PBU-PS-P1000 to return to ambient conditions before recharging, or charging other devices.
-
Page 13: Troubleshooting
MAINTENANCE Recharge as needed. There are no predesignated intervals at which to recharge as long as the PORTABLE POWER STATION PBU-PS-P1000 is being used regularly. It needs to wait 1-2hours to recharge again after AC discharging from 100% to 0% uninterruptedly. -
Page 14: Warranty Period
WARRANTY Limited Warranty Warranty to the original consumer purchaser that the PORTABLE POWER STATION will be free from defects in workmanship and material under normal consumer use during the applicable warranty period identified in the 'Warranty Period' section below, subject to the exclusions set forth below. This warranty statement sets forth our total and exclusive warranty obligation. - Page 15 WARNING (A) Read all the instructions before using the product. (B) To reduce the risk of injury, close supervision is necessary when the product is used near children. (C) Do not put fingers or hands into the product. (D) Use of an attachment not recommended or sold by power pack manufacturer may result in a risk of fire, electric shock, or injury to persons.
- Page 16 installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna.
