- Page 1 User's manual Manual del usuario Manuel de l'utilisateur Customer Service Servicio de atención al Cliente Service à la clientèle US: 1-800-645-2986 US: 1-800-645-2986 Canada: 888-645-2986 Global Industrial™ 2-Seat Warehouse Personnel Carrier Model: 800574 Operator’s Manual...
- Page 2 In case of any discrepancies, consider the actual vehicle as correct and use this manual for reference purposes only. Global Industrial is not liable for errors in this manual or any consequential damage that results from the use of this manual.
-
Page 3: Table Of Contents
Personnel Carrier TABLE OF CONTENTS 1. VEHICLE DESCRIPTION ..............................3 2. GENERAL SAFETY INFORMATION ..........................4 1.1. Safety Warning Labels ............................. 4 3. RECEIVING AND UNPACKING VEHICLE ........................6 4. VEHICLE QUICK SETUP ..............................7 5. VEHICLE SPECIFICATIONS ............................8 5.1. -
Page 4: Vehicle Description
Personnel Carrier VEHICLE DESCRIPTION The warehouse personnel carrier primarily is used to carry personnel. It may be used to tow or transport suitable goods on its cargo deck. To ensure safe operation, it is imperative to adhere to the operating instructions and appropriate use cases. -
Page 5: General Safety Information
Personnel Carrier GENERAL SAFETY INFORMATION Safety Warning Labels 1. Operating Instructions Label 2. Off-Road Use Only Label 3. Proper Training Label 4. Pinch Point Warning Label... - Page 6 Any unauthorized repairs, modifications, or adjustments could lead to unsafe conditions resulting in severe bodily injury and/or property damage. Any modifications must be approved by the manufacturer. Global Industrial is not responsible for any consequences resulting from unauthorized repairs, modifications, and adjustments.
-
Page 7: Receiving And Unpacking Vehicle
With assistance, lift cargo deck off the vehicle. Take precaution on pinch points. Refer to “VEHICLE CONTROLS” part of the manual to learn more about vehicle controls before operating vehicle. Refer to QR code or link for model no. 800574 unpacking video and instructions: https://www.globalindustrial.com/p/2-seat-warehouse-personnel-carrier-24v... -
Page 8: Vehicle Quick Setup
Examine the contents of all packages and accessories that may have come in separate packages along with the vehicle and ensure everything listed on the packing slip is there. Model no. 800574 includes an on-board charging cable. Refer to “Before Operating Vehicle” section of this manual to check that the vehicle is in correct operating condition. -
Page 9: Vehicle Specifications
Personnel Carrier VEHICLE SPECIFICATIONS Model No. 800574 Passenger Capacity Up to 2 Rated Capacity 1100 lbs Towing Capacity 2200 lbs Maximum Speed 9 mph Maximum Speed on Slow Mode 5 mph Turning Radius (Intersecting Aisle) 73" Horsepower 4.29 HP Ground Clearance 2.5”... -
Page 10: Data Name Plate
Personnel Carrier Data Name Plate Do not remove any name plate, warnings, or instructions affixed to your Global Industrial vehicle. Promptly replace any that become damaged or removed. Each vehicle is assigned with a unique serial number. The serial number can be found on the name plate located below the right side of the driver’s seat. -
Page 11: Vehicle Controls
Personnel Carrier VEHICLE CONTROLS... - Page 12 Personnel Carrier (1) Steering tiller controls the path of the vehicle and operates similarly to a conventional automobile steering wheel as shown below. To turn the vehicle left, push the tiller away towards the right, i.e., in a counterclockwise direction. To turn the vehicle right, push the tiller away towards the left, i.e., in a clockwise direction.
- Page 13 Personnel Carrier (7) Battery indicator The top portion of this instrument is a battery capacity indicator. The bottom portion is an hour meter The battery capacity indicator has 10 bars of LED lights (5 green bars, 3 yellow bars, and 2 red bars) indicating the battery’s state of charge.
- Page 14 Personnel Carrier (13) Headlight is designed to illuminate the vehicle’s pathway. It is activated with the headlight rocker switch (14) Blue safety light The vehicle is equipped with a blue safety light that turns on when key switch (7) is turned to the “ON”...
-
Page 15: Vehicle Operation
Any unauthorized repairs, modifications, or adjustments could lead to unsafe conditions resulting in severe bodily injury and/or property damage. Any modifications must be approved by the manufacturer. Global Industrial is not responsible for any consequences resulting from unauthorized repairs, modifications, and adjustments. - Page 16 Personnel Carrier Drive slowly when making a turn, especially on wet or inclined surfaces. Drive slowly up and down grades. Do not drive on steep hills or inclines. Do not drive on grades that exceed the vehicle’s gradeability. Do not park vehicle on incline/slope. Do not use accelerator to hold vehicle on an inclined surface.
-
Page 17: Before Operating Vehicle
Personnel Carrier Before Operating Vehicle If any of the following items malfunction or do not work as expected, do not operate vehicle until problem has been corrected. Daily Pre-Operation Checklist Item Check content No loose hardware Body and chassis Body and seat are clean and free of damage. Fully or adequately charged Battery Charging cord is disconnected from port... -
Page 18: Operating Vehicle
Personnel Carrier Operating Vehicle 1. Sit on seat. If applicable, ensure rear passenger is seated and holding onto handholds. 2. Insert key, press on brake pedal firmly, and turn key to “ON” position. 3. Switch the FNR switch to the desired direction of travel. 4. -
Page 19: Batteries And Charging
BATTERIES AND CHARGING Charging the Vehicle The Global Industrial personnel carrier contains four, 6V deep cycle gel AGM batteries, which are virtually maintenance-free. It is recommended to fully charge the vehicle upon receipt. The charge time of the new batteries is approximately 10-12 hours. -
Page 20: Charging Indication Lights
Personnel Carrier Charging Indication Lights The charging indication lights are located directly above the on-board charging port. LED Color Indication Flashing red Battery charging Green Fully charged Battery Maintenance Always power off vehicle by removing key and disconnecting batteries before servicing or repairing vehicle. -
Page 21: Charger Troubleshooting
Personnel Carrier CHARGER TROUBLESHOOTING Charger Error Codes LED Color Indication Potential Cause / Solution Green, red Empty load Battery or charger connections are loose. The battery is reversed. The battery voltage is too low. Red, green, red, 3s pause Overvoltage/overcurrent Restart vehicle and if error light sustains, contact support. -
Page 22: Maintenance And Repair
Personnel Carrier MAINTENANCE AND REPAIR The following maintenance procedures are based on cases where the warehouse personnel carrier is used 8 hours a day or 200 hours per month. Always power off vehicle by removing key and disconnecting batteries before servicing or repairing vehicle. - Page 23 Personnel Carrier • Tires are free of damage • No loose hardware Wheels/tires • Check wear on tires and bearings. Replace if necessary. • Replace tires • Replace wheel bearing • Brake pedal has firm pressure with minimal travel. Check brake clearance •...
-
Page 24: Troubleshooting The Vehicle
Personnel Carrier Troubleshooting the Vehicle Faults Potential Cause Potential Solution The vehicle does not start. Battery is depleted Inspect, charge, or replace the AGM batteries. The battery terminals Tighten the terminal screws. are loose. The fuse has been Replace the fuse. (part no. 20416000004) blown out. -
Page 25: Troubleshooting With Controller Led Indicators
Personnel Carrier Troubleshooting with Controller LED Indicators LED display code example 2.4: ☼☼ ☼☼☼☼ means that LED first blinks twice, then turns off, then blinks another four times. 1311 Display Fault Explanation Fault Cause Code 1. Vehicle operation fault creates high Restart vehicle by turning CURRENT SHUNT current spikes... - Page 26 Personnel Carrier 1. Operation sequence fault in interlock switch, direction, and key The signal is more switch. Check the operation than 20% when the 2. Accelerator fault sequence, the accelerator vehicle is started and 3. The delayed time of operation adjustment and the code the controller auto- sequence set before is too short.
-
Page 27: Storing The Vehicle
Personnel Carrier 1. The battery voltage is higher than Make the battery voltage OVERVOLTAGE the maximum work voltage of the lower than the cut-off The battery voltage controller. work voltage of the is too high. 2. The charger is still connected to controller.
