Designed for satellite dish installations.
If you want a cost effective professional satellite finder, this is the one for you!
Front Panel
2
1
1. Receiver connecting port and power supply connection.
2. Upgrade software & parameters via U disk.
3. Satellite signal input.
4. Display the menu and the measured values.
5. LED Lights when 22K/13V/18V is on.
6. Switching between Satellite Name/ LNB Type/ Transponder.
7. Satellite Name/ LNB Type/ Transponder moves left or right.
How To Connect
Connect the cable from the LNB to the "LNB IN" port on the Finder.
Connect the cable from your satellite receiver or portable power support to
the "Receiver" port on the Finder.
Digital Satellite Finder
4
Digital Satellite Finder
6
5
7
3
Advertisement
Related Manuals for Sathero SH-100HD
Summary of Contents for Sathero SH-100HD
- Page 1 Digital Satellite Finder Digital Satellite Finder Designed for satellite dish installations. If you want a cost effective professional satellite finder, this is the one for you! Front Panel 1. Receiver connecting port and power supply connection. 2. Upgrade software & parameters via U disk. 3.
- Page 2 Digital Satellite Finder Portable Power Satellite Finding Turn on the satellite receiver or portable power, the Finder will automatically turn on. From the menu, move cursor to "S" , use [◄][►] buttons to switch between satellites, select the one you want. Press and hold the [►] button for 2 seconds, turn off the beep.
