- Page 1 USER'S MANUAL Digital Combo Signal Finder We operate a policy of technically change without prior notice, the picture of outlook and color is for a reference only, the actual item is the standard.
-
Page 2: Front Panel
FRONT PANEL... -
Page 3: Mini Usb-Port
FRONT PANEL No. Item Description MINI USB-Port USB port for PC connection and power supply connection AV In Input audio and video signals,Output DC 12V 2A Terrestrial signal input and CCTV camera signal RF In input(Optional) USB-Port Connect to USB or USB-HDD device HDMI-Port Connect to TV through HDMI cable Satellite signal input... - Page 4 INSTRUCTION Charging If the finder is being used for the first time, it may be necessary to charge for no longer than 6 hours. If the battery runs low during use, you should recharge it for 3 or 5 hours, it will be full when the power light turns to orange from green.
- Page 5 INSTRUCTION Select LNB From the finding menu, move the cursor to LNB Type, Use [◄][►] buttons to choose LNB Type between Single, Universal and MDU, then move the cursor to the next bar, Use [◄][►]buttons to select the default LNB frequency.
- Page 6 INSTRUCTION DVB- T/T2 menu(Optional) From the main menu, you can find the T/T2 options. Press OK button, the T/T2 menu will appear. Select Country From the T/T2 menu, move cursor to Country, Use [◄][►]buttoms to select the Country that you want. Select Mode From the T/T2 menu, move cursor to Mode, Use [◄][►]to switch between Auto and Manual.
- Page 7 INSTRUCTION Delete Channels From the main menu, select “Channel”, press [OK] to enter the channel edit menu. Use [▲/▼] buttons to choose from the options below. TV Channels Radio Channels Delete ALL Channels Delete ALL TV Channels Delete ALL Radio Channels Delete ALL FTA Channels Delete ALL Scramble Channels Press OK button to confirm...
- Page 8 NOTES Notice Before being ready to seek satellite signal, make sure that the cable is properly connected first. While installing the antenna, make sure that the LNB in port of the finder is well connected to the tuner of the antenna with a tested cable. Turn the antenna in the approximate direction, the finder will light the LED bar and beep when the antenna is close to the satellite.
-
Page 9: Technical Specifications
Technical Specifications DVB-S/S2 F-type connector IEC 169-24 Frequency range 950MHz ~ 2150MHz Input level -65dBm ~ -25dBm Input Input Impedance 75Ω LNB power supply 14/18V, Max 650mA LNB switch control 22kHz Demodulator Demodulator front end QPSK, 8PSK,16APSK, 32APSK Symbol rate 2Mbps~45Mbps Measurement Unit dBm, dBuV...
