  • Page 1 Installation Manual Building Automation Systems QWL2040 Panel Integrated Building Manager 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com 202403 Building Automation Systems...

  • Page 2: Table Of Contents

    Appendix D: Configuring Local Management Port as a Fail-Over Port ........40 Fail-Over Port Configuration Via Internal Gateway ....................40 Fail-Over Port Configuration Via CLI .........................42 Appendix E: Installing and Using TCS Insight Software .............. 44 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com...

  • Page 3: Introduction

    Panel for local programming and/or configuring the components of the Panel. Appendix D provides information on using TCS Insight software, a service tool that can be used to program the QWL locally. TCS Insight is a very powerful service tool that should be used only by trained technicians.

  • Page 4: Installation

    Installation Glossary of Terms Astronomical Time Clock/Time: Timekeeping settings based on the sunrise and sunset at the geographical location of the unit. Baud Rate: The speed with which a device communicates over a network connection. BTU: British Thermal Unit. A measure of the quantity heat required to raise the temperature of one pound of liquid water one degree Fahrenheit.
  • Page 5 Installation RS485: A networking standard which defines he electrical characteristics of drivers and receivers for use in serial communications systems. TCP: Transmission Control Protocol. A standard that defines how to establish and maintain a network conversation through which application programs can exchange data. TCP/IP: Transmission Control Protocol/Internet Protocol.

  • Page 6: Material List

    Installation Material List • QWL2040 Panel • External Power Supply Wall Mounting The Panel is designed for wall mounting using four #10 pan head screws. The unit MUST be powered down while mounting to the wall. When selecting a location to mount the Panel, be sure to allow space for cable connections.

  • Page 7: Power And Communication Connections

    IT department. NOTE: If using a cellular modem provided by TCS, connect the Ethernet cable to the LAN port on the modem (contact TCS Technical Support at 800.288.9383, ext. 2 for additional information).

  • Page 8: Input Wiring

    NOTE: The Local Management Ethernet Port (L) on the side of the Ubiquity Cloud Gateway is used only for local onsite management of the QWL2040 Panel device. Optionally, this port can be configured as secondary Internet fail-over port (see Appendix D: Configuring Local Management Port as a Fail-Over Port on page 40 COM Ports (RS485 Network): Connect up to two RS485 Networks to the inputs on Com Port panel or on the Serial Board adjacent to the Gateway.
  • Page 9 Installation NOTE: Do not install line voltage devices (120VAC or greater) within this panel. The QWL2040 Panel is comprised of the following components: • Ubiquity Cloud Gatewayr • SLQ218 Lighting Controller • SLQ100 Electrical Pulse Meter These components accept the following inputs: •...

  • Page 10: Rs485 Controller Network Wiring & Setup

    RS485 Controller Network Wiring & Setup The QWL2040 Panel can handle as many as 64 connected controllers on each port, including COM and serial ports. All controllers connected to the network must be programmed with the same communication baud rate as well as a unique communication address from 0 to 255, excluding 248.

  • Page 11: Three-Wire Network Wiring

    Three-Wire Network Wiring on page 11). • If the Panel will be in the middle of the network, do not wire in the terminating resistor on the QWL2040 Panel terminal block Connect one end (ideally the furthest end from the QWL2040 Panel) of the shield wire of the network wiring to earth ground.

  • Page 12: Two-Wire Network Wiring

    Last in Daisy Chain Earth Ground Only at one end Two-wire diagram Shielded, twisted two-conductor NOTES: QWL2040 Panel at end of the communications wiring with one end network. If using more than 64 earth grounded. (120 Ω balancing resistors provided.)

  • Page 13: Startup

    (if utilized). 4. Connect the power source to the QWL2040 Panel and apply power. If your Panel was preconfigured by the TCS factory or another user, it will automatically go online and contact Ubiquity Cloud.

  • Page 14: Troubleshooting

    Installation Troubleshooting The LEDs in the QWL2040 Panel ’s indicator panel on the front of the unit can be used to aid in troubleshooting and allow the occupant to view the current operating status of the Panel. Front indicator panel Power LED Does Not Light Up Be sure that the power supply module, included with the Panel, is plugged in to an outlet that has power.
  • Page 15 There also could be a bad connection, a bad cable, a bad ground, or a bad component. Contact TCS Technical Support (800.288.9383, ext. 2) for assistance. 2800 Laura Lane • Middleton, WI 53562 800.288.9383...

  • Page 16: Gateway Configuration

    Introduction to Gateway Configuration The QWL2040 Panel utilizes an internal Gateway to communicate with Ubiquity Cloud and the attached device networks. This Gateway can be configured locally by connecting a laptop directly to the device, or by connecting a monitor and keyboard.
  • Page 17 Gateway Configuration Installation information Application Information This section contains settings which define how the Panel interacts with the controller network, and how it communicates the data to the Ubiquity Cloud Server. Application Options Select a Network Polling Cycle Time for the Panel. This is the time interval that the unit will poll the entire network of controllers on all ports.
  • Page 18 “timed out.” Select the time-out period for each port. TCS recommends TCSbus and Modbus set at 200 ms for wired networks. Auto-detection Range: (Default 0, 255) This is the lowest address to start polling and the highest address to stop polling during the auto-detected sequence.
  • Page 19 If Secure Mode has been enabled and you need access, call TCS Technical Support (800.288.9383, ext. 2) for assistance. Here is where you change the default login credentials used to access the Configuration Page. TCS recommends changing these credentials.
  • Page 20 Gateway Configuration Security information Commissioning Tools You can access a separate page containing various commissioning tools by clicking the “Commissioning Tools” button at the bottom of the Security Information page. These tools provide you with access to managing the communication status of the Panel and the controller network connected to it.

  • Page 21: Gateway Configuration Via Cli

    2. Connected: The unit is able to communicate to the Ubiquity Cloud Server BUT is not being matched up with a specific site. Typically this indicates that the site is not initialized on the Ubiquity Cloud Server side yet. Contact TCS Technical Support (800.288.9383, ext.
  • Page 22 Gateway Configuration Command Line Interface Screens Gateway configuration Application options 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...
  • Page 23 Gateway Configuration Proxy options Extended application options 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...

  • Page 24: Lighting/Pulse Meter Programming

    Introduction to Lighting/Pulse Meter Programming The Lighting Module of the QWL2040 Panel is an SLQ218, which is equivalent to the SL2108. The Pulse Meter Module of the Panel is an SEQ100, which equivalent to the SE1000. The lighting and meter modules can be programmed remotely via Ubiquity Cloud (www.ubiquitysystems.net), which will automatically detect the modules.
  • Page 25 Lighting/Pulse Meter Programming When Channel Is “ON” You can select how you want the time clock output (Digital Output Mode) to behave in the event of a power failure at the controller, which will control whether the lighting will stay on. You can choose the channel to be Normally Open or Normally Closed during such periods.
  • Page 26 Lighting/Pulse Meter Programming Momentary Override: The digital input acts like a toggle switch. This must also be a momentary N.O. switch. If the time clock is on, pressing the switch turns it off, If the time clock is off, pressing the switch turns it on. Monitor mode: the digital input acts as a monitor for the DI and has no other function.

  • Page 27: Pulse Meter Module Programming

    + week and the ending month + week. Scheduling Via TCS Insight When scheduling via TCS Insight, click on the Channel Schedules tab to display additional tabs for each channel (1 – 8). Each channel tab has subtab for all available functions.
  • Page 28 Lighting/Pulse Meter Programming If you have a Type C device (three terminals KYZ), you will need to double the multiplier. This is because the SEQ100 only counts the contact closures for the K and Z terminals. Programming the Meter Constants CT Value: The value of the CT wired to the meter.

  • Page 29: Appendices

    Appendices Appendices Appendix A: Local Management Port The QWL2040 Panel can be configured locally at the device using a laptop computer. If using this method of configuration, you will need: 1. Laptop with a hardwired Network Interface Card (NIC). 2. Ethernet cable.
  • Page 30 Appendices Change adapter options 3. On the Network Connections panel locate the Ethernet interface that is connected to the cable. Right click on the item and select “Properties.” Properties 4. On the Ethernet Properties panel locate the “Internet Protocol Version 4 (TCP/IPv4)”. Select that option, then click on the “Properties”...
  • Page 31 Appendices TCP/IPv4 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...
  • Page 32 Appendices 5. On the Internet Protocol Version 4 (TCP/IPv4) Properties change the IP schema to: • IP Address: 10.248.248.2 • Subnet Mask: 255.0.0.0 • Default Gateway: 10.248.248.2 • DNS: Blank 6. Click on the “OK” button and close the window. Port to static settings 2800 Laura Lane •...
  • Page 33 Appendices 7. Launch any web browser and type in the following address: https://10.248.248.1. Device address 8. Depending on your browser’s configuration, you may get the following screen: Privacy error warning screen 9. Click on the “Advanced” button in the Privacy Error Warning screen. 2800 Laura Lane •...
  • Page 34 Appendices 10. Click on the “Proceed” link to take you to the next screen. Proceed screen 11. Enter the Login user name and password. Login screen 12. Configure the Gateway as needed. (See Gateway Configuration Via Laptop on page 16). 2800 Laura Lane •...

  • Page 35: Appendix B: Revert Back To Dhcp Settings

    Appendices Appendix B: Revert Back to DHCP Settings If you have changed your laptop’s network configuration (See Appendix A: Local Management Port on page 29) and wish to revert back to its previous configuration, follow the steps below: Windows 10 or Later: 1.
  • Page 36 Appendices Properties 4. On the Ethernet Properties panel locate the “Internet Protocol Version 4 (TCP/IPv4)”. Select that option, then click on the “Properties” button. 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...
  • Page 37 Appendices TCP/IPv4 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...
  • Page 38 Appendices 5. On the Internet Protocol Version 4 (TCP/IPv4) Properties “General” tab: 6. Click on the “Obtain an IP address automatically” radio button. 7. Click on the “Obtain DNS server automatically” radio button. 8. Click on the “OK” button. Revert back to DHCP settings  2800 Laura Lane •...

  • Page 39: Appendix C: Monitor And Keyboard

    Appendices Appendix C: Monitor and Keyboard The QWL2040 Panel can be configured locally at the device using a keyboard and monitor. If using this method of configuration, you will need: • Monitor with HDMI or DP(Display Port) connection (depending on your monitor, you may need a VGA-to-HDMI/DP adapter) •...

  • Page 40: Appendix D: Configuring Local Management Port As A Fail-Over Port

    Appendix D: Configuring Local Management Port as a Fail-Over Port The QWL2040 Panel Gateway has two Ethernet ports: Cloud Ethernet 1 and Local Ethernet 2. By default, Cloud Ethernet 1 is used to connect the Panel to the Ethernet, and Local Ethernet 2 is configured as a local management port; however, Local Ethernet 2 can be configured as a fail-over Ethernet port in the event of an Internet interruption on Cloud Ethernet 1.
  • Page 41 Failover options section Failover Options Section The Failover Options section contains several default settings that should be adequate in most situations. TCS strongly recommends contacting your IT department before making any changes to the default settings. Click on the green Update Application Info button beneath the RS485 Network Port Configuration section to save the failover server location and other settings.

  • Page 42: Fail-Over Port Configuration Via Cli

    6. Skip to the Local Ethernet 2 fields. Enter the failover network information provided by your IT department. 7. Exit the CLI to save settings. Disconnect the monitor and keyboard. Do not reboot the QWL2040 Panel. Changes made via the CLI will take about five minutes to execute.
  • Page 43 Appendices Failover URL Settings E-port 2 mode settings 2800 Laura Lane • Middleton, WI 53562 800.288.9383 www.tcsbasys.com Building Automation Systems...

  • Page 44: Appendix E: Installing And Using Tcs Insight Software

    TCS Insight is a free software tool for the initial installation, programming, and verification of the lighting and pulse meter modules built into the QWL2040 Panel. It is meant to be used in those instances when you may not have access to Ubiquity Cloud.
  • Page 45 Appendices TCS Insight network tab NOTE: If the laptop does not detect the converter, you will need to install an FTDI driver. Click on the Help tab in the Insight software and select Install FTDI Driver. Follow the installation instructions.
