G-Force LB 102 Instruction Manual

IT IS THE RESPONSIBILITY OF THE USER ORGANISATION TO PROVIDE THE IDENTITY CARD AND TO FILL IN THE DETAILS REQUIRED.
THE IDENTITY CARD SHOULD BE FILLED IN BEFORE THE FIRST USE BY A COMPETENT PERSON, RESPONSIBLE INTHE USER ORGANIZATION FOR PROTECTIVE EQUIPMENT.
ANY INFORMATION ABOUT THE EQUIPMENT LIKE PERIODIC INSPECTIONS, REPAIRS, REASONS OF EQUIPMENT'S WITHDRAWN FROM USE SHALL BE NOTED INTO THE IDENTITY CARD BY A COMPETENT PERSON.
THE IDENTITY CARD SHOULD BE STORAGED DURING A WHOLE PERIOD OF EQUIPMENT UTILIZATION.
DO NOT USE THE EQUIPMENT WITHOUT THE IDENTITY CARD.
ALL RECORDS IN THE IDENTITY CARD CAN BE FILLED IN ONLY BY A COMPETENT PERSON.
IDENTITY CARD
MODEL AND TYPE OF EQUIPMENT
REF. NUMBER
SERIAL NUMBER
USER NAME
DATE OF PURCHASE
PERIODIC EXAMINATION AND REPAIR HISTORY
REASON FOR
DATE
ENTRY PERIODIC EXAMINATION
OR REPAIR AND OTHER REVELANT INFORMATIONS
1
2
3
4
G-Force safety
CHITTENING INDUSTRIAL ESTATE
Avonmouth
BS11 0YB
England
www.safety-lifting.com
tel. 0044 1179 381600
fax 0044 1179 381 602
DATE OF MANUF.
DATE OF PUTTING INTO OPERATION
DEFECTS NOTED, NAME AND SIGNATURE
REPAIRS CARRIED OUT OF COMPETENT PERSON
EC type examination carried out by
CETE APAVE SUDEUROPE
BP 193, 13322 Marseille
France - 0082
Instruction Manual
Double safety lanyard lb 102 is a component of personal protective equipment against falls from a height and complies with
EN 354.
BASIC EQUIPMENT
The lanyard LB 102 is made of 10,5mm polyamide kernmantle rope. The ends of the lanyard are sewn making the connecting
loops equipped with thimbles.
The lanyard connected with a certified (according EN 355) energy absorber and connected to a certified safety harness
(according EN 361) and then attached to a certified anchor point (according EN 795) can be used as a basic personal protective
system against falls from a height.
middle
attaching loop
ATTENTION!
Double safety lanyard LB102 can be equipped only with certified (according to EN 362) snap hooks.
ADMISSIBLE TIME OF USE DOUBLE SAFETY LANYARD LB 102
PERIODIC
! the lanyard must be withdrawn from use and destroyed when:
EXAMINATION
- it was used more than 5 years from the date of putting it into operation.
NEXT DUE DATE
- it was used to arrest a fall.
- any mechanical, chemical or thermal defects have appeared.
the lanyard can be used five years, counting from the date of putting the device into operation. After five years of usage the lanyard must be
!
withdrawn from use and destroyed.
CONTENT OF THE IDENTITY LABEL
1. type of the device
2. reference number of the device*
3. material which device is made of
4. lengths of the lanyard
5. number of the manufacturing series
6. month/year of the device manufacture
7. CE marking with identity number of the notified body
controlling manufacturing of the equipment (the article 11)
8. caution: read the manual
9. number/year of the European standard
10. name of the manufacturer or distributor
*) XX / YY- code of lengths
for example: XX=15 - length 1,5 m
YY=20 - length 2,0 m
DOUBLE
LANYARD
EN 354:2002 Ref. LB 102 XX YY
ø
ø10,5mm polyamide
kernmantle rope
maximal length up to 2 m
XX
DOUBLE SAFETY LANYARD
DATE OF MANUFACTURE:
6
LB 102
SAFETY
end
attaching
loop
end
attaching
loop
1 2 3 4
POLYAMIDE
LB 102 XX YY
LENGTH X,X m / Y,Y m
SERIAL NUMBER:
11.2004 0001
EN 354:2002
7 10 9 8 5
