H5101 | H5102 | H5103
H5104 | H5105 | H5106
GoSmart ZigBee / Wifi switch module
Table of Contents
Safety instructions and warnings ........................................................................................... 2
Contents of the package ........................................................................................................ 3
Technical Specifications .......................................................................................................... 3
Description of the device ....................................................................................................... 4
Installation and assembly ....................................................................................................... 5
Controls and functions ......................................................................................................... 10
Troubleshooting FAQ ........................................................................................................... 12
1
Advertisement
Related Manuals for GoSmart H5101
Summary of Contents for GoSmart H5101
-
Page 1: Table Of Contents
H5101 | H5102 | H5103 H5104 | H5105 | H5106 GoSmart ZigBee / Wifi switch module Table of Contents Safety instructions and warnings ................... 2 Contents of the package ......................3 Technical Specifications ......................3 Description of the device ....................... 4 Installation and assembly ....................... -
Page 2: Safety Instructions And Warnings
Observe the safety instructions in this manual. EMOS spol. s r.o. declares that the products H5101, H5102, H5103, H5104, H5105, H5106 are in compliance with the basic requirements and other relevant provisions of the directives. The equipment can be freely operated in the EU. -
Page 3: Contents Of The Package
Power supply: AC 100-240 V 50/60 Hz Dimension: 40 × 40 × 18 mm Net weight: 30 g App:EMOS GoSmart for Android and iOS Connectivity: 2.4 GHz Wi-Fi (IEEE802.11b/g/n) / Zigbee 2402 ~ 2 480 MHz Frequency band: 2.400-2.4835 GHz... -
Page 4: Description Of The Device
Description of the device 1 - RESET button 2 - Holes for mounting 3 - Wiring diagram of the relevant module 4 - LED status light • Flashing blue - Device is in pairing mode / has disconnected from the network •... -
Page 5: Installation And Assembly
Installation and assembly Place the connected module in the installation box under a switch or socket. Thanks to the possibility of fixing, the module can also be installed in various other places (e.g. under plasterboard, in the ceiling...) The wiring diagram can be found below. - Page 6 Wiring diagrams for Wi-Fi and ZigBee switch modules with LN wires (H5101, H5102, H5105, H5106) 1 channel switch - Without switch1 channel switch - With two switches 1 channel switch - With one switch2 channel switch - Without switch 2 channel switch - With two...
- Page 7 Wiring diagrams for Wi-Fi and ZigBee switch modules without N wire (H5103, H5104) 1 channel switch - Without switch1 channel switch - With two switches 1 channel switch - With one switch2 channel switch - Without switch 2 channel switch - With two switches2 channel switch - With one switch...
- Page 8 Enter the name of a valid email address and choose a password. Confirm your consent to the privacy policy. Select register. Pairing with an app Select Add device. Select a GoSmart product category and select a Smart Switch (ZigBee) / Smart Switch (Wi-Fi) device.
- Page 9 [For ZigBee module only] Select the ZigBee gateway you want to pair the module with. This gateway must be added in the application before pairing the module. Reset the module by holding down the RESET button for 5 seconds or by flipping the physical switch 6 times (6 times on-off) and checking that the LED is flashing.
-
Page 10: Controls And Functions
Controls and functions Icons and indicator lights Advanced settings (described in more detail in the following section) Timers Module settings Switch button (ON/OFF) *Long press to rename the button Description of extension settings • Device information - Basic information about the device and its owner •... - Page 11 Timer settings • Countdown - The device turns off/on after a set time (Depending on the current switch-on status) • Schedule - Scheduling automatic switch-on according to the set time (e.g. Monday from 13:00 to 15:00 - On; 15:00-17:00 - Off...) •...
-
Page 12: Troubleshooting Faq
Troubleshooting FAQ I can't get the devices to pair. What can I do? • Make sure you are using a 2.4GHz Wi-Fi network and have a strong enough signal • Allow the app all permissions in the settings • Make sure you are using the latest version of the mobile operating system and the latest version of the app What can I control with the module? •...
